climate control FIAT 500E 2013 2.G User Guide

Smartphone Features
•With the “FIAT Access” smartphone app, you can monitor the state of charge of the high
voltage battery or initiate charging from your phone .You can also turn on your car’s
climate control system remotely .The smartphone app provides the following features:
• Monitor battery charge level
• Display available driving distance
• Check charging status
• Remotely activate vehicle climate control system
• Unlock and lock doors
• Assist with locating your vehicle
• Locate charging stations
• Send a point-of-interest to your vehicle
• Schedule a charge
• View energy consumed
• Notifications for charging and preconditioning events
How do I get the “FIAT Access” smartphone App?
• Visit the 500e registration website:
https://www .uconnectaccess.fiatusa.com/bevsubscribe/basicSubscription.jsp
•
Once in the registration website, you will need to enter your vehicle’s VIN and Con-
nectivity ID .The connectivity ID is found in
the vehicle's instrument cluster .To locate
the connectivity ID follow the steps below:
1. Press the menu button on the instrument
cluster .
GETTING STARTED
11

EXTENDING YOUR DRIVING RANGE PER CHARGE
•A little knowledge will go a long way to extend your driving range on the 500e .First and
foremost understand that the drive system and cabin temperature management features
use the most energy from the high voltage battery .Reducing energy draw from these
features are the easiest and most effective way to extend driving range .
• Just like a conventional vehicle, 500e likes to keeps things smooth and steady for most
efficient operation. When driving, avoid aggressive driving styles and high speeds for
extended times. When practical, choose surface streets over the highway, work to
maintain a steady speed to extend range .
•
The 500e uses high voltage components to heat and cool the cabin, so a little awareness can go a long way to extend range .When using automatic climate control, consider setting
temperatures a few degrees higher or lower during hot and cold days .If your 500e has been
soaking in hot or cold temperatures for an extended period, it is recommended that the car
be preconditioned via the mobile application while still plugged into a charging source .This
will allow 500e to use external power to establish a comfortable cabin temperature before
the drive, and allow the battery to maintain the temperature using significantly less energy .
Additional tips:
•keep tires properly inflated
• avoid carrying nonessential cargo
• be mindful of adding external accessories that may increase aerodynamic drag
• perform all scheduled maintenance at recommended intervals
OPERATING YOUR VEHICLE
28

Flash To Pass
•Pull the lever toward you to activate the high beams. The high beams will remain on until
the lever is released.
Headlight Delay (Follow Me Home)
•Within two minutes of the ignition switch being turned to the OFF/LOCK position or the igni- tion key being removed from the ignition, pull the turn signal lever toward the steering wheel .
•Each movement of the lever toward the steering wheel will increase the illumination
period by 30 seconds, up to a maximum of 210 seconds.
• To deactivate, pull the multifunction lever toward the steering wheel and hold it for more
than two seconds.
NOTE:
Activation of Follow Me Home is only enabled once per key cycle and steps must be
repeated each time you want to activate it.
Fog Lights
• Push the fog light button, located on the climate controls, once to turn on the fog lights.
• Push the button a second time to turn the fog lights off.
OPERATING YOUR VEHICLE
31

FUSES
Interior Fuses
•The interior fuse panel is part of the Body Control Module (BCM) and is located on the
driver's side under the instrument panel.
Cavity Vehicle
Fuse
Number Mini Fuse
Description
1 F12 7.5 Amp Brown Right Low Beam
2 F32 5 Amp Tan Front and Rear Ceiling Lights Trunk and Door
Courtesy Lights
3 F53 5 Amp Tan Instrument Panel Node
4 F38 20 Amp Yellow Central Door Locking
5 F36 10 Amp Red Diagnostic Socket, Car Radio, Climate Control
System, Tire Pressure Monitor, TCU and CTM
6 F43 20 Amp Yellow Bi-Directional Washer
7 F48 20 Amp Yellow Passenger Power Window
8 F13 7.5 Amp Brown Left Low Beam
9 F50 7.5 Amp Brown Airbag
10 F51 5 Amp Tan Car Radio Switch, Climate Control System,
Stop Light, Exterior Mirrors, Sunroof Switch,
GPS (option) and CTM
11 F37 5 Amp Tan Stop Light Switch, Instrument Panel Node
12 F49 5 Amp Tan Exterior Mirror, GPS, Electric Mirror, Parking
Sensor, Sunroof Switch
13 F31 5 Amp Tan Ignition, Climate Control, RDU and EVCU
14 F47 20 Amp Yellow Driver Power Window
MAINTAINING YOUR VEHICLE
71
