compression ratio FIAT 500L 2019 Owner handbook (in English)

ENGINE
Versions 1.4 16V 95 HP
Engine code 843A1000
CycleOtto
Number and position of cylinders 4 in line
Piston bore and stroke (mm) 72.0 × 84.0
Total displacement (cm³) 1368
Compression ratio 11 ± 0.2
Maximum power (EC) (kW) 70
Maximum power (EEC) (HP) 95
corresponding engine speed (rpm) 6000
Maximum torque (EEC) (Nm) 127
Maximum torque (EEC) (kgm) 12.9
corresponding engine speed (rpm) 4500
Spark plugs NGK DCPR7E-N-10
Fuel Unleaded petrol 95 R.O.N. (EN228 specifications)
Emission level Euro 6
172
TECHNICAL DATA

Versions 1.3 16V 95 HP Multijet
Engine code 330A1000
CycleDiesel
Number and position of cylinders 4 in line
Piston bore and stroke (mm) 69.6 × 82.0
Total displacement (cm³) 1248
Compression ratio 16.8 ± 0.4
Maximum power (EC) (kW) 70
Maximum power (EEC) (HP) 95
corresponding engine speed (rpm) 3750
Maximum torque (EEC) (Nm) 215
Maximum torque (EEC) (kgm) 21.9
corresponding engine speed (rpm) 1500
Fuel Diesel for motor vehicles (EN590 Specification)
Emission level Euro 6
173

Versions 1.6 16V 120 HP MultiJet
Engine code940C1000
CycleDiesel
Number and position of cylinders 4 in line
Piston bore and stroke (mm) 79.5 × 80.5
Total displacement (cm³) 1598
Compression ratio 16.5 ± 0.4
Maximum power (EC) (kW) 88
Maximum power (EEC) (HP) 120
corresponding engine speed (rpm) 3750
Maximum torque (EEC) (Nm) 320
Maximum torque (EEC) (kgm) 32.6
corresponding engine speed (rpm) 1750
Fuel Diesel for motor vehicles (EN590 Specification)
Emission levelEuro 6
174
TECHNICAL DATA
