21
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
Pause function
If while listening to a Compact Disc another function is
selected (e.g.: the radio), playing is stopped and when
the Compact Disc mode is resumed, it starts again
from the point in which it was stopped.
If while listening to the radio another function is
selected, when the Radio mode is resumed, it is tuned
to the last station selected.Volume adjustment
Volume level can be adjusted from min. (“VOLUME
0”) to max. (“VOLUME 66”) volume.
Adjust volume through button/knob 19 (ON/OFF
VOLUME).
Turn the knob rightwards to increase volume and
leftwards to decrease it. Set volume is displayed for
about 4 seconds (e.g.: “VOLUME 23”).
If the volume level is changed during the broadcast of a
traffic bulletin or during use of the phone (if the voice
feature is installed), the new setting is maintained only
until the end of the bulletin or phone call.
Volume can be also adjusted during manual/automatic
tuning, AutoSTore, radio station scan or CD Changer
mode.

27
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
Should it be not possible to receive the PI stored on a
frequency after searching along the whole band, the
radio will tune to the stored frequency.
Pressing the respective preset button for longer than 2
seconds will store the tuned station (the sound system
will always store the frequency and the PI code).
Storing is confirmed by a beep.
Storing the last station heard
The radio automatically keeps in storage the last
station heard for each reception band, which is then
tuned when the radio is turned on or the reception
band is changed.
Automatic tuning
Briefly press button 3 (
N) or 6 (O) to start
automatically searching the tuning for the next station
that it is possible to receive in the direction chosen.
If button 3 (
N) or 6 (O) is pressed for longer, quick
searching takes place: upon having tuned in to the first
well receivable station, the tuner stops for about 1
second (in Mute) before quick searching continues.
When the button is released, the tuner stops on the
next receivable station.
If the TA function is on (traffic information), the tuner
only searches stations which broadcast traffic bulletins.If the PTY function is on, the tuner only searches PTY
stations. When searching, the display alternatively
shows the type of programme and the word
“SEARCH”.
If the station on which the tuner stops is one of the
stations stored with the preset buttons, the display will
show the presetting number for a few seconds.
Manual tuning
This allows manual station searching in the chosen
band.
Proceed as follows:
❒select the band with button 13 (BAND-
AUTOSTORE): FM1, FM2, FMT, MW or LW;
❒press briefly and repeatedly button 7 (
÷) or 5
(
˜) to start searching in the chosen band.
Pressing one of the buttons 7 (
÷) or 5 (˜)
longer obtains fast forward searching, which is
stopped when the button is released.
To turn on manual tuning search it is necessary to turn
off the PTY and AF (alternative frequencies), if on.
If the station tuned is a station stored with the preset
buttons, the display will show the presetting number
for a few seconds.

44
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
Possible error messages
If the CD inserted is illegible (e.g.: CD-ROM inserted,
CD not inserted properly or reading error), the
display will show the wording “CD ERROR” for about
2 seconds.
The CD is then ejected and the previous source
before CD was selected returns.
Display information
When the CD player is working, the display shows the
following information which means:
“T05”: shows the number of the track on the CD
“03:42”: shows the time elapsed since the start of the
track (if the corresponding Menu function is on)
“XXXXXXX”: shows the name allocated to the CD.
If the CD Name function is selected and no CD name
is stored, the display will show the track time.Select track (forward/backward)
Briefly press button 7 (
÷) to play the previous track
and button 5 (
˜) to play the next one. Tracks are
played in sequence:after the last track, the first one
will be played and vice versa.
If playing the track started more than 3 seconds ago,
pressing briefly button 7 (
÷) the track is played
again from the start. In this case if wanting to play the
previous track, press the button twice consecutively.
Fast forward/backward
Keep button 5 (
˜) pressed to move the track
selected forward at high speed and keep button 7
(
÷) pressed to move it quickly backward.Fast
forward/backward is stopped once the button is
released.
If the CD name display function was selected in the
menu, this will be replaced by the CD time display
function. CD name display is resumed after about 2
seconds from pressing the button.

45
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
Pause function
To pause the CD player, press button 14 (3-II). The
display will show “PAUSE”.
To resume playing the track,press button 14 (3-II)
again.
The pause function is deactivated changing the sound
source.
Scan function (scanning CD tracks)
With this function it is possible to play the start of all
the CD tracks contained in the CD Changer.
Keep button 1 (SOURCE-SCAN) pressed until hearing
the “beep” to play the first 10 seconds of every track
on the CD. While playing the display will alternately
show for about 2 seconds, the CD function chosen
(CD time, name or number) and the word “SCAN”. If
the Scan function is on, the Repeat and Mix functions
are turned off.
The scanning sequence is the following:
❒from the track played up to the last of the tracks on
the CD;
❒from the first CD track to the last one (after the
last one, scanning will restart from the first one and
so on).The Scan function is interrupted in the following cases:
❒pressing button 1 (SOURCE-SCAN) again to
continue listening to the track being played;
❒pressing button 3 (
N) or 6 (O);
❒pressing a preset button (from 1 to 6);
❒turning the Mute function on;
❒changing the sound source;
❒pressing button 1 (SOURCE-SCAN), 12 (MENU-
PRESET SCAN) or 9 (AUDIO-LOUDNESS);
❒if the TA function is on and the station selected is
broadcasting a traffic bulletin.
The Scan function will stay on until stopped by the
user.

48
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
CD CHANGER (CDC) (where provided)
CD Changer (multiple Compact Disc player) for 5
discs is available at Lineaccessori Fiat.
Selecting the CD Changer
Turn on the set,then press briefly button
1 (SOURCE-SCAN) to select the “CHANGER”
function.
Inserting/ejecting a CD
To insert CDs into the CD Changer: insert gently a
CD with the label upwards into the CD Changer
compartment and push it gently to the stop. The
powered loading system will position it correctly.
To eject CDs from the CD Changer: keep pressed the
button with the number corresponding to the CD to
be ejected, set near the CD compartment.Possible error messages
Error messages will be displayed in the following cases:
❒no CD in the CD Changer:the display will show
“CD ERROR” until changing the sound source;
❒selected CD is illegible (CD not in the selected
position or CD not inserted properly): the display
shows “CD ERROR” after the number of the
selected CD for about 2 seconds. The next CD will
be selected; if there are no other CDs or if they are
also illegible the display will show the wording “NO
CD” until the sound source is changed;
❒error in CD reading: the display shows “CD
ERROR” for about 2 seconds. The next CD will be
selected; if there are no other CDs in the CD
Changer (after the last CD search will restart from
the first one) or if they are also illegible the display
will show the wording “NO CD” until the sound
source is changed;
❒a CD-ROM is inserted: next CD will be selected.

49
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
Display information
When the CD Changer is working,the display shows
the following information which means:
❒“T05”: shows the number of the track on the CD;
❒“03:42”: shows the time elapsed since the start of
the track (if the corresponding Menu function is on);
❒“CD 04”: the number of the CD in the loader.
❒“XXXXXXX”: shows the name allocated to the
CD.
Choosing the CD
Press button 3 (
N) to select the next CD and button
6 (
O) to select the previous CD. If in the menu the
CD time display function was selected, this will be
replaced for about 2 seconds by the CD number.
If the loader does not contain a disc in the position
selected, the display briefly shows the wording “NO
CD”, and the next CD is played automatically.Select track (forward/backward)
Briefly press button 7 (
÷) to play the previous track
of the CD chosen and button 5 (
˜) to play the next
one. Tracks are played in sequence:after the last
track, the first one will be played and vice versa.
To select tracks continuously, keep the button
pressed.
If playing the track started more than 3 seconds ago,
pressing briefly button 7 (
÷) the track is played
again from the start.In this case if wanting to play the
previous track, press the button twice consecutively.
Fast forward/backward
Keep button 7 (
÷) pressed to move the track
selected backward at high speed and keep button 5
(
˜) pressed to move it quickly forward. Fast
forward/backward is stopped once the button is
released.
If the CD number or CD name display function was
selected in the menu,this will be replaced for about 2
seconds by the CD time display function.

64
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
Display information
When a MP3 CD is inserted the display shows “CD”
and the following information which means:
❒“TR05”: shows the number of the track on the MP3
CD;
❒“BEST OF”: shows the name given to the directory
(if the relevant menu function is active);
❒“XXX*XXX”: shows the track name and the artist’s
name (if the relevant menu function is active);
❒“03:42”: shows the time elapsed since the start of
the track (if the relevant menu function is active);
❒“BEST 01”: shows the MP3 CD name
(if the relevant menu function is active);Select track (forward/backward)
Briefly press button 7 (
÷) to play the previous track
and button 5 (
˜) to play the next one. Tracks are
played in sequence: after the last track, the first one of
the current directory will be played and vice versa.
If no other directory/track is selected in the following
2 seconds, the first track in the new directory will be
played.
If playing the track started more than 3 seconds ago,
pressing briefly button 7 (
÷) the track is played
again from the start.In this case if wanting to play the
previous track, press the button twice consecutively.
Fast forward/backward
Keep button 5 (
˜) pressed to move the track
selected forward at high speed and keep button 7
(
÷) pressed to move it quickly backward. Fast
forward/backward is stopped once the button is
released.
If the directory display function, track title and artist’s
name or file name display function was selected in the
menu, this will be replaced for about 2 seconds by
track elapsed time function display function.

65
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
Scan function (scanning MP3 CD tracks)
With this function it is possible to listen to the
beginning of all the tracks contained in the CD.
Keep button 1 (SOURCE-SCAN) pressed until hearing
the “beep” to play the first 10 seconds of every track
on the CD. While playing the display will alternately
show for about 2 seconds, the CD function chosen
(CD time, name or number) and the word “SCAN”. If
the Scan function is on, the Repeat and Mix functions
are turned off.
The scanning sequence is the following:
❒from the track played up to the last of the tracks in
the directory;
❒changing directory and scanning tracks from start to
end (and so on for every directory in the CD until
the function is interrupted).The Scan function is interrupted in the following cases:
❒pressing button 1 (SOURCE-SCAN) again to
continue listening to the track being played;
❒pressing button 3 (
N) or 6 (O) (in MP3 CD mode,
will select previous/next directory);
❒pressing a preset button (from 1 to 6);
❒turning the Mute function on;
❒changing the sound source;
❒pressing button 1 (SOURCE-SCAN),
12 (MENU-PRESET SCAN) or
9 (AUDIO-LOUDNESS);
❒if the TA function is on and the station selected is
broadcasting a traffic bulletin.
The Scan function will stay on until stopped by the
user.
