182TECHNICAL SPECIFICATIONS
TRANSMISSION
CLUTCH
Hydraulic, self-adjusting external
control.
GEARBOX
Five forward gears and reverse with
synchromesh for front gear engage-
ment.
Cyclical gear reduction and differen-
tial assembly incorporated in the gear-
box.
Drive transmission to the front
wheels by means of drive shafts con-
nected to the differential assembly and
the wheels with CV joints.
BRAKES
SERVICE AND
EMERGENCY BRAKES
Front:
– disc, floating shoe, self-ventilated.
Rear:
– drum, self-centring callipers.
Crossed hydraulic circuit control.
Vacuum brake booster.
ABS system with four sensors and
EBD.
Automatic take-up of friction liner
wear.
Lacking the ABS, there is the brake
force distributor that acts on rear
brake circuit according to load on rear
axle
HANDBRAKE
Controlled by a lever, it works me-
chanically on the rear brake shoes.
SUSPENSIONS
FRONT
Independent wheel, McPherson sus-
pension with steel wishbones an-
chored to an auxiliary crossmember.
Coil springs and sway bar.
Double acting telescopic hydraulic
shock absorbers.
REAR
Stiff axle with wishbones.
Double acting telescopic hydraulic
shock absorbers.
Sway bar in Fiat Doblò Passengers
Transport versions.
174-211 Doblo GB 16-12-2008 14:26 Pagina 182

203TECHNICAL SPECIFICATIONS203
Use
Lubricants and greases
for transmission
Brake fluids
Radiator
antifreeze
Diesel fuel additive
Windscreen/
rear window
washer fluid
(*) IMPORTANT Do not top up or mix with fluids having characteristics different from those specified.
(❑) For particularly hard climate conditions, we recommend use of a 60% PARAFLU UP and 40% demineralized water mixture.
Specifications of the lubricants and fluids to
use for best vehicle operation
Oil SAE 75W-80 EP that passes API GL-5 and MIL-L-
2105D LEV specifications
Oil type ATF DEXRON II D LEV, SAE 10 W
Synthetic fluid, FMVSS n° 116 DOT 4, ISO 4925,
SAE J-1703, CUNA NC 956-01
Red protective with antifreeze action, based on
inhibited monoethylen glycol with organic formula based
on O.A.T,
That passes CUNA NC 956-16, ASTM D 3306
specifications
Diesel fuel additive
Mixture of alcohol and surfactants CUNA NC 956-II
Fluids and lubricants
recommended
TUTELA CAR
ZC 75 Synth
TUTELA GI/E
TUTELA TOP 4
PARAFLU UP
(*)
TUTELA DIESEL ART
TUTELA
PROFESSIONAL SC
35
Applications
Mechanical gearbox
and differentials
Hydraulic power
steering
Hydraulic brakes and
clutch controls
Radiator antifreeze
proportion:
50% distilled water and
50% PARAFLU UP (❑)
To be mixed with
diesel fuel
(25 cm
3for 10 litres)
To be used diluted or
undiluted
