122IN AN EMERGENCY
To change a wheel proceed as
follows:
1)Stop the vehicle in a position that
is not dangerous for oncoming traffic
where you can change the wheel safe-
ly. The ground should be flat and ad-
equately firm. Do not lubricate the bolt
threads before fitting
them back: they could
come loose.
Fasten the wheel cap correctly
to prevent the wheel from com-
ing free in motion.
Never tamper with the inflation
valve.
Never place tools between the
rim and tyre.
Check the tyre and spare wheel
pressure regularly. The tyre in-
flation pressure is shown in sec-
tion “Technical specifications”.
CHANGING A WHEEL
Please note:
– The jack weighs 1.85 kg
– The jack requires no adjustments
– The jack cannot be repaired. If it
breaks it must be replaced with a new
jack
– No tool with the exception of the
handle can be fitted on the jack.2)Turn the engine off and pull up the
handbrake.
3Engage first or reverse gear.
4)Either move the left-hand front
seat back forwards (Fiat Doblò Car-
go versions) lifting lever A-fig. 2and
take the tool bag shown in fig. 3or lift
the rear seat (for Fiat Doblò Passen-
ger Transport versions) with lever B-
fig. 4and take the bag shown in fig.
5. Take the bag to the wheel to be re-
placed.
5)Take the wheel removal wrench.
A
fig. 2
F0A0040b
fig. 3
F0A0094b
119-148 Doblo GB 9-05-2008 12:09 Pagina 122
Page 126 of 222
125IN AN EMERGENCY
– When fitting the space-saver spare
wheel back onto container, fit the
spacer tab on the outer side of the
rim, then position the space-saver
spare wheel with the outer side of the
rim fig. 14bfacing upwards
– hook the lower side of the support
bracket C-fig. 16to the anchoring
spring Dand tighten the support bolt
fig. 6.3) Put the jack and tools back in the
tool bag.
4)Rearrange the tool bag behind the
left-hand side seat (Fiat Dobló Cargo
versions) or under the rear seat (Fiat
Doblò Passengers Transport ver-
sions).
5)Fasten the bag with the elastic
band.
IMPORTANT Do not use inner
tubes with tubeless tyres.
Check the inflation pressure of the
tyres and the spare wheel regularly.
Use the extension shown in fig. 13
to fasten or loosen the inflation valve
cap.
fig. 13
F0A0713b
fig. 14a
F0A0280b
fig. 15
F0A0281b
In certain Passengers Transport ver-
sions instead of the traditional spare
wheel, a space-saver spare wheel is
provided. For anchoring to support
proceed as follows:
– If the space-saver spare wheel is
used, the spacer pad cannot be refit-
ted on the outer side of the standard
wheel rim but it shall be stowed tem-
porarily in the luggage compartment.
fig. 14b
F0A0611b
fig. 16
F0A0610b
119-148 Doblo GB 9-05-2008 12:09 Pagina 125
Page 129 of 222
128IN AN EMERGENCY
– make sure the compressor switch
E-fig. 16fis set to 0(off), start the en-
gine and fit plug D-fig. 16einto the
nearest current outlet and then turn
on the compressor by setting switch
E-fig. 16ftoI(on). Inflate the tyre to
the pressure specified in paragraph
“Inflation pressure” in section “Tech-
nical Specifications”. Check tyre pres-
sure on gauge Fwith compressor off
to obtain precise reading;
– if after 5 minutes it is still impossi-
ble to reach at least 1.5 bar, disengage
compressor from valve and current
outlet, then move the vehicle forth for
approx. ten metres in order to dis-
tribute the sealing fluid inside the tyre
evenly, then repeat the inflation oper-
ation;– If after this operation it is still im-
possible after 5 minutes to reach at
least 1.8 bar, do not start driving since
the tyre is excessively damaged and
the quick tyre repair kit cannot guar-
antee suitable sealing, contact Fiat
Dealership;
– if reaching the tyre pressure spec-
ified in paragraph “Inflation pressure”
in section “Technical Specifications”,
start driving immediately;Apply the sticker in a vis-
ible position for the driver
to indicate that the tyre
has been treated with the quick
tyre repair kit. Drive carefully es-
pecially when cornering. Do not
exceed 80 km/h. Avoid heavy
braking and accelerating.
fig. 16c
F0A0714b
fig. 16d
F0A0715b
fig. 16e
F0A0539b
fig. 16f
F0A0545b
119-148 Doblo GB 9-05-2008 12:09 Pagina 128
Page 150 of 222
149VEHICLE MAINTENANCE
V V
E E
H H
I I
C C
L L
E E
M M
A A
I I
N N
T T
E E
N N
A A
N N
C C
E E
IMPORTANTThe Manufacturer
requires the Service Schedule coupon-
related checks to be carried out. Fail-
ure to do so could result in the war-
ranty being cancelled for those defects
that can be attributed to such failure.
Scheduled Servicing is performed at
all Fiat Dealershipsand there is a set
time scale for such operations.
If during each operation, in addition
to the ones programmed, the need
arises for further replacements or re-
pairs, these may be carried out only
with the explicit agreement of the
Customer.IMPORTANT You are recom-
mended to get in touch with a Fiat
Dealershipimmediately if any minor
running problems crop up without
waiting for the next coupon.SCHEDULED
SERVICING
Correct maintenance of the vehicle
is essential for ensuring it stays in tip-
top condition for a long time to come.
This is why Fiat has programmed a
series of checks and maintenance op-
erations every 20,000 km.
It is however important to remem-
ber that scheduled servicing is not all
your vehicle requires. Regular checked
- also in the initial period before the
20,000 kilometre coupon and later be-
tween coupons - ordinary care is re-
quired, such as checking fluid levels
and topping up, checking tyre inflation
pressure, etc...
149-173 Doblo GB 9-05-2008 12:10 Pagina 149
Page 168 of 222
167VEHICLE MAINTENANCE
Tyres must be replaced when the
tread wears down to 1.6 mm. In any
case, comply with the laws in the
country where the vehicle is being dri-
ven.
IMPORTANT NOTES
As far as possible avoid sharp brak-
ing and screech starts.
Be careful not to hit the kerb, pot-
holes or other obstacles hard. Driving
for long stretches over bumpy roads
can damage the tyres.
Periodically check that the tyres have
no cuts in the sidewalls, abnormal
swelling or irregular tyre wear. If any
of these occur, have the vehicle seen
to at a Fiat Dealership. If the pressure is too low
the tyre overheats and
this can cause it serious
damage.
WHEELS
AND TYRES
TYRE PRESSURE
Check the pressure of each tyre, in-
cluding the spare, every two weeks
and before long journeys.
The pressure must be checked when
the tyre is rested and cold.
It is normal for the pressure to rise
when you are driving. If you have to
check or restore the pressure when
the tyres are warm, remember that
the pressure value must be 0.3 bar
above the specified value.
See “Wheels” in “Technical specifi-
cations” for the correct tyre inflation
pressure.Incorrect pressure causes abnormal
tyre wearfig. 22:
A- Correct pressure: tyre wears
evenly
B- Under inflated tyre: shoulder
tread wear
C- Over inflated tyre: centre tread
wear.Tyre pressure must be
correct to ensure good
road holding.
ABC
fig. 22
F0A0173b
149-173 Doblo GB 9-05-2008 12:10 Pagina 167
Page 186 of 222
185TECHNICAL SPECIFICATIONS
COLD INFLATION PRESSURES (bar)
Versions Size Medium load Full load
Front Rear Front Rear
Passenger Transportation 185/65 R15 88T 2.3 (*) 2.3 (*) 2.3 2.7
Family (7 seater) 185/65 R15 92T 2.3 2.7 2.3 2.7
Cargo standard capacity/Combi N1185/65 R15 92T 2.3 2.7 2.3 2.7
Cargo extra capacity/Long wheelbase 175/75 R14 C99/98T 3.0 3.5 3.0 3.5
Combi N1 exra capacity 175/75 R14 C99/98T 2.8 3.0 3.0 3.5
Passenger Transportation Natural Power 175/70 R14 88T 2.6 3.0 2.6 3.0
Cargo Natural Power 175/70 R14 C95/93S 2.8 3.5 2.8 3.5
With warm tyres the pressure should be +0.3 bar in relation to the prescribed value. Check again the correct pressure when the tyres are cold.
(*) Up to 3 people + 50 kg. Versions Steel Alloy Factory-fitted Alternative Tyre Space-saver
rim rim tyre min. sizes that (*)spare wheel
can be adopted (**)
Passenger Transportation 5,5 J x 15H2-ET32 5,5 J x 15H2-ET32 185/65 R15 88T 185/65 R15 88T185/65 R15 88Q (M+S)125/80 R15 95M
Family (7 seater) 5,5 J x 15H2-ET32 5,5 J x 15H2-ET32185/65 R15 92T 185/65 R15 88T185/65 R15 88Q (M+S) –
Cargo 5,5 J x 15H2-ET32 5,5 J x 15H2-ET32 185/65 R15 92T 175/75 R14 C99/98T185/65 R15 92Q (M+S) –
standard capacity/ (or EXTRA LOAD 175/70 R14 C95/93T 175/70 R14 C95/93T
Combi N1or Reinforced)
Cargo 5,5 J x 14H2-ET32 5,5 J x 14H2-ET32 175/75 R14 C99/98T 175/75 R14 95S 175/75 R14 C99/98 Q (M+S) –
exra capacity/175/70 R14 95S 175/70 R14 C95/93T
Long wheelbase/
Combi N1(where fitted)
Passenger Transportation 5,5 J x 14H2-ET32 5,5 J x 14H2-ET32 175/70 R14 88T 175/70 R14 C95/93S 175/70 R14 88 Q (M+S) –
Natural Power
Cargo Natural Power 5,5 J x 14H2-ET32 5,5 J x 14H2-ET32 175/70 R14 C95/93S – 175/70 R14 C95/93T –
(*) Tyres with load and speed index equal to or higher than the specified values are admitted
(**) When replacing tyres, you are however recommended to adopt tyres with load and speed ratings equal to or higher than those of the factory-fitted tyres.
174-211 Doblo GB 16-12-2008 14:26 Pagina 185
Page 216 of 222
215INDEX
Rearview mirrors
- electric ....................................... 56
- exterior ..................................... 55
- interior ...................................... 55
Rev counter .................................. 24
Reversing light ............................... 134
Rims ........................................ 183-185
Roof bars
- fasteners presetting ................ 86
Rubber tubing................................ 168
SBR system ................................. 10
Seat adjustment ............................ 48
Seat belts
- general warnings...................... 13
- height adjustment.................... 11
- maintenance ............................ 14
- use .............................................. 9
Seats
- accessing the rear seat........... 52
- adjustments .............................. 48
- cleaning ...................................... 173
- electrically heated ................... 49
- passenger folding seat ............ 50
Side doors ...................................... 75
Side/taillights
- control ...................................... 63- front bulb replacement .......... 133
- rear bulb replacement ........... 134
Snow chains ................................... 116
Snow tyres .................................... 117
Sound system ............................... 97
- setup system ............................ 97
- sound system installation ...... 98
Spark plugs
- maintenance ............................. 181
- type............................................. 179
Starting the engine ....................... 105
- bump starting ........................... 121
- diesel versions ......................... 107
- emergency startup ......... 107-119
- ignition switch .......................... 20
- jump starting ............................ 120
- petrol versions......................... 106
- stopping the engine ................ 108
- warming up the engine .......... 107
Steering column lock ................... 20
Steering column stalks
- left-hand stalk ......................... 63
- right-hand stalk ........................ 64
Steering wheel adjustment ......... 55
Steering........................................... 183
Stopping the engine ..................... 107
Storing the vehicle ....................... 118Structure ........................................ 183
Sun visors ....................................... 71
Suspensions .................................. 182
Symbols........................................... 6
Tailgate.......................................... 79
Technical characteristics ............ 174
Third brake lights ........................ 136
Tilting shelf ................................... 71
Tools ............................................... 121
Top speed ...................................... 186
Towing a trailer
- assembly diagram .................... 114
- tow hitch installation .............. 114
- warnings ................................... 113
Towing the vehicle ....................... 146
Transmission ................................ 182
Transporting children in safety . 15
Trip computer .............................. 36
Tyre pressure................................ 185
Tyres
- if a tyre is punctured .............. 121
- inflation pressure .................... 184
- reading ....................................... 184
- standard..................................... 185
Using the gearbox ..................... 109
212-220 Doblo GB 16-12-2008 14:26 Pagina 215
Page 221 of 222
FUEL CAPACITY (litres) ENGINE OIL CHANGE
1.4 1.3 Multijet 1.9 Multijet
litres kg litres kg litres kg
Oil sump2.4 2.1 3.0 2.6 4.0 3.5
Oil sump and filter2.6 2.25 3.2 2.8 4.3 3.7
Dispose of waste oil properly
Versions Size Medium load Full load
Front Rear Front Rear
Passenger Transportation 185/65 R15 88T 2.3 (*) 2.3 (*) 2.3 2.7
Family (7 seater) 185/65 R15 92T 2.3 2.7 2.3 2.7
Cargo standard capacity/Combi N1185/65 R15 92T 2.3 2.7 2.3 2.7
Cargo extra capacity/Long wheelbase 175/75 R14 C99/98T 3.0 3.5 3.0 3.5
Combi N1 exra capacity 175/75 R14 C99/98T 2.8 3.0 3.0 3.5
Passenger Transportation Natural Power 175/70 R14 88T 2.6 3.0 2.6 3.0
Cargo Natural Power 175/70 R14 C95/93S 2.8 3.5 2.8 3.5
With warm tyres the pressure should be +0.3 bar in relation to the prescribed value. Check again the correct pressure when the tyres are cold.
(*) Up to 3 people + 50 kg.
Tank capacity.................................................................................................................... 60
Reserve.......................................................................................................................... 5 - 7
Use only unleaded petrol with a rated octane number (RON) not less than 95.
Refuel diesel vehicles with diesel fuel for motor vehicles (EN590 Specification).
COLD TYRE INFLATION PRESSURE (bar)
Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print no. 603.81.542 - 12/2008 - 2
ndedition
212-220 Doblo GB 16-12-2008 14:26 Pagina 220
