wheelbase FIAT DOBLO COMBI 2015 2.G Workshop Manual

1.4 T-JET Euro 5 / Euro 6 Combined
Cargo short wheelbase / Cargo long wheelbase 169
Cargo Short wheelbase, High roof 175
Cargo Long wheelbase, High roof 179
Combi 5-seater169
Combi 5-seater, Long wheelbase 173
Doblò 5/7-seater169
1.3 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Combined
Cargo short wheelbase 126
Cargo Short wheelbase, Increased payload 126
Cargo long wheelbase 129
Combi 5-seater129
Flatbed short wheelbase / long wheelbase (F.C.*
1360)128
Flatbed short wheelbase / long wheelbase (F.C.*
1590)137
Flatbed short wheelbase / long wheelbase (F.C.*
1700)142
*Flywheel class
1.3 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Eco
PackCombined
Cargo Short Wheelbase 115
Cargo Increased payload, Short wheelbase 115
298
TECHNICAL SPECIFICATIONS

1.3 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Eco
PackCombined
Cargo Increased payload, Long wheelbase 118
Combi Short wheelbase / Long wheelbase 118
Flatbed short wheelbase / long wheelbase (F.C.*
1360)117
Flatbed short wheelbase / long wheelbase (F.C.*
1590)126
Flatbed short wheelbase / long wheelbase (F.C.*
1700)131
*Flywheel class
1.3 MultiJet 90 HP Euro 5 / Euro 5+ NO Start&Stop with
DPFCombined
Cargo Short wheelbase / Cargo Short wheelbase, Increased
payload / Cargo Long wheelbase133
Combi 5-seater, Short wheelbase / Combi 5-seater, Long
wheelbase136
Flatbed short wheelbase / long wheelbase (F.C.*
1360)135
Flatbed short wheelbase / long wheelbase (F.C.*
1590)144
Flatbed short wheelbase / long wheelbase (F.C.*
1700)149
*Flywheel class
1.3 MultiJet Euro 4 Combined
Cargo short wheelbase 136
Cargo Short wheelbase, Increased payload 136
299

1.3 MultiJet Euro 4 Combined
Cargo long wheelbase 139
Combi 5-seater139
Flatbed141
1.3 MultiJet Euro 4 Start&Stop with DPF Combined
Doblò 5/7-seater129
1.3 MultiJet 75 HP Euro 5+ DPF Start&Stop Combined
Cargo 1,000 kg short wheelbase / long wheelbase 137
Cargo short wheelbase / Cargo short wheelbase, increased
payload126
Cargo long wheelbase, increased payload / Combi 5-seater 129
1.3 MultiJet 75 HP Euro 5+ DPF NO Start&Stop Combined
Cargo 1,000 kg short wheelbase / long wheelbase 144
Cargo Short wheelbase / Cargo Short wheelbase, Increased
payload / Cargo Long wheelbase133
Combi 5-seater / Cargo long wheelbase / Increased payload 136
1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Combined
Cargo short wheelbase 136
300
TECHNICAL SPECIFICATIONS

1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Combined
Cargo short wheelbase, increased payload Cargo long
wheelbase137
Combi 5-seater, short wheelbase 138
Combi 5-seater, long wheelbase 141
Doblò 5/7-seater138
Cargo short wheelbase, High roof / Cargo short wheelbase,
increased payload, High roof146
Doblò 5-seater, High roof 150
Doblò 5-seater, long wheelbase 138
Flatbed short wheelbase / long wheelbase (F.C.*
1360)140
Flatbed short wheelbase / long wheelbase (F.C.*
1470)148
Flatbed short wheelbase / long wheelbase (F.C.*
1590)150
Flatbed short wheelbase / long wheelbase (F.C.*
1700)154
Flatbed short wheelbase / long wheelbase (F.C.*
1810)170
*Flywheel class
1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Eco
PackCombined
Cargo Short Wheelbase 124
Cargo Increased payload, Short wheelbase / Long wheelbase 125
Combi Short wheelbase 126
Combi Long wheelbase 129
301

1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Eco
PackCombined
Panorama Short wheelbase / long wheelbase - Doblò Short
wheelbase / long wheelbase126
Cargo / Cargo Increased payload, Short wheelbase, High roof 134
Panorama Short wheelbase High roof 136
Flatbed short wheelbase / long wheelbase (F.C.*
1360)128
Flatbed short wheelbase / long wheelbase (F.C.*
1470)135
Flatbed short wheelbase / long wheelbase (F.C.*
1590)137
Flatbed short wheelbase / long wheelbase (F.C.*
1700)141
Flatbed short wheelbase / long wheelbase (F.C.*
1810)155
*Flywheel class
1.6 MultiJet 105 HP Euro 5 / Euro 5+ NO Start&Stop Combined
Cargo Short Wheelbase 143
Cargo Short wheelbase, Increased payload 144
Cargo Long wheelbase / Combi 5-seater, Short wheelbase 145
Combi 5-seater, Long wheelbase 148
Doblò 5/7-seater145
Cargo Long wheelbase, High roof 158
Cargo Short wheelbase, High roof 154
Cargo Short wheelbase, High roof, Increased payload / Doblò
5-seater, High roof158
302
TECHNICAL SPECIFICATIONS

1.6 MultiJet 105 HP Euro 5 / Euro 5+ NO Start&Stop Combined
Doblò 5-seater, long wheelbase 145
Flatbed short wheelbase / long wheelbase (F.C.*
1360)148
Flatbed short wheelbase / long wheelbase (F.C.*
1470)156
Flatbed short wheelbase / long wheelbase (F.C.*
1590)158
Flatbed short wheelbase / long wheelbase (F.C.*
1700)162
Flatbed short wheelbase / long wheelbase (F.C.*
1810)178
*Flywheel class
1.6 MultiJet 90 HP Euro 5 / Euro 5+ NO Start&Stop Combined
Doblò 5/7-seater145
Doblò 5-seater, High roof 158
1.6 MultiJet Euro 4 Combined
Cargo short wheelbase 143
Cargo increased payload / short wheelbase / long wheelbase 144
Cargo short wheelbase, High roof / Cargo short wheelbase,
increased payload, High roof152
1.6 MultiJet Euro 4 Start&Stop with DPF Combined
Doblò 5/7-seater138
Doblò 5-seater, High roof 150
303

2.0 MultiJet Euro 5 / Euro 5+ Combined
Cargo short wheelbase/long wheelbase 148
Combi 5-seater / Doblò 5/7-seater 150
Cargo short wheelbase, High roof / Cargo short wheelbase,
increased payload, High roof152
Doblò 5-seater, High roof 157
Doblò 5-seater, long wheelbase 150
2.0 MultiJet 135 HP Euro 5 / Euro 5+ Combined
Cargo Short Wheelbase 154
Cargo Short wheelbase, Increased payload / Cargo Long
wheelbase / Combi 5-seater, Short wheelbase156
Combi 5-seater, Long wheelbase - Doblò 5/7-seater - Cargo
Long wheelbase, High roof163
Cargo Short wheelbase, High roof 158
Cargo Short wheelbase, High roof, Increased payload / Cargo
Short wheelbase, High roof167
Cargo Short wheelbase, High roof, Increased payload - Doblò
5-seater, High roof163
Combi 5-seater, Long wheelbase, High roof 167
Doblò 5-seater, long wheelbase 156
Flatbed short wheelbase / long wheelbase (F.C.*
1360)153
*Flywheel class
304
TECHNICAL SPECIFICATIONS

2.0 MultiJet 135 HP Euro 5 / Euro 5+ Combined
Flatbed short wheelbase / long wheelbase (F.C.*1470)157
Flatbed short wheelbase / long wheelbase (F.C.*
1700)167
Flatbed short wheelbase / long wheelbase (F.C.*
1930)185
*Flywheel class
