load capacity FIAT DOBLO COMBI 2017 2.G User Guide

Cargo 1.6 Multijet
Key
A. Unladen weight including driver (with all fluids, fuel tank 90% full and without optional equipment) - B. Maximum permitted
load - C. Payload including the driver - D. Payload excluding the driver - E. Towable loads (braked / non-braked trailer) -
F. Maximum load on roof - G. Maximum load on tow hitch (braked trailer).
Versions AB(*)C(**)D(**)E
F(***)G
Tot. Front Rear
Short wheelbase - Low roof-2front
seats1395 1890 1090 1140 570
495
(°)1300/500 100 60
1395 2100 1090 1140 780 705 1300/500 100 60
1465 2425 1200 1450 1035
960
(°°)1300/500 100 60
1485 2505 1150 1450 10951020
(^)1300/500 100 60
(*) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
(**) Values refer to minimum equipment level. If special equipment is fitted (fixed window, trailer towing device, etc.) the unladen weight will increase and
consequently the payload will decrease in relation to the maximum permitted loads.
(***) Including any installed roof carrier systems (Lineaccessori Fiat bars/box).
(°) Reduced payload
(°°) Extra capacity
(^) GVW 2505
238
TECHNICAL DATA

Versions AB(*)C(**)D(**)E
F(***)G
Tot. Front Rear
Short wheelbase - High roof-2front
seats1438 1933 1090 1140 570
495
(°)1300/500 - 60
1438 2143 1090 1140 780 705 1300/500 - 60
1475 2435 1200 1450 1035
960
(°°)1300/500 - 60
1505 2505 1150 1450 10751000
(^)1300/500 - 60
(*) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
(**) Values refer to minimum equipment level. If special equipment is fitted (fixed window, trailer towing device, etc.) the unladen weight will increase and
consequently the payload will decrease in relation to the maximum permitted loads.
(***) Including any installed roof carrier systems (Lineaccessori Fiat bars/box).
(°) Reduced payload
(°°) Extra capacity
(^) GVW 2505
239

Versions AB(*)C(**)D(**)E
F(***)G
Tot. Front Rear
Short wheelbase - Low roof-3front
seats1395 1890 1090 1140 570
495
(°)1300/500 100 60
1395 2100 1090 1140 780 705 1300/500 100 60
1465 2425 1200 1450 1035
960
(°°)1300/500 100 60
1485 2505 1200 1450 10951020
(^)1300/500 100 60
Short wheelbase - High roof-3front
seats1438 1933 1120 1140 570
495
(°)1300/500 - 60
1438 2143 1150 1140 780 705 1300/500 - 60
1475 2435 1200 1450 1035
960
(°°)1300/500 - 60
1505 2505 1200 1450 10751000
(^)1300/500 - 60
(*) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
(**) Values refer to minimum equipment level. If special equipment is fitted (fixed window, trailer towing device, etc.) the unladen weight will increase and
consequently the payload will decrease in relation to the maximum permitted loads.
(***) Including any installed roof carrier systems (Lineaccessori Fiat bars/box).
(°) Reduced payload
(°°) Extra capacity
(^) GVW 2505
241

Combi 1.6 Multijet
Key
A. Unladen weight including driver (with all fluids, fuel tank 90% full and without optional equipment) - B. Maximum permitted
load - C. Payload including the driver - D. Payload excluding the driver - E. Towable loads (braked / non-braked trailer) -
F. Maximum load on roof - G. Maximum load on tow hitch (braked trailer).
Versions AB(*)C(**)D(**)E
F(***)G
Tot. Front Rear
Short wheelbase - Low roof-2front
seats-3rearseats1505 2164 1090 1310 734 659 1300/500 100 60
1505 2254 1090 1310 824
749
(°°)1300/500 100 60
Long wheelbase - Low roof-2front
seats-3rearseats1600 2349 1200 1310 824 749 1300/500 100 60
Long wheelbase — High roof 1600 2349 1200 1310 809 734 1300/500 100 60
(*) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
(**) Values refer to minimum equipment level. If special equipment is fitted (fixed window, trailer towing device, etc.) the unladen weight will increase and
consequently the payload will decrease in relation to the maximum permitted loads.
(***) Including any installed roof carrier systems (Lineaccessori Fiat bars/box).
(°°) Extra capacity
243

Cargo 2.0 Multijet
Key
A. Unladen weight including driver (with all fluids, fuel tank 90% full and without optional equipment) - B. Maximum permitted
load - C. Payload including the driver - D. Payload excluding the driver - E. Towable loads (braked / non-braked trailer) -
F. Maximum load on roof - G. Maximum load on tow hitch (braked trailer).
Versions AB(*)C(**)D(**)E
F(***)G
Tot. Front Rear
Short wheelbase - Low roof-2front
seats1448 1943 1120 1140 570
495
(°)1500/500 100 60
1448 2153 1120 1140 780 705 1500/500 100 60
1475 2435 1200 1450 1035
960
(°°)1500/500 100 60
1535 2505 1200 1450 1045
970
(^)1500/500 100 60
(*) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
(**) Values refer to minimum equipment level. If special equipment is fitted (fixed window, trailer towing device, etc.) the unladen weight will increase and
consequently the payload will decrease in relation to the maximum permitted loads.
(***) Including any installed roof carrier systems (Lineaccessori Fiat bars/box).
(°) Reduced payload
(°°) Extra capacity
(^) GVW 2505
244
TECHNICAL DATA

Versions AB(*)C(**)D(**)E
F(***)G
Tot. Front Rear
Short wheelbase - High roof-2front
seats1465 1960 1120 1140 570
495
(°)1500/500 - 60
1465 2170 1120 1450 780 705 1500/500 - 60
1505 2465 1200 1450 1035
960
(°°)1500/500 - 60
1555 2505 1200 1450 1025
950
(^)1500/500 - 60
Long wheelbase - Low roof-2front
seats1505 2000 1120 1450 570
495
(°)1500/500 100 60
1505 2465 1200 1450 1035 960 1500/500 100 60
Long wheelbase - High roof-2front
seats1545 2040 1200 1450 570
495
(°)1500/500 - 60
1545 2505 1200 1450 1035 960 1500/500 - 60
(*) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
(**) Values refer to minimum equipment level. If special equipment is fitted (fixed window, trailer towing device, etc.) the unladen weight will increase and
consequently the payload will decrease in relation to the maximum permitted loads.
(***) Including any installed roof carrier systems (Lineaccessori Fiat bars/box).
(°) Reduced payload
(°°) Extra capacity
(^) GVW 2505
245

Versions AB(*)C(**)D(**)E
F(***)G
Tot. Front Rear
Short wheelbase - Low roof-3front
seats1448 1943 1120 1140 570
495
(°)1500/500 100 60
1448 2153 1120 1140 780 705 1500/500 100 60
1475 2435 1200 1450 1035
960
(°°)1500/500 100 60
1535 2505 1233 1450 1045
970
(^)1500/500 100 60
Short wheelbase - High roof-3front
seats1465 1960 1120 1140 570
495
(°)1500/500 - 60
1465 2170 1135 1450 780 705 1500/500 - 60
1505 2465 1200 1450 1035
960
(°°)1500/500 - 60
1555 2505 1233 1450 1025
950
(^)1500/500 - 60
Long wheelbase - Low roof-3front
seats1505 2000 1150 1450 570
495
(°)1500/500 100 60
1505 2465 1200 1450 1035 960 1500/500 100 60
Long wheelbase - High roof-3front
seats1545 2040 1200 1450 570
495
(°)1500/500 - 60
1545 2505 1233 1450 1035
960
(^)1500/500 - 60
(*) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
(**) Values refer to minimum equipment level. If special equipment is fitted (fixed window, trailer towing device, etc.) the unladen weight will increase and
consequently the payload will decrease in relation to the maximum permitted loads.
(***) Including any installed roof carrier systems (Lineaccessori Fiat bars/box).
(°) Reduced payload
(°°) Extra capacity
(^) GVW 2505
246
TECHNICAL DATA

Combi 2.0 Multijet
Key
A. Unladen weight including driver (with all fluids, fuel tank 90% full and without optional equipment) - B. Maximum permitted
load - C. Payload including the driver - D. Payload excluding the driver - E. Towable loads (braked / non-braked trailer) -
F. Maximum load on roof - G. Maximum load on tow hitch (braked trailer).
Versions AB(*)C(**)D(**)E
F(***)G
Tot. Front Rear
Short wheelbase - Low roof-2front
seats-3rearseats1511 2170 1135 1450 734 659 1500/500 100 60
1605 2354 1150 1450 824
749
(°°)1500/500 100 60
Long wheelbase - Low roof-2front
seats-3rearseats1615 2364 1200 1450 824 749 1500/500 100 60
Long wheelbase - High roof-2front
seats-3rearseats1675 2424 1200 1450 824 749 1500/500 - 60
(*) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
(**) Values refer to minimum equipment level. If special equipment is fitted (fixed window, trailer towing device, etc.) the unladen weight will increase and
consequently the payload will decrease in relation to the maximum permitted loads.
(***) Including any installed roof carrier systems (Lineaccessori Fiat bars/box).
(°°) Extra capacity
247
