FIAT DUCATO 2008 3.G Owners Manual

Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering - Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print n. 603.81.357 - 11/2008 - 4thedition
ENGINE OIL CHANGE
100 Multijet - 120 Multijet - 130 Multijet - 160 Multijet
Tank capacity90 (*)
Reserve10 / 12
Refuel diesel engines with diesel fuel for motor vehicles only (EN 590 Specifications)
(*) For all versions it is possible to request 120 litre tank.
On “Free time” versions it is possible to request 60 litre tank
FUEL CAPACITIES (litres) COLD TYRE PRESSURE (bar)
100 Multijet 120 Multijet 130 Multijet 160 Multijet
litres litres litres litres
Engine sump and filter 6.38 6.5 6.5 7.0
Tyres Use Front Rear
215/70 R15
215/70 R15
225/70 R15
225/70 R15 C
225/70 R15
215/70 R15 CP
215/75 R16
225/75 R16
225/75 R16 C
225/75 R16 CP
(*) Total weight on ground
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres..3000 PTT(*) Light with standard tyres, PANORAMA excluded
3300 PTT(*) Light / 3500 PTT(*) Light with standard tyres
PANORAMA with standard tyres
3000 PTT(*) Light with oversize tyres, PANORAMA excluded
3300 PTT(*) Light / 3500 PTT(*) Light with oversize tyres
Winter tyres M+S class C on Camping vehicle
PANORAMA with oversize tyres
Light range with Camping tyres
Heavy range with standard tyres
Heavy range with oversize tyres
Winter tyres M+S class C on Camping vehicle
Heavy range with Camping tyres 4.0 ± 0.05 4.0 ± 0.05
4.1 ± 0.05 4.5 ± 0.05
4.1 ± 0.05 4.5 ± 0.05
4.0 ± 0.05 4.0 ± 0.05
4.1 ± 0.05 4.5 ± 0.05
4.3 ± 0.05 4.75 ± 0.05
4.1 ± 0.05 4.5 ± 0.05
5.0 ± 0.05 5.5 ± 0.05
4.5 ± 0.05 5.0 ± 0.05
4.5 ± 0.05 5.0 ± 0.05
5.2 ± 0.05 5.2 ± 0.05
5.5 ± 0.05 5.5 ± 0.05
