FIAT DUCATO 250 2007 3.G Comfort Matic Manual

10
WARNING LIGHTS
AND MESSAGESREDUCE GEAR CHANGES
The message appears on the display to in-
dicate that the driver is using the gearbox
incorrectly.
Incorrect use (by the driver) could auto-
matically activate a procedure for pro-
tecting the system.MANUAL MODE NOT
AVAILABLE
The message appears on the multifunc-
tion display when it is not possible to se-
lect MANUALmode with the engine
running. “COMFORT-MATIC”
GEARBOX FAULT (red)
When the ignition key is
turned to MAR, the warning
light turns on and should go off after a few
seconds.
The warning light on the dial comes on ei-
ther steady or blinking (together with a
message on the multifunction display and
a buzzer) to indicate that the gearbox is
faulty.
t
If a fault is present, contact
a Fiat Dealership as soon as
possible to check the sys-
tem.
Contact a Fiat Dealership if
the message remains on the
display.
Contact a Fiat Dealership if
the message remains on the
multifunction display.

11
AUTOMATIC MODE
NOT AVAILABLE
The message appears on the multifunction
display when it is not possible to select
AUTOmode with the engine running.CLUTCH OVERHEATING
The message appears on the multifunction
display together with a buzzer when the
clutch overheats.
In this situation, limit take-off and gear
shifts or if necessary park (turning off the
engine) until conditions are optimum.PRESS BRAKE PEDAL -
DELAYED START-UP
The multifunction display shows these
messages alternately and in sequence to-
gether with an warning buzzer when the
system does not recognise the brake ped-
al to be operational during a starting at-
tempt.
In this situation, keep the key on AVVfor
at least 7 seconds with the brake pressed:
the engine start. The system will be in re-
covery mode (maximum speed permitted:
3
rd).
IMPORTANT Messages are displayed on-
ly if start-up takes place in a gear other
than neutral (N). Contact a Fiat Dealership if
the message remains on the
multifunction display.
If the message still appears on
the multifunction display,
contact a Fiat Dealership.
To safeguard clutch efficien-
cy, do not use the accelerator
to keep the vehicle at a stand-
still (e.g.: parking on a hill);
the clutch could be damaged by over-
heating. Use the brake pedal instead
and operate the accelerator only when
you are ready to set off;
Contact a Fiat Dealership if
the messages remain on the
multifunction display.

12
GEAR NOT AVAILABLE
This message appears on the multifunction
display together with a warning buzzer in
the following cases:
❒when it is not possible to change gear
due to a fault in the system;
or
❒when, due a fault in the system, is is on-
ly possible to engage 1st(1), 2nd(2), 3rd
(3) or reverse (R).MANOEUVRE NOT PERMITTED
The message appears on the multifunction
display together with a warning buzzer
when the system will not accept a gear
change via the control lever because cer-
tain conditions required for acceptance of
the gear change are missing.
PRESS BRAKE PEDAL
AND REPEAT MANOEUVRE
The message appears on the multifunction
display accompanied, in some cases, by a
warning buzzer for safety reasons if you
attempt to change gear with the vehicle
parked without previously pressing the
brake pedal.PLACE GEAR LEVER IN N
(neutral)
This message appears on the multifunction
display together with a warning buzzer
when the system asks the driver to per-
form the manoeuvre.
When the gearbox is shifted to (N) the
message on the display should go off.
Contact a Fiat Dealership if
the message remains on the
multifunction display.Contact a Fiat Dealership if
the message remains on the
multifunction display.
Contact a Fiat Dealership if
the message remains on the
multifunction display.

13
TOWING THE VEHICLE
Ensure the gearbox is in neutral (N) (by
checking that the vehicle moves when
pushed) and tow in the same way as a nor-
mal vehicle with a manual gearbox (see in-
structions in Owner Handbook).
If it is not possible to put the gearbox in
neutral, do not tow the vehicle and con-
tact a Fiat Dealership.
IF A FUSE BLOWS
For the location of fuses, see the illustrations in the paragraph “if a fuse blows” in the
“In an emergency” section of the Owner Handbook.
FUSE AMPS
COMFORT-MATIC gear control system and gear selector lever (power supply + ignition) F24 7.5
COMFORT-MATIC gearbox pump F26 30
COMFORT-MATIC gearbox control unit
(power supply + battery) F27 10

14
CHECKING FLUID LEVELS
COMFORT-MATIC GEARBOX HYDRAULIC OPERATING SYSTEM FLUID
To check the gear oil and check/replace the hydraulic clutch operating system fluid, contact only a Fiat dealership.
AIR CLEANER
Have the air cleaner replaced by a Fiat Dealership.
Used gear oil contains substances that are hazardous for the environment. It is ad-
visable to have oil changed by a Fiat Dealership where used oil will be disposed of
according to the law.WARNING
SCHEDULED SERVICING PLAN
Check gearbox every
oil level 45,000 km
Check fluid in hydraulic every
clutch operation system 45,000 km
Check fluid in hydraulic every
clutch operation system 90,000 km (or every 2 years)

15
ENGINE CODES - BODYWORK VERSIONS
Version Engine code
100 Multijet4HV
120 MultijetSOFIM F1AE0481D
130 MultijetSOFIM F1AE0481N
160 MultijetSOFIM F1CE0481D
The following body version code and key is an example that may be applied to all
body version codes :
Key: 250 A A M F A AX
MODEL
PAYLOAD
ENGINE
ENGINE TRANSMISSION/AXLES
BODYWORK
WHEELBASE
VERSION
PAYLOAD
A3000 kg
B3300 kg
C3500 kg LIGHT
D3500 kg HEAVY
E4005 kg
ENGINES
A100 Multijet
C120 Multijet
D160 Multijet
E130 Multijet
TRASMISSION
MManual gearbox
AAutomatic gearbox
BODYWORK
AChassis cab
BChassis without cab
CLow loader with cab
DBox
EPrimary school bus
LMiddle school bus
FVan
WHEELBASE
AShort wheelbase
BMedium wheelbase
CLong wheelbase
DMedium-long wheelbase
GBox with long cab
HChassis with long cab
MMinibus
PPanorama
R6/9 seater crew cab
UChassis without low loader
drive cab

16
TRASMISSION
Six speeds plus reverse
Gearbox with electronically-controlled
hydraulic system
ClutchSingle dry plate with hydraulic engagement
Drive Front
PERFORMANCE
For top speeds, see “Performance” in the “Technical Data” section of the Owner Handbook.

17
Specified fuels
Recommended products
TUTELA CAR CS SPEED -
Specific fluid with“ATF DEXRON
III” additive
TUTELA TOP4
Synthetic fluid FMVSS n° 116 DOT
4, ISO 4925 SAE JI704, CUNA NC
956-01
CAPACITIES
COMFORT-MATIC
gearbox hydraulic operating system
Clutch hydraulic operating system
litres
0.7
0.050kg
0.59
–

18
FUEL CONSUMPTION AND CO2EMISSIONS
Fuel consumption according to Directive 1999/100/EC (litres x 100 km)
CO
2emissions according to 1999/100/CE Directive (g/km).
Payload Fuel consumption CO2emissions
Urban Extraurban Combined Combined
Short wheelbase Ducato 9.2 6.9 7.7 204
Medium wheelbase Ducato 9.6 7.2 8.1 213
Ducato MAXI 10.0 7.6 8.5 224 Combi versions (*)
Payload Fuel consumption CO2emissions
Urban Extraurban Combined Combined
Ducato all types 10.0 7.6 8.5 224 Panorama versions (*)

19
Payload Fuel consumption CO2emissions
Urban Extraurban Combined Combined
Ducato: Van CH1-MH1/Truck CH1
MH1-MLH1-LH1 – Chassis cabs 10.3 7.7 8.7 229
and without drive cabs(**)
Ducato: Van MH2-LH2-LH3/
Truck XLH1-Crew cab MH1-LH1
10.6 8.0 9.0 237
Chassis cabs and without
drive cab (**)
Ducato MAXI: Truck MH1 – Chassis
10.5 7.9 8.9 233
chassis cabs and without drive cab (**)
Ducato MAXI: Van MH1-MH2
LH2-LH3/Truck MLH1-LH1-XLH1
10.9 8.2 9.2 242
Crew cab MH1-LH1 – Chassis
cabs and without drive cabs (**)
Ducato MAXI: Van XLH2-XLH3/
Crew cab truck XLH1 – Chassis 10.9 8.2 9.2 242
cabs and without drive cabs (**)
(*) Fuel consumption figures recorded in AUTO mode
(**) Fuel consumption figures apply to pre-conversion vehicles Goods transport versions (*)
