IMPORTANT The remote control system frequency can be disturbed by
significant radio transmissions outside the car (e.g: mobile phones, HAM
radio systems, etc.) that could cause remote control malfunctioning.
Opening the doors and the tailgate
Pressing and keeping the pushbutton pressed
Ë: for a short time: remote
unlocking of doors, boot lid, unlocking of fuel lid, timed switching on of
inner roof lamp and double blinking.
Doors will be unlocked automatically if the fuel inertial cut-off switch
comes into operation.
Use the “Set-up menu” of the reconfigurable multifunction display (see
the relevant paragraph in section “Dashboard and controls”) to set the
system so that when pressing button
Ëonly the driver’s door will open.
IMPORTANT The remote control system frequency can be disturbed by
significant radio transmissions outside the car (e.g: mobile phones, HAM
radio systems, etc.) that could cause remote control malfunctioning.
Closing the doors and the tailgate
Pressing and keeping the pushbutton pressed
Á: ffor a short time: remote
locking of doors, boot lid, locking of fuel lid, switching off of inner roof
lamp and single blinking.
Press the button twice quickly to activate the dead lock device (see
paragraph “Dead lock device”) (where provided).
Deterrence led
When locking the doors, the led on button (A) switches on for about 3 seconds and than starts flashing (deterrence
function). Once doors are locked, if one or more doors or the tailgate are not closed correctly, the led and
direction indicators will start flashing quickly.
IMPORTANT The remote control system frequency can be disturbed by significant radio transmissions outside the
car (e.g: mobile phones, HAM radio systems, etc.) that could cause remote control malfunctioning.
9
