F0H0203m
JACKING THE CAR
If the car is to be lifted, go to a Fiat Dealership which is equipped with
the arm hoist or workshop lift.
Jack up the car only by positioning the jack arms or the shop jack in the
points shown in the figures.
TOWING THE CAR
The car is delivered with two tow rings: the short tow ring shall be fitted
at the front and the long one at the back.
Tow rings are arranged in tool container.
Side figures show how rear (long) ring was arranged, within spare wheel
and in the container of kit Fix & Go automatic, respectively.
F0H0342m
F0H0361m
