engine FIAT IDEA 2009 1.G Dualogic Transmission Manual

15
ENGINE CODES - BODYWORK VERSIONS
Versions Engine type code Bodywork code
1.4 16V 95 HP843A1000350AXA11 04G - Euro 5 (❑)350AXA11 04H - Euro 5 (❍)
1.3 Multijet 70 HP188A9000350AXB11 05H (❑)350AXB11 05L (❍)
350AXG11 10N (❑)
1.3 Multijet 90 HP199A3000 350AXG11 10P (❍)
350BXG11 CX (*) (❍)
1.3 Multijet 95 HP199B1000 350AXM11 14(❑)
(❑) 5 seater
(❍) 4 seater
(*) VAN version
PERFORMANCE
The top speed after running in is 175 km/h with the 1.4 16V95 HP engine.
The top speed after running in is 159 km/h with the 1.3 Multijet 70 HP engine.
The top speed after running in is 173 km/h with the 1.3 Multijet 90 HP engine.
The top speed after running in is 175 km/h with the 1.3 Multijet 95 HP engine.
603_97_015 IDEA DUAL GB 1e 4-02-2009 16:25 Pagina 15

18
CO2emissions in accordance with directive 2004/3/EC (gr x 100 km)
The CO
2emission value, with reference to combined consumption equivalent to 136 (gr x 100 km) with 1.4 16V95 HP engine.
The CO
2emission value, with reference to combined consumption equivalent to 121 (gr x 100 km) with 1.3 Multijet 70 HP engine.
The CO
2emission value, with reference to combined consumption equivalent to 118 (gr x 100 km) with 1.3 Multijet 90 HP engine.
The CO
2emission value, with reference to combined consumption equivalent to 115 (gr x 100 km) with 1.3 Multijet 95 HP engine.
CO2EMISSIONS
CAPACITIES
Dualogic gearbox hydraulic
activation system
1.3 Multijet 70 HP
1.3 Multijet 90 HP - 1.3 Multijet 95 HP 1.4 16V 95 HP
litres
0.70kg
0.59litres
0.70kg
0.59 Recommended fuels
Recommended products
TUTELA CAR CS SPEED -
Special oil with
“ATF DEXRON III” additive
603_97_015 IDEA DUAL GB 1e 4-02-2009 16:25 Pagina 18

Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print n° 603.97.015 - 02/2009 - 1
stEdition
