USB FIAT LINEA 2007 1.G Blue And Me User Manual

The innovating Windows Mobile™-based Telematic
Solution for the car
CONTENTS
OVERVIEW ................................................................................ 3
The hands-free kit ...................................................................... 3
Message reader ........................................................................... 5
Media player ............................................................................... 6
Road safety ................................................................................. 7
DISPLAY AND BUTTONS ON THE STEERING
WHEEL ......................................................................................... 8
HANDS-FREE KIT QUICK REFERENCE GUIDE ............. 10
Prepare your mobile phone phonebook ............................ 10
Try out the voice commands ................................................. 11
Pair your mobile phone ........................................................... 11
Make a phone call ..................................................................... 12
MESSAGE READER QUICK REFERENCE GUIDE............. 13
MEDIA PLAYER QUICK REFERENCE GUIDE ................ 13
HOW TO USE Blue&Me™ ................................................. 14
Steering wheel controls .......................................................... 14
Voice commands ....................................................................... 14
Display ......................................................................................... 17Audio ........................................................................................... 17
Blue&Me™ function menu .................................................. 17
HANDS-FREE KIT FUNCTIONS .......................................... 18
Making a phone call .................................................................. 19
Incoming calls ............................................................................. 22
Managing phone calls ................................................................ 23
Conference call function ......................................................... 23
MESSAGE READER FUNCTIONS ........................................ 24
How to read the last SMS text received.............................. 24
Inbox ............................................................................................. 25
Managing messages .................................................................... 25
Deleting all messages................................................................. 26
Signal types................................................................................... 26
MEDIA PLAYER FUNCTIONS ............................................. 27
How to connect the USB device to Blue&Me™ ............ 27
How to manage the media library ........................................ 27
- Selection by folder ................................................................. 28
- Selection by artist .................................................................. 29
- Selection by genre .................................................................. 29
- Selection by album ................................................................. 30
- Selection by playlist ............................................................... 30

Playing audio tracks .................................................................. 31
- Shuffle playback of the whole media library...................... 31
- Now playing (track data) ...................................................... 31
- Audio play ................................................................................ 31
- Pause ......................................................................................... 31
- Play ............................................................................................. 31
- Stop ........................................................................................... 32
- Next track ............................................................................... 32
- Previous track ......................................................................... 32
- Changing audio source ......................................................... 32
Practical hints for using the media player ............................ 32
- Scrolling .................................................................................... 32
- Organizing media files ........................................................... 33
- Building the media library on Blue&Me™ .................... 33
- Building playlists for Blue&Me™ ..................................... 33
SETTINGS FUNCTIONS......................................................... 34
Pairing a mobile phone ............................................................ 34
Managing user data ................................................................... 37
Managing updates ...................................................................... 40
- Updating Blue&Me™ ......................................................... 40
- Pausing the update ................................................................. 41
- Using the phone during the updating procedure ........... 42
- Resuming the update ............................................................. 42
Advanced options ..................................................................... 43
- Accessing the device ID......................................................... 43
- Changing the GPRS code ..................................................... 43
Media player settings ................................................................ 44
- Autoplay ................................................................................... 44
- Shuffle ........................................................................................ 45
- Loop .......................................................................................... 45
Exit the settings menu ............................................................. 46Blue&Me™ SUPPORTED MOBILE PHONES ................ 46
Mobile phones with Bluetooth®wireless technology...... 46
- “Pull” phones
(phonebook automatically downloaded) .......................... 47
- “Push” phones
(phonebook not automatically downloaded) .................. 47
- Mobile phones with message reader .................................. 47
- List of Blue&Me™ supported mobile phones ............. 48
Supported USB memory devices .......................................... 50
- USB memory devices ............................................................ 50
- Supported digital audio files ................................................ 50
- Supported playlist formats .................................................... 51
VOICE COMMANDS (KEYWORDS) - SUMMARY ....... 52
Always available voice commands.......................................... 52
Hands-free phone kit voice commands ................................ 53
Message reader voice commands ......................................... 55
Media player voice commands................................................ 56
Settings function voice commands......................................... 59
TROUBLESHOOTING ............................................................ 60
Hands-free kit ............................................................................ 60
- General - display screen ....................................................... 60
- Phone-specific: Audiovox
®/Orange®.................................. 67
- Phone-specific: Motorola®.................................................... 68
- Phone-specific: Nokia®.......................................................... 70
- Phone-specific: Sony-Ericsson®........................................... 73
Message reader ........................................................................... 75
Media player ................................................................................ 77
PERSONAL DATA PROTECTION ..................................... 81
SYSTEM SOFTWARE USE NOTICE .................................. 82

3
With this system you can also play your
favourite music stored on USB device and
select tracks and playback modes with
both voice commands or buttons on the
steering wheel.
THE HANDS-FREE KIT
The basic characteristic of this hands-free
kit is voice recognition with Bluetooth
®
wireless technology. With this system you
can make and receive calls safely and se-
curely using either voice commands or
buttons on the steering wheel under what-
ever driving condition without having to
take your eyes off the road or removing
your hands from the steering wheel, as re-
quired by current law regulations.
Bluetooth
®wireless technology enables
wireless connection between your mobile
phone and the hands-free kit installed on
your car. To use the hands-free kit, you need a
Bluetooth
®wireless technology enabled
mobile phone. This hands-free kit gives
you the possibility of interacting vocally
with your mobile phone while driving,
even if your mobile device does not fea-
ture this capability. You can also interact
with your mobile phone manually and vi-
sually using the steering wheel controls
and the instrument panel multifunction dis-
play.
For further details on the mobile phones
supported by Blue&Me™, refer to sec-
tion Blue&Me™SUPPORTED MOBILE
PHONES.
To get started with Blue&Me™hands-
free kit with voice recognition, you have
to simply pair your Bluetooth
®wireless
technology enabled mobile phone with the
system.
Pairing is an operation that has to be made
only once.
Hands-free kit with Bluetooth®wireless technology,
message reader and media player
OVERVIEW
Windows Mobile™-based Fiat Blue&Me™
is a personal telematic system enabling to
use communication and entertainment ap-
plications expressly designed for use in the
car.
The Blue&Me™system installed on your
car is equipped with hands-free kit, mes-
sage reader and media player, and it is pre-
set for future installation of additional ser-
vices.
The Blue&Me™system, fully integral
with voice commands, buttons on the
steering wheel and multifunction display
messages, gives you the possibility of in-
teracting with your Bluetooth
®wireless
technology mobile phone (even if you
keep it in your pocket or bag) without hav-
ing to take your eyes off the road or re-
moving your hands from the steering
wheel. To use voice commands you are
not required to train the voice recognition
system to recognize your voice. This im-
plies that the system is nearly equally per-
forming with different persons, i.e.: the
voice recognition system is of the “speak-
er independent” type.

6
MEDIA PLAYER
With the Blue&Me™media player you
can play, via the car sound system, the dig-
ital audio files stored on a USB device by
simply connecting it to the USB port lo-
cated in the car.
In this way, while you are driving you can
play your favourite personal music collec-
tions.
The media player enables the following op-
erations:
❒Digital audio playback- you can play
all your digital audio files (.mp3, .wma,
.wav) or play a customized playlist (.m3u
or .wplformat).
❒Audio file selection by category-
you can play all audio files of a certain
category, e.g.: album, artist or genre.
❒Playback options- while playing tracks
you can select the following options: Play,
Stop, Next track, Previous track, Shuffle and
Loop track.
Note
The media player does not support audio
files compressed with other formats (e.g.:
.aac) and DRM (Digital Right Management)
protected audio files. Non-supported au-
dio files that may be present on the USB
device will be ignored.To use the media player, you have to sim-
ply connect (directly or by an extension
lead) your USB device to the car USB
port. Turning the ignition key to MAR,
Blue&Me™will start building your me-
dia library. At the end of this operation
you can surf the whole library and scroll
its categories as required using the but-
tons on the steering wheel or voice com-
mands. Blue&Me™will then play your
selection via the car sound system.

8
DISPLAY AND BUTTONS ON THE STEERING WHEEL
In this manual, the descriptions of the menu entries refer to the multifunctional display, which visualises some entries
in abbreviated form compared to the version with reconfigurable multifunctional display.
The reconfigurable multifunctional display visualises the menu entries in full.
fig. 1F0R2000g
USB port Multifunction display Reconfigurable multifunction display

13
MESSAGE READER
QUICK REFERENCE
GUIDE
If your mobile phone with Bluetooth®
wireless technology supports the message
reader function, at the arrival of a new
SMS text, Blue&Me™plays a tone and it
will ask if you would like to read it.
❒pronounce “Yes” or press ß/MAIN
or SRC/OKto read the last message
received
❒pronounce “No” or press &/ESC, the
system will store the message so you
can read it later
For further details on the message read-
er SMS, refer to section “MESSAGE
READER FUNCTIONS”.

If you encounter difficulties with any of
the message reader settings, consult sec-
tion “MESSAGE READER – TROU-
BLESHOOTING”
MEDIA PLAYER QUICK
REFERENCE GUIDE
To start playing the digital audio files
stored on your USB device, proceed as
follows:
❒Copy tracks to your USB device
(Blue&Me™recognizes .wma, .mp3
and .wavformats for audio files and .wpl
and .m3uformats for playlists).
❒USB devices without USB wire: just
connect the USB device (directly or by
an extension lead) to the USB port on
the car (see fig. 1).
❒USB devices with USB wire: use the
wire to connect the USB device to the
USB port on the car (see fig. 1).
❒Turn the ignition key to MAR.
Blue&Me™will start automatically to
play your digital tracks selecting them
from the library built at the moment the
USB device is connected.
❒After Blue&Me™has built the library
containing your digital audio files, you can
select and play tracks, albums, artists and
playlists by interacting manually or ver-
bally with Blue&Me™. Building the li-
brary may require a few minutes if your
USB device contains several files.

14
❒You can also decide whether to play au-
dio files automatically when connecting
the USB device or to play them upon
your command.
For further details on media player, refer
to section MEDIA PLAYER FUNCTIONS.

If you encounter difficulties with any of
the voice recognition operations, consult
section MEDIA PLAYER - TROU-
BLESHOOTING.
HOW TO USE
Blue&Me™
CONTROLS STEERING WHEEL
Buttons on the steering wheel (see fig. 1)
are used to perform functions on the
hands-free kit, activating voice recognition,
using the media player functions or select-
ing a Blue&Me™menu option.
Certain buttons have multiple functions
which depend on the current state of the
system.
The function chosen in response to a key
press is in some cases controlled by the
duration of the key press (short or long).

DISPLAY AND BUTTONS ON THE
STEERING WHEEL.
Note
Instructions concerning manual controls
are identified in the text by symbol
?.VOICE COMMANDS
Voice commands can be pronounced by
the driver, which does not need to change
his/her normal driving position to be heard
by the system, since the microphone is
properly located and oriented to this pur-
pose.
Voice commands, which are words rec-
ognized by the system, are identified as
“keywords”.
The hands-free phone system recognizes
and responds to a preset list of voice com-
mands. The list of available voice com-
mands depends on the keyword level that
you are currently on. The current list is al-
ways available by pressing
‘and pro-
nouncing “Help” or, pronouncing “Help”
after whichever question of the system.
Blue&Me™also recognizes personalized
versions of voice commands like the name
of a contact in your phonebook.
There is no voice training required for us-
ing voice commands with this system.

27
❒USB devices with USB wire: use the
wire to connect the USB device to the
USB port on the car (see fig. 1).
❒Turn the ignition key to MAR.
Blue&Me™will start automatically to
play your digital tracks selecting them
from the library built at the moment
the USB device is connected.
❒If AUTOPLAYis set to“ON”,
Blue&Me™will start playback auto-
matically.

SETTINGS FUNCTION - MEDIA
PLAYER.
When building the media library is over, it
will be possible to use Blue&Me™to to
select and play tracks.
MEDIA PLAYER
FUNCTIONS
The MEDIA PLAYERmenu enables the
following:
❒to display tracks stored on your USB
device
❒to play audio files stored on your USB
device.
Note
Before starting to use your media player,
read section SUPPORTED USB MEMO-
RY DEVICES to make sure your USB
memory device is supported by
Blue&Me™.
HOW TO CONNECT THE USB
DEVICE TO Blue&Me™
To connect your USB device to
Blue&Me™, proceed as follows:
❒Copy tracks on your USB device
(Blue&Me™recognizes .wma, .mp3
and .wavformats for audio files and .wpl
and .m3ufor playlists).
❒USB devices without USB wire: just
connect the USB device (directly or by
an extension lead) to the USB port on
the car (see fig. 1).HOW TO MANAGE
THE MEDIA LIBRARY
With the media player you can select the
audio files stored on your USB device, us-
ing voice commands or steering wheel
buttons.
You can scroll audio files by folder, artist,
genre, album or playlist and then select the
required category using voice commands.
After selecting the required category, se-
lect the required file using manual con-
trols.
Enter track data (e.g.: title, artist, album,
genre) for surfing your media library
friendly.

28
Note
Not all formats require to enter media in-
fo. Formats .mp3and .wmarecognized by
Blue&Me™require media info where-
as .wavnot. If no media info is entered, au-
dio files can only be selected by folder.
For further details, refer to section PRAC-
TICAL HINTS FOR USING THE MEDIA
PLAYER.Selection by folder
Track folders on your USB device are dis-
played in the FOLDERSmenu.
?
To select tracks through manual in-
teraction, proceed as follows:
Launch the Main Menu and select
MEDIA PLAYER, then press
SRC/OKor
ß/MAIN.
Select FOLDERS, then press
SRC/OKor
ß/MAIN.
Scroll folders. To play all folders, se-
lect PLAY ALLand then press
SRC/OKor
ß/MAIN. To display
folder tracks, press SRC/OKor
ß/MAIN.
Scroll the selected folder tracks.
To play the required track, select
the title and then press SRC/OKor
ß/MAIN.
}
Or, using voice interaction:
Press
‘and pronounce “Fold-
ers”.
Scroll folders. To play all folder, se-
lect PLAY ALLand then press
SRC/OKor
ß/MAIN. To display
folder tracks, press SRC/OKor
ß/MAIN.
Scroll the selected folder tracks. To
play the required track, select the ti-
tle and then press SRC/OKor
ß/MAIN.
For further details on FOLDERS,
menu customization, see section
PRACTICAL HINTS FOR USING
THE MEDIA PLAYER.

29
Selection by artist
?
To select the tracks of a special
artist using manual interaction, pro-
ceed as follows:
Launch the Main Menu, select ME-
DIA PLAYER, and then press
SRC/OKor
ß/MAIN.
Select ARTISTSand then press
SRC/OKor
ß/MAIN.
Scroll artists. To select the required
artist, press SRC/OKor
ß/MAIN.
Scroll the artist’s albums. To play all
the albums of the required artist, se-
lect PLAY ALLand press
SRC/OKor
ß/MAIN.
To play an album, select the re-
quired album and then press
SRC/OKor
ß/MAIN.
To play a track, select the title and
then press SRC/OKor
ß/MAIN.
}
Or, using voice interaction:
Press
‘and pronounce “Artists”.
Scroll the artist’s albums. To play all
the albums of the required artist, se-
lect PLAY ALLand then press
SRC/OKor
ß/MAIN. To play an
album, select the required album
and then press SRC/OKor
ß/MAIN.
To play a track, select the title and
then press SRC/OKor
ß/MAIN.
Note
If your USB device contains many audio
files, the ARTISTSmenu can be subdi-
vided into alphabetical sub-menus. Alpha-
betical sub-menu can display just the first
letter of the tracks it contains (e.g.: A-F),
or it can display the first two letters (e.g.:
Aa-Ar).Selection by genre
?
To select the tracks of a special
genre using manual interaction, pro-
ceed as follows:
Launch the Main Menu, select ME-
DIA PLAYER, and then press
SRC/OKor
ß/MAIN.
Select GENRESand then press
SRC/OKor
ß/MAIN.
Scroll genres. To play all the tracks
of the displayed genre, press
SRC/OKor
ß/MAIN.
}
Or, using voice interaction:
Press
‘and pronounce “Genres”.
Scroll genres. To play all the tracks
of the displayed genre, press
SRC/OKor
ß/MAIN.
Note
If your USB device contains many audio
files, the GENRESmenu can be subdivid-
ed into alphabetical sub-menus. Alphabet-
ical sub-menu can display just the first let-
ter of the tracks it contains (e.g.: A-F), or
it can display the first two letters (e.g.: Aa-
Ar).
