NOTE Carefully clean the cap of reservoir
Aand the surrounding surface.
When opening the cap, make sure that no
dirt gets into the reservoir.
For topping up always use a funnel with
built in filter (mesh smaller than or equal
to 0.12 mm).
IMPORTANT Brake fluid absorbs mois-
ture. For this reason, if the car is mainly
used in areas with a high degree of at-
mospheric humidity, the fluid should be
replaced at more frequent intervals than
specified in the “Service schedule”. Check level through the reservoir.
fig. 7F0R0138m
Do not travel with the wind-
screen washing reservoir
empty: the windscreen washer is fun-
damental to improve visibility.
WARNING
Some commercial wind-
screen washer additives are
flammable. The engine compartment
contains hot parts which could start
a fire if they come into contact.
WARNING
Prevent brake fluid which is
highly corrosive from coming
into contact with painted
parts. Wash with water im-
mediately if this should happen.
Brake fluid is poisonous and
highly corrosive. In the case
of accidental contact, wash the parts
with water and mild soap and rinse
with plenty of water. Call a doctor
immediately if swallowed.
WARNING
Symbol πon the contain in-
dicates a synthetic brake flu-
id, which is different from a mineral
fluid. Use of a mineral type fluid will
damage the special rubber seals of
the braking system beyond repair.
WARNING
BRAKE FLUID fig. 7
Release cap A: check that the liquid con-
tained in the tank is at the maximum level.
Fluid level in the reservoir must not ex-
ceed the MAXmark.
Use the brake fluid shown in the “Fluids
and lubricants” table (see “Technical Spec-
ifications”).

189
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCEOil consumption is extremely
low; if another top-up should
be required after only a short
period of time, have the system checked
for leakage at a Fiat Dealership.
BATTERY
The car fits a low-maintenance battery: no
top-ups with distilled water are needed in
normal conditions of use.
CHECKING THE CHARGE fig. 9
Use the gauge A (where provided) on the
battery lid positioned as shown in fig. 9and
take action according to the colour it as-
sumes.
Refer to the table below. POWER STEERING FLUID fig. 8
Check that the oil level with the car on flat
ground and the engine cold is between the
MINand MAXlines on the reservoir
body. The level may go over the MAX
line when the oil is hot.
If topping up is required, make sure the oil
you used has the same specifications as
that already in the system.
AIR CLEANER
Have the air cleaner replaced by a Fiat
Dealership.
POLLEN FILTER
Have the pollen filter replaced by a Fiat
Dealership.
Prevent power steering flu-
id from coming into contact
with hot engine parts: the liquid is
flammable.
WARNING
fig. 8F0R0139m
Brilliant whiteTop-up Go to a Fiat Dealership
Dark without greenLow charge Recharge the battery
area in the middle(go to a Fiat Dealership)
Dark with green Electrolyte and charge OK No action needed
area in the middle

191
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
The total intake of these systems (facto-
ry and after-market) must be less than 0.6
mA x Ah (of the battery) as shown in the
following table:
Battery Maximum
permissible
loadless
consumption
40 Ah 24 mA
50 Ah 30 mA
60 Ah 36 mA
IMPORTANT A battery which is kept at
a charge of less than 50% (optical indica-
tor with dark colour without green area
in the middle) for any length of time will
be damaged by sulphation leading to a re-
duction in cranking power.
The battery will also be more at risk of
freezing (e.g. already at -10°C). Refer to
the paragraph “Car inactivity” in “Starting
and driving” if the car is left parked for a
long time.
If after buying the car, you want to install
electric accessories which require per-
manent electric supply (alarm, etc.) con-
tact Fiat Dealership whose qualified per-
sonnel, in addition to suggesting the most
suitable devices, will evaluate the overall
electric absorption, checking whether the
car’s electric system is capable of with-
standing the load required, or whether it
should be integrated with a more power-
ful battery.
Since these devices continue absorbing en-
ergy even when the ignition key is off, they
gradually run down the battery. USEFUL ADVICE FOR
LENGTHENING THE LIFE OF
YOUR BATTERY
To avoid draining your battery and length-
en its life, observe the following indica-
tions:
❒when you park the car, ensure the
doors, tailgate and bonnet are closed
properly;
❒switch off all lights inside the car: the
car is however equipped with a system
which switches all internal lights off au-
tomatically;
❒do not keep accessories (e.g. sound sys-
tem, hazard lights, etc.) switched on for
a long time when the engine is not run-
ning;
❒before performing any operation on the
electrical system, disconnect the bat-
tery negative cable;
❒make sure that battery terminals are al-
ways be perfectly tight.
Always wear the proper pro-
tective eyewear when work-
ing on the battery or near it.
WARNING

218
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
Bonnet .................................................. 88
Boot ........................................................ 86
– extension........................................ 87
– opening/closing the tailgate ......... 86
– emergency opening....................... 83
Boot light............................................... 74
Brake assist .......................................... 92
Brakes
– fluid level ........................................ 188
– technical data ................................ 205
Bulb (replacement)
– general instructions ..................... 158
– types of bulbs ................................ 158
Capacities ............................................ 106
Car inactivity ....................................... 132
Car maintenance
– periodical checks........................... 183
– scheduled servicing ...................... 178
– service schedule ..................179-181
– use of the car under
heavy conditions............................ 183
Card box - CD box............................. 72
Carrying children safely ..................... 109
Ceiling lights.......................................... 72
– boot light ....................................... 66
– courtesy ......................................... 66– front ................................................ 64
– puddle/door .................................. 66
– rear ................................................. 65
Central console oddment
compartment..................................... 71
Chassis (marking) ............................... 201
Checking fluid....................................... 184
Child lock.............................................. 83
Child restraint systems
– “Universal Isofix” ......................... 114
– Passenger’s seat compliance ...... 115
Cigar lighter.......................................... 80
Clutch ................................................... 216
CO2emissions..................................... 217
Code Card ........................................... 6
Consumption
– engine oil ........................................ 186
– fuel ................................................... 216
Controls................................................ 75
Correct use of the car ...................... 127
Cruise Control..................................... 70
Courtesy lights ..................................... 74
– bulb replacement .......................... 174
– control button .............................. 74
Current outlet...................................... 73
ABS system.......................................... 92
Accessories purchased
by the owner .................................... 100
Additional heater................................. 56
Air bag
– front................................................. 115
– side .................................................. 118
Air cleaner............................................. 189
Adjustable Air vents ........................... 50
Alarm...................................................... 11
Armrest................................................. 71
Ashtray................................................... 81
ASR system........................................... 95
– activation/deactivation................. 95
At the filling station ............................ 101
Automatic climate
control system .................................. 59
Battery
– checking the charge ..................... 189
– jump starting ................................. 146
– recharging ...................................... 185
– replacing ......................................... 190
Bodywork
– maintenance .................................. 195
– version codes ............................... 202
II I
N N
D D
E E
X X

219
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
VEHICLE
IN AN
EMERGENCY
VEHICLE
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
EOBD system ...................................... 96
ESP system............................................ 93
External lights ...................................... 66
Fiat CODE system ............................. 6
Fix & Go automatic ............................ 153
Flashing the headlights ....................... 66
Fluid levels ............................................ 196
Fluids and lubricants ........................... 214
Follow me home (device) ................. 67
Front ceiling lights
– bulb replacement........................... 165
– control ............................................ 72
Front fog lights
– bulb replacement .......................... 162
– control button .............................. 75
Fuel
– consumption................................... 229
– cut-off switch.................................. 69
– level gauge....................................... 17
Fuel cut-off switch............................... 77
Fuel filler cap ....................................... 102
Fuel level gauge ................................... 17
Fuses (replacement) ........................... 167
Gearbox
– using manual gearbox .................. 132
Glass holder - can holder................... 72
Glove box/oddment compartment .. 70
Handbrake .......................................... 125
Hazard lights ........................................ 75
Head restraints
– front ................................................ 45
– rear................................................... 46
Headlight washer
– control ............................................ 61
– fluid level ........................................ 200
Headlights.............................................. 91
– beam adjustment .......................... 89
– headlight slant adjusting device ... 89
Heated rear window ......................52-57
Heating and ventilation ...................... 49
Identification data .............................. 200
Ignition device....................................... 13
In an emergency .................................. 145
Instrument panel ................................. 14
Instruments .......................................... 16
Interior fittings .................................... 78
Interiors ................................................ 197
Isofix (child restraint system) .......... 114
Jack ........................................................ 148
Jacking the car ..................................... 186
Key with remote control ................ 8
Key without remote control ........... 11
Dashboard........................................... 5
– Left hand drive version ............... 5
Dashboard and controls..................... 4
Dead lock device................................. 77
Digital display ....................................... 18
Dimensions .......................................... 210
Dipped beam headlights
– control ............................................ 66
– bulb replacement........................... 161
Direction indicators
– control ............................................ 67
– front bulb replacement ............... 161
– rear bulb replacement ................. 162
– side bulb replacement ................. 162
Doors..................................................... 82
Electrical socket ................................ 73
Engine
– identification code ........................ 200
– marking ........................................... 202
– technical data ................................ 203
Engine compartment
– washing ........................................... 197
Engine coolant...................................... 187
Engine coolant temperature gauge .. 17
Engine oil
– consumption .................................. 186
– level check....................................... 186
– specifications ................................. 227

Fiat Group Automobiles S.p.A. - Servizi al Cliente - Assistenza Tecnica - Ingegneria Assistenziale - Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print N. 603.81.255 - 07/2007 - 1stEdition
ENGINE OIL CHANGE
1.4 - 1.4 T-JET - 1.3 Multijet
Tank capacity 45
Reserve5 ÷ 7
Refuel petrol engines with unleaded petrol with octane rating (RON) no lower than 95 only (EN 228 Specifications)
Refuel diesel engines with diesel fuel for motor vehicles only (EN 590 Specifications)
FUEL CAPACITIES (litres)
COLD TYRE INFLATION PRESSURE (bar)
Tyre Medium load Full load
Front Rear Front Rear
185/65 R15 84T 2.3 2.1 2.3 2.3
195/60 R15 88H 2.3 2.1 2.3 2.3
195/55 R16 87H 2.3 2.1 2.4 2.4
205/45 R17 88V 2.4 2.2 2.5 2.4
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
1.4 1.4 T-JET 1.3 Multijet
litres kg litres kg litres kg
Engine sump and filter 2.6 – 2.4 2.6 3.2 –
