FUSE SUMMARY TABLE
LIGHTS
Right dipped beam headlight
Left dipped beam headlight
Right main beam headlight
Left main beam headlight
Front fog lights
Brake light/third stop light
Reversing light
Front/rear ceiling light/s
Door/puddle lights
+30 rear fog lights
RH/LH headlight fuse boxes
(versions with gas-discharge headlights)
COMPONENTS
Selespeed transmission pump (2.420V versions)
Ignition switch
Headlight aiming device
Climate control compressor
Anti-pollution sensor (versions with automatic two-zone climate
control system)/headlight washer relay coil/
Body Computer/Climate control system fan
Powered door mirrors control
(movement, ideograph lighting)
FIGURE
57
57
59
59
59
57
57
57
57
57
57
FIGURE
59
59
57
59
57
57
FUSE
F12
F13
F14
F15
F30
F37
F31
F32
F32
F53
F37
FUSE
F05 (MAXI-FUSE)
F03 (MAXI-FUSE)
F13
F19
F31
F51
AMPERE
15
15
10
10
15
7.5
7.5
10
10
7.5
7.5
AMPERE
30
20
15
7.5
7.5
7.5

202
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
IINDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
COMPONENTS
+ 30 Sound system/Connect-Navigator/
Heating-climate control unit/EOBD system diagnostic socket/
Volumetric-antiraising sensors/Alarm siren/
Bluetooth system control unit
Rear window wiper seat warming relay coil
Left rear power window
Right rear power window
Rear heated window
Windscreen wiper/washer/rear window washer
Passenger compartment current outlet (saloon versions)/Current outlet
(MultiWagon versions)/Cigar lighter
Door mirror demisting device/heated window nozzles
Cruise Control
Electric power steering control unit
Engine compartment control unit
Dashboard control unit
+30 door electronic control unit (door lock actuators,
dead lock, boot, rear heated window)/Trailer control unit, if any
Free
Headlight washer
Primary services (electronic injection)
Secondary services (electronic injection)
Water in diesel fuel filter sensor (Multijet versions)/
flow meter (Multijet versions)
FUSE
F39
F52
F33
F34
F40
F43
F44
F41
F35
F02 (MAXI-FUSE)
F70 (MEGA-FUSE)
F71 (MIDI-FUSE)
F36
F38
F09
F17
F11
F35
AMPERE
10
15
20
20
30
30
20
7.5
7.5
70
150
70
20
–
20
10
15
7.5
FIGURE
57
57
57
57
57
57
57
57
57
59
61
61
57
57
59
59
59
57
