spark plugs FIAT STILO 2006 1.G Owners Manual

108
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
Diesel Particulate Filter clogged
If the dedicated message is displayed, re-
fer to section “Warning lights and mes-
sages”.
During normal service the
catalyst and the diesel par-
ticulate filter (DPF) reach high tem-
peratures. Do not therefore park the
car over inflammable materials (grass,
dry leaves, pine needles, etc.): fire
hazard.
WARNING
PROTECTING THE
ENVIRONMENT
The devices for curtailing petrol engine
emissions are the following:
❒ three-way catalytic converter;
❒Lambda sensors;
❒fuel evaporation system.
In addition, do not let the engine run, even
for a test, with one or more spark plugs
disconnected.
The devices for curtailing diesel fuel en-
gine emissions are the following:
❒oxidising catalytic converter;
❒ exhaust gas recirculation system
(E.G.R.);
❒Lambda sensors;
❒diesel particulate filter (DPF) (where
provided it is fitted instead of the Lamb-
da sensor).DIESEL PARTICULATE FILTER
(DPF) (where provided)
The Diesel Particulate Filter is a mechan-
ical filter, integral with the exhaust system,
that physically traps particulates present
in the exhaust gases of Diesel engines.
The diesel particular filter has been adopt-
ed to eliminate almost totally particulates
in compliance with current / future law
regulations.
During normal use of the car, the engine
control unit records a set of data (e.g.:
travel time, type of route, temperatures,
etc.) and it will then calculate how much
particulates has been trapped by the filter.
Since this filter physically traps particulates,
it shall be cleaned (reclaimed) at regular
intervals by burning carbon particles. Re-
claiming procedure is controlled auto-
matically by the engine control unit ac-
cording to the filter conditions and the
conditions of use of the car. During re-
claiming the following phenomena could
take place: idling slight increase, fan acti-
vation, slight smoke increase, high exhaust
temperatures. These situations shall not
be considered as faults and they do not af-
fect car performance and environment.

212
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
30 60 90 120 150 180
●●
●●
●●●●●●
●
●
●
●
●●●
●●●●●●
●●●
●●●
●●●●●●
●●●●●●
●●●
●●●●●●
Thousands of km
Check timing belt conditions
(1.616V excluding version)
Check timing belt conditions
(1.616V version)
Check engine control system operation
(through diagnostic socket)
Replace accessory drive belt/s
(excluding 1.616V version)
Replace accessory drive belt/s (1.616V version)
Replace timing belt
(excluding Multijet and 1.616V versions) (*)
Replace timing belt
(Multijet and 1.616V versions) (*)
Change spark plugs (1.616V version)
Change spark plugs (petrol versions - excluding 1.616V)
Replace diesel fuel filter (Multijet versions)
Replace air cleaner cartridge
Change engine oil and oil filter
(petrol versions) (or every year)
Change engine oil and oil filter
(Multijet versions without DPF) (or every 2 years)
Change engine oil and oil filter
(Multijet versions with DPF) (**)
Change brake fluid (or every 2 years)
Change pollen filter (or every year)
(*) Regardless of the km covered, the timing belt shall be replaced every 3 years for particularly demanding use (cold climates, driving in the
city, idling for a long time) or in any case every 5 years
(**) Engine oil and oil filter shall be changed when the relevant warning light/message on the display turn on and in any case every 2 years.

241
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
ENGINE
GENERAL
Engine code
Cycle
Number and layout of cylinders
Piston bore and stroke mm
Total displacement cm3
Compression ratio
Maximum power (EEC) kW
HP
corresponding ratio rpm
Maximum torque (EEC) Nm
kgm
corresponding ratio rpm
Spark plugs
Fuel
1.416V
843A1000
Otto
4 in line
72.0 x 84.0
1368
11.2
70
95
5800
128
13
4500
NGK
DCPR7E-N
Unleaded petrol
95 RON
(Specification
EN228)
1.416V (*)
192B2000
Otto
4 in line
72.0 x 84.0
1368
11.2
66
90
5500
128
13
4500
NGK
DCPR7E-N
Unleaded petrol
95 RON
(Specification
EN228)
1.616V
192B3000
Otto
4 in line
79 x 81.5
1598
10.5
77
105
6200
150
15.3
3900
Bosch
FQR 8 LEU 2
Unleaded petrol
95 RON
(Specification
EN228)
1.816V
192A4000
Otto
4 in line
82.0 x 82.7
1747
10.3
98
133
6400
162
16.5
3500
NGK BKR6EZ
Champion
RC10YCC
Unleaded petrol
95 RON
(Specification
EN228)
2.420V
192A2000
Otto
5 in line
83 x 90.4
2446
10.5
125
170
6000
221
22.5
3500
Champion
RC8BYC
Unleaded petrol
95 RON
(Specification
EN228)
(*) Version for specific markets

266
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
Seats ........................................................ 37
– cleaning ............................................ 235
– easy entry ......................................... 38
– manually adjustable front seats .. 37
– rear sliding seats ............................ 39
– seat warming ................................. 38
Selespeed (gearbox) ........................... 141
Side/taillights .......................................... 59
Ski tunnel ................................................ 91
Skywindow (blade sunroof) .............. 74
Smart washing ...................................... 63
Snow chains .......................................... 155
Sound system (presetting).................. 100
Spark plugs ............................................. 241
Starting the engine ............................... 136
Steering .................................................. 244
Steering column lock .......................... 20
Steering wheel ....................................... 42
Sun visors .............................................. 73
Sunroof (Skywindow) ......................... 74
Suspensions ........................................... 244
Symbols .................................................. 8
Technical specifications............. 237
Third brake light
(bulb replacement) ............................ 191
Tilting shelf ............................................ 72Top speeds ............................................ 253
Towing the car ...................................... 206
Towing trailers ...................................... 151
Transmission ........................................ 241
Trip Computer...................................... 34
Tyre repair kit
(Fix&Go automatic)........................... 177
Tyres
– changing ............................................ 171
– pressure ............................................ 246
– snow tyres ....................................... 154
– standard tyres ................................. 247
– understanding tyre marking......... 246
Using the manual gearbox ............... 140
Using the Selespeed gearbox ........... 141
Warning lights and messages.. 157
Weights ................................................... 254
Wheel
– changing ............................................ 171
Wheel geometry................................... 245
Window (washing/cleaning) ........ 62-234
Windscreen washer/wiper ................. 62
Windscreen wiper
– blades ................................................ 231
– control .............................................. 62
– nozzles .............................................. 232 Presetting for mounting
the “Universal Isofix”
child restraint system ...................... 124
Pretensioners ....................................... 113
Protecting the environment ............. 108
Puddle light/door opening light
(bulb replacement) ............................ 195
Radio transmitters and
cellular telephones............................. 101
Rain sensor ........................................... 63
Rear fog lights ........................................ 69
Rear window washer/wiper............... 64
Rear window wiper
– blades ............................................... 231
– control ............................................. 64
– nozzles ............................................. 232
Rearview mirrors ................................. 43
Reversing lights
(bulb replacement) ..................... 188-189
Rims
– understanding rim marking .......... 246
Roof rack/ski rack ............................... 93
Rubber hoses ....................................... 230
Safety devices.................................. 109
S.B.R. system ........................................ 112
Seat belts ................................................ 110
