SETTINGS
Press the “Settings” button on the
display to show the main “Settings”
menu.
NOTE The menu items displayed vary
according to the versions.
As a guideline, the menu includes the
following items:
Display
Units (where provided)
Voice commands
Time and Date;
Safety/Driving assistance (where
provided)
Lights
Doors & Locks
Engine Off Options
Audio
Telephone/Bluetooth®
Radio Setup
SiriusXM Setup (where provided)
Restore Default Settings
Clear Personal Data
Apps restore (where provided)
Safety / Driving
Assistance
(where provided)
This function can be used to carry out
the following adjustments:
“Brake Control” (where provided):
this function can be used to select the
Brake Control system intervention
mode.The options available are:
- "Off": the system is deactivated;
- “Warning only”: the system intervenes
by activating automatic braking;
- “Warn + Act. Brk": the system
intervenes by providing the driver with
an acoustic warning and activating
automatic braking.
"Brake Control Sensitivity" (where
provided): this function can be used to
select the "readiness" of the Brake
Control system to intervene, according
to the distance from the obstacle. The
options available are "Near", "Med",
"Far".
“Park Assist"(for versions/markets,
where provided): this function can be
used to select the type of warning
provided by the Park Assist system.
The options available are:
- “Warning Only”
- “Warning + image”
“Front Park Assist”
The options available are: "Low",
"Medium", "High".
“Rear Park Assist”
The options available are: "Low",
"Medium", "High".
"Rear View Camera Delay" (where
provided): permits a delay in the
disappearance of images from the
camera when reverse is disengaged.
“Active Rear View Camera
Guidelines”(where provided): activates
dynamic grids that indicate the
trajectory of the vehicle on the display.
"Rain sensor"(where provided): this
function can be used to activate/
deactivate the automatic operation of
the wipers in the event of rain.
NAVIGATION
(Uconnect™ 7" HD Nav LIVE only)
Press the "Nav" button to show the
navigation map on the display.
NOTE: The navigation system volume
can only be adjusted during navigation
when the system provides voice
indications.
Navigation main menu
In the map display or navigation view,
tap the main menu button to open the
menu fig. 236 and fig. 237:
“Search”: select this button to
search for an address, a place
or a point of interest, then plan
a route to the location.
“Current route”: select this
button to cancel or change the
planned route.
285

“My places”: select this button
to create a collection of useful
or favourite addresses. The
following items are always
available in "My places":
“Home” and “Recent
destinations”.
“Parking”: select this button to
search for car parks.
“Weather”: select this button to
receive weather service
information.
NOTE The “Weather” function is only
active if TomTom Services are activated.
Otherwise, the button will appear
greyed out (and the function will not be
available).
“Petrol station”: select this
button to search for service
stations.
“TomTom services”: select this
button to access the following
services (available on
subscription): “Traffic”, “Speed
cameras”, “Weather”, “Online
search”.
"Report safety camera": tap on
this button to report a new
speed camera location.
NOTE The “Report safety camera”
function is only active if TomTom
Services are activated. Otherwise, the
button will appear greyed out (and the
function will not be available).
Select this button to open the
"Settings" menu;
Select this graphic button to
open the "Help" menu. The
"Help" menu contains
information about the
Uconnect™system, for
example the map version, the
serial number of the device
and the legal notices.
Select this button to return to
the previous screen.
Select this button to return to
the map display or navigation
view.
Select this button to deactivate
voice instructions. You will no
longer hear voice instructions
but you will still receive
information such as traffic
information and warning
sounds.Tip: you can
deactivate the warning sounds
by selecting “Settings”, then
“Sounds and warnings”.
Select this button to activate
voice instructions.
Select this button to reduce
the screen brightness and
display the map in darker
colours. When driving at night
or in unlit tunnels, watching the
screen is more comfortable
and less distracting for the
driver if the map uses darker
colours.Tip: the device will
automatically switch between
day and night view depending
on the time of day. To
deactivate this function, select
“Appearance” in the “Settings”
menu and deselect the option
"Switch to night colours" when
it is dark.
Select this button to increase
the screen brightness and
display the map in brighter
colours.
286
MULTIMEDIA

Navigation (Uconnect™ 7" HD Nav
LIVE only)
The following voice commands can be
given after pressing the
button on
the steering wheel:
Find "POI"
Navigate to “address”
Go to "city name" centre
Navigate to an address
Drive towards a town centre
Navigate home
Go via home
Cancel Route
Add this position to “My places”
Display “My Places”
Navigate through a saved location
Recent Destinations
Stop at a recent destination
Zoom in/Zoom out
2D/3D view
Report Speed Camera
Report risk area
MOPAR®CONNECT
(where provided)
These services let you keep your
vehicle under control at all times and
receive assistance in the event of
accident, theft or breakdown.
To have these services, install the
Mopar
®Connect Device on your
vehicle from the country (list
available on the
www.driveuconnect.eu website)
and request activation by following
the instructions received at the
email address given when your
vehicle was handed over to you.
To use the connected services, you
must download theUconnect™LIVE
App or access the
www.driveuconnect.eu portal.
You can find all the details about the
services in theMopar
®Connect
section of the
www.driveuconnect.eu portal.
PRIVACY MODE
Privacy mode lets you disable the “Find
car”, “Notify Area” and “Notify Speed”
services, which allow registered
customers to locate their cars, for a
fixed time.
IMPORTANT Vehicle position tracing
remains active for the assistance
services, where provided, in the event
of accident or vehicle theft, but is not
visible to the customer.
PRIVACY MODE activation
procedure
Proceed as follows:
take note of the total odometer
reading;
make sure that the instrument panel
is off;
Send the following text message to
+393424112613: “PRIVACY

” (e.g.:
PRIVACY
ZFA3340000P123456 12532). You can
find the chassis number in the
registration document;
before starting the engine, wait to
receive the text message confirming
that Privacy mode has been activated
and indicating when it expires.
When you have received the
confirmation, you can start your trip in
the knowledge that the vehicle will not
be traced until the indicated expiry time.
If it expires while you are still travelling,
Privacy mode will be extended until you
turn off the engine (instrument panel
off).
288
MULTIMEDIA

INDEX
ABS (system)...............75
Active Grille Shutter............45
Active safety systems...........75
Adaptive cruise control.........124
AdBlue (additive top-up
procedure)...............140
AdBlue® (UREA) additive for
diesel emissions...........144
Airbag...................104
Front airbags.............104
Side bags...............108
Automatic climate control
system..................31
Automatic light control..........23
Automatic transmission.....113 ,173
AUX source.............264 ,279
Battery..................201
Battery recharging............203
Bodywork (cleaning and
maintenance).............209
Bonnet....................33
Brakes...................209
Carrying children safely.........91
Changing a wheel............162
Checking levels..............191
Child protection systems........91
Child safety device............14
Climate control system..........29CO2 emissions..............243
Control buttons..............54
Control panel and on-board
instruments...............47
Courtesy lights...............25
Daytime running lights (DRL)......22
Daytime running lights (DRL) (bulb
replacement)..............150
Dimensions................225
Dipped headlights.............23
Dipped headlights (bulb
replacement)..............149
Direction indicators............24
Display....................52
Doors.....................13
Double load compartment (TIPO
STATION WAGON version)......38
Driving assistance systems.......78
DTC (system)................75
Dual-clutch automatic
transmission..........116 ,175
ECO function...............45
Electric power steering..........34
Electric windows..............33
Electronic Cruise Control........122
Engine...................215
marking................214
Engine compartment..........191
Engine compartment (washing). . . .210
Engine oil (consumption)........200Engine oil (level check).........200
ERM (system)................77
ESC (system)................75
External lights...............22
Fiat Code (system)............13
Fix&Go kit.................166
Flashing the headlights..........23
Fluids and lubricants..........238
Fog lights..................24
Front ceiling light..............25
Front fog light (bulb replacement) . .150
Front panel control summary
table...................272
Front seat electric heating........16
Front seats (manual adjustments) . . .15
Fuel consumption............243
Fuel cut-off system...........171
Full Brake Control (system).......78
Fuse boxes................156
Fuses (replacement)...........155
GSI (Gear Shift Indicator)........52
Hazard warning lights.........146
Emergency braking.........146
Head restraints...............19
Headlight alignment corrector.....23
Headlights (cleaning)..........210
Heavy-duty use of the car
(scheduled servicing)........190
HHC (system)................76

i-Size child restraint systems......98
Identification data
chassis marking...........213
engine marking............214
identification data plate.......213
Ignition device...............12
Important information and
recommendations..........290
Interior lights................25
Interiors (cleaning)............211
ISOFIX child restraint system
(installation)...............95
iTPMS (indirect Tyre Pressure
Monitoring System)..........82
Jump starting..............169
Key removal (automatic
transmission).............173
Key removal (dual-clutch
automatic transmission).......175
Keys.....................11
key with remote control.......11
Lever release (automatic
transmission).............173
Lever release (dual-clutch
automatic transmission).......175
Lifting the vehicle.............207
Light bulbs
Bulbs types..............147
Luggage Compartment.........35Luggage compartment
(extension)................16
Luggage covering curtain (TIPO
STATION WAGON version)......37
Main beam headlights..........23
Main Beam Headlights (bulb
replacement)..............149
Main menu.................53
Manual climate control..........29
Manual transmission..........113
Media mode...............277
Mopar Connect.............288
Multi-functional display - Right
hand drive version...........50
Multi-Functional Reconfigurable
Display - Right hand drive
version..................51
Multifunction display...........47
Number plate lights (bulb
replacement)..............154
Occupant protection systems.....85
Official type approvals.........289
Paintwork (cleaning and
maintenance).............209
Parking Brake...............112
Parking lights................23
Parking sensors.............131
Parking the vehicle...........112
Passive/active safety (LPG
system)..................41PBA (system)................76
Performance (top speed)........242
Periodic checks (scheduled
servicing)................190
Pre-tensioners...............89
Load limiters..............89
Prescriptions for handling the
vehicle at the end of its life.....244
Rain sensor................27
Rear seats..................16
Rear view camera............133
Rear View Camera............133
Rear view mirrors.............21
Reconfigurable Multifunction
Display..................48
Refuelling.................234
Refuelling procedure..........139
Emergency refuelling........141
Refuelling the vehicle..........139
Replacing a bulb.............146
Replacing an external bulb......149
Rims and tyres (dimensions)......219
Roof rack/ski rack.............40
Saving fuel................137
SBR (Seat Belt Reminder)........87
SBR (Seat Belt Reminder)
system..................87
Scheduled servicing...........179
Screen wiper/washer...........26
INDEX
