GETTING TO KNOW YOUR CAR
24
Once you have released
the lever, check that the
seat is firmly locked in the
runners by trying to move it back
and forth. Failure to lock the seat
in place could result in the seat
moving suddenly and the driver
losing control of the car.TO ADJUST THE RECLINING
SEAT BACK fig. 24
Pull out the lever Ato its full extent
and move it up or down to get the re-
quired position, then release it.
HEIGHT ADJUSTMENT
(DRIVER’S SEAT) fig. 24
To lift the seat, pull out the lever B
to its full extent and move it up or
down to get the required position. To
lower the seat, pull down the lever B
and move it up or down to get the re-
quired position.IMPORTANTThe adjustment can
only be made sitting in the driving
seat. Do not remove the seats or car-
ry out maintenance and/or repairs on
them: any operations that are not car-
ried out properly may affect the safe-
ty devices; always take your vehicle to
a Fiat Dealership.
LUMBAR ADJUSTMENT
fig. 25
(for versions/markets, where provided)
That provides better support for the
back. Turn knob Ato make the ad-
justment.
FRONT SEATS
MOVING THE SEAT
BACKWARDS
OR FORWARDS fig. 23
Lift lever Aand push the seat back-
wards or forwards.
fig. 23
F0B0015b
fig. 24
F0B0188b
fig. 22
F0B0016b
