Page 55 of 254
GETTING TO KNOW YOUR CAR
54
ODOMETER DISPLAY
This instrument displays the follow-
ing values:
on the upper line:partial kilome-
tres and engine oil level gauge (for ver-
sions/markets, where provided)
on the lower line:total kilometres
and programmed maintenance indica-
tor; versions with automatic gear are
also fitted with engaged gear indicator
(for further details see the chapter
“Automatic gear”).
Trip kilometre counter fig. 80
Press button Ato display the trip
kilometres. Keep it pressed to reset.Engine oil level gauge
(for versions/markets, where provided)
After turning the ignition key to M,
this indicator first displays the kilo-
metres to be reached before carrying
out the next maintenance operation
and then displays the engine oil level
in the engine sump for a limited time.
Fig. 81shows the correct oil level
condition. Flashing of the wording
“OIL”, together with the sound of the
buzzer and the dedicated message in-
dicate low engine oil level. Flashing of
wording “OIL –“ indicates an engine
oil level sensor failure.
fig. 80
F0B0244b
fig. 81
F0B0415b
fig. 82
F0B0246b
Scheduled maintenance
indicator fig. 82
The maintenance indicator uses
warning lamp Aand kilometre
counter Bto indicate when oil and oil
filter are to be replaced in accordance
with the service schedule. To keep the
warranty valid, go to a Fiat Dealer-
ship(see also the “Car maintenance”
chapter).
001-077 ULYSSE ING:001-077 ULYSSE ING 5-11-2009 12:11 Pagina 54
Page 61 of 254
GETTING TO KNOW YOUR CAR
60
GLOW PLUGS
(Amber)
The light comes on when
the ignition key is turned to Mand
then goes off when the glow plugs
have reached the set temperature.
Start the engine immediately after
the warning light goes off.
IMPORTANTWhen the environ-
ment temperature is very high, the
warning light might come on for less
than a second.FUEL RESERVE
(Amber)
The warning light comes on
when 8 litres of fuel have remained in
the tank.
Refuel as soon as possible after the
warning light comes on. SERVICE WARNING
LIGHT (Red)
This warning light will turn
on in the following cases: low coolant
level, particulate filter failure, low par-
ticulate filter additive level, risk of
clogged particulate filter.
DIPPED HEADLIGHTS
(Green)
When the dipped-beam
headlamps are turned on.
RIGHT DIRECTION
INDICATOR (Green)
The warning light starts
flashing when the direction indicator
control stalk is lifted or together with
the left direction indicator, when the
hazard light button is pressed.
K
2
E
m
The warning light will come on when
the front passenger air bag is deacti-
vated.
REAR FOG LIGHTS
(Amber)
When the rear fog lights
are turned on.
ESP SYSTEM (Amber)
The light comes on when
you turn the ignition key to
M, but it should go out after a couple
of seconds.
If the warning light either stays on or
comes on while travelling contact a Fi-
at Dealership.
Warning light flashing when driving
indicates that the ESP system is active.
4
ñ
è
001-077 ULYSSE ING:001-077 ULYSSE ING 5-11-2009 12:11 Pagina 60
Page 186 of 254
SERVICE SCHEDULE
30 60 90 120 150 180
●●●●●●
●●●●●●
●●●●●●
●●●●●●
●●●●●●
●●●
●●●●●●
●●●●●●
●●●●●●
●●●
●●●●●●
●●●
●
●●●●●●
CAR MAINTENANCE
185
Thousands of kilometres
Check tyre conditions/wear and adjust pressure if required
Check light system operation
(headlights, direction indicators, hazard lights, boot lights, passenger
compartment lights, glovebox lights, warning lights, horn)
Check windscreen wiper/washer operation, adjust nozzles if required
Check windscreen/rear window blade position/wear
Check front disk brake pad conditions and wear and pad wear
indicator operation
Check rear disk brake pad conditions and wear
Sight inspect the conditions of: body external parts, underbody protection, pipes
and hoses (exhaust - fuel - brakes), rubber parts (boots, sleeves, bushes, etc.)
Check cleanness of locks, bonnet and boot and lever cleanness and lubrication
Check and top up, if required, fluid levels (brakes/hydraulic clutch,
windscreen/rear window washer, battery, engine coolant, etc.)
Check and adjust handbrake lever stroke, if required
Sight inspect accessory drive belt conditions
Check accessory drive belt tension (for engines without automatic belt tightener)
Sight inspect timing belt conditions
Check exhaust emissions/smoke
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 185
Page 242 of 254
INDEX
241
- maintenance indicator............ 54
- scheduled servicing ................ 184
- service
schedule ............................ 185-186
Ceiling lights
(central and rear) ..................... 103
- bulb replacement ................... 168
Central door locking system ..... 22
Central glass/can holder ............. 97
Chassis marking ........................... 216
Cheap running that respects
the environment ....................... 145
Checking fluid levels ................... 189
- brake and hydraulic
clutch fluid ................................ 197
- engine coolant.......................... 195
- engine oil ................................... 193
- power steering fluid ............... 196
- windscreen/rear window/
headlight washer fluid ............ 195
Child restraint systems .............. 42
- passenger seat compliance
with regulations on child’s
seat use...................................... 46
- presetting for mounting
“Isofix Type” child' seat ......... 47
Child safety lock
- electrical .................................... 23- mechanical ................................ 23
Child surveillance (mirrors)....... 35
Cigar lighter ................................. 101
Climate control system ............. 62
- air vents ............................ 63-64
Clutch
- technical specifications........... 221
CO
2emissions in exhaust ......... 233
CODE card
(Fiat CODE system) ................ 11
Compartments under front
seats .............................................. 98
CONNECT ................................... 56
Containing running costs
and pollution .............................. 145
Cruise Control ............................. 88
Dashboard ................................. 48
Diesel fuel filter
(draining the condense) .. 190-200
Dimensions ................................... 226
Dipped beam headlights
- control ....................................... 79
- halogen bulb replacement ..... 163
- Xenon light replacement ....... 164
Direction indicators
- control ...................................... 82- replacing front bulbs ............. 162
- replacing side bulbs ............... 165
- types ........................................... 161
Document compartment............ 98
Door lights ................................... 104
Doors super lock ......................... 22
Driving your car ........................... 136
EBD (Electronic braking
force distributor) ...................... 118
Elastic bands .................................. 100
Electric windows ......................... 105
- anti-crushing system ............... 105
- driver’s door controls ........... 105
- passenger’s door controls .... 106
- sliding door controls .............. 106
Electrical sockets .......................... 104
Electro-chromatic mirror........... 34
Electronic alarm .......................... 14
- deactivation without the
remote control ....................... 17
- programming the system....... 17
- request for additional
remote controls ...................... 17
- switching the volumetric
protection off ........................... 17
240-252 ULYSSE ING:240-252 ULYSSE ING 5-11-2009 12:13 Pagina 241
