Page 86 of 254
GETTING TO KNOW YOUR CAR
85
Rear window wiper fig. 103
This feature can only work with the
ignition key at M.
– Turn knurled knob Afrom 0to
'.
When the windscreen wiper is
working and the reverse gear is en-
gaged, the rear window wiper is au-
tomatically turned on to improve rear
visibility.Rear window washer fig. 104
This feature can only work with the
ignition key at M.
– Turn knurled knob Afrom
'to
&(temporary position) and a jet of
rear window washer fluid is sent to
the rear window.
At the same time, the rear window
wiper will flick wipe thrice.
fig. 103
F0B0427b
fig. 104
F0B0428b
fig. 105
F0B0269b
TRIP COMPUTER
The trip computer is device for dis-
playing the following information by
pressing repeatedly button A-fig. 105
on the stalk edge:
range, current fuel consump-
tion, distance from destination,
trip 1 (kilometres travelled, av-
erage consumption, average
speed) etrip 2 (kilometres trav-
elled, average consumption, av-
erage speed).
This information will be viewed on
the infotelematic CONNECT system
display.
Reset: press and keep button A
pressed for more than 2 seconds.
078-135 ULYSSE ING 10-03-2009 11:39 Pagina 85
Page 141 of 254
DRIVING YOUR CAR
140
BEFORE GETTING BEHIND
THE WHEEL
The main suggestions are the fol-
lowing:
– make sure all lights including the
headlights are working properly;
– adjust the position of the seat,
steering wheel, driving and door mir-
rors properly for the best driving po-
sition;
– adjust the head restraints careful-
ly so that they support the head and
not the neck;
– make sure that nothing (mats, etc.)
gets in the way of the pedals when
they are pushed down;
– make sure that any child restraint
systems (child seats, carriers, etc.) are
properly fixed, preferably on the back
seat as this is the safest place in the
event of an accident;– make sure that objects being trans-
ported are carefully arranged so they
will not fly forward if you have to
brake sharply;
– do not eat a heavy meal before
travelling. Light eating will help keep
your reflexes prompt. Above all, do
not have anything alcoholic to drink.
Using certain prescription drugs can
reduce your ability to drive: read in-
structions for use carefully.
Periodically, remember to check:
– tyre pressure and conditions;
– engine oil level;
– coolant level and conditions of the
system;
– brake fluid level;
– power steering fluid level;
– windscreen washer liquid level.WHEN TRAVELLING
The main suggestions are the fol-
lowing:
– the first rule of safe driving is pru-
dence. Prudence also means putting
yourself into a position where you can
predict wrong or imprudent behaviour
from other drivers;
– stick closely to the rules of the
road in the particular country where
the vehicle is being driven and, above
all, do not exceed speed limits;
– ensure that, besides yourself, all the
other passengers in the vehicle have
their seat belts fastened, that children
are sitting in the appropriate child
seats and any animals in the car are
placed in suitable compartments;
– you should be physically fit and
mentally alert before setting out on
long journeys;
136-152 ULYSSE ING 10-03-2009 11:40 Pagina 140
Page 186 of 254
SERVICE SCHEDULE
30 60 90 120 150 180
●●●●●●
●●●●●●
●●●●●●
●●●●●●
●●●●●●
●●●
●●●●●●
●●●●●●
●●●●●●
●●●
●●●●●●
●●●
●
●●●●●●
CAR MAINTENANCE
185
Thousands of kilometres
Check tyre conditions/wear and adjust pressure if required
Check light system operation
(headlights, direction indicators, hazard lights, boot lights, passenger
compartment lights, glovebox lights, warning lights, horn)
Check windscreen wiper/washer operation, adjust nozzles if required
Check windscreen/rear window blade position/wear
Check front disk brake pad conditions and wear and pad wear
indicator operation
Check rear disk brake pad conditions and wear
Sight inspect the conditions of: body external parts, underbody protection, pipes
and hoses (exhaust - fuel - brakes), rubber parts (boots, sleeves, bushes, etc.)
Check cleanness of locks, bonnet and boot and lever cleanness and lubrication
Check and top up, if required, fluid levels (brakes/hydraulic clutch,
windscreen/rear window washer, battery, engine coolant, etc.)
Check and adjust handbrake lever stroke, if required
Sight inspect accessory drive belt conditions
Check accessory drive belt tension (for engines without automatic belt tightener)
Sight inspect timing belt conditions
Check exhaust emissions/smoke
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 185
Page 188 of 254
CAR MAINTENANCE
187
Every 1,000 km or before long jour-
neys, check and top up if required:
– engine coolant fluid level;
– brake fluid level;
– windscreen washer fluid level;
– yre pressure and conditions;– light system operation (headlights,
direction indicators, hazard lights,
etc.);
– windscreen wiper/washer opera-
tion and windscreen/rear window
blade position/wear;Every 3,000 km check and top up if
required: engine oil level.
You are recommended to use
PETRONAS LUBRICANTS, products,
designed and produced specifically for
Fiat vehicles (see table “Capacities” in
section “Technical specifications”).
ROUTINE MAINTENANCE
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 187
Page 191 of 254
CAR MAINTENANCE
190
1.Windscreen/rear window and
headlight (for versions/markets, where
provided) washer fluid -2.Engine
coolant - 3.Power steering fluid -
4.Engine oil - 5.Brake and hydraulic
clutch fluid.
fig. 1 - Versions 2.0 JTD 120 HP - 136 HPF0B0442b
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 190
Page 192 of 254
CAR MAINTENANCE
191
1.Windscreen/rear window and
headlight (for versions/markets, where
provided) washer fluid -2.Engine
coolant - 3.Power steering fluid -
4.Engine oil - 5.Brake and hydraulic
clutch fluid.
fig. 2 - Versions 2.2 JTDF0B0600b
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 191
Page 196 of 254
Top up only with the
same fluid contained in
the cooling circuit.
PARAFLU
UP(red) cannot be
mixed with PARAFLU11(blue) or
with other fluids. Should this take
place, do not start the engine and
contact Fiat Dealership.
CAR MAINTENANCE
195
WINDSCREEN - REAR
WINDOW - HEADLIGHT
WASHER FLUID fig. 7-8
(for versions/markets, where provided)
Remove cap Aand check the fluid
level.
If it is necessary to top up the fluid,
pour in a mixture of water and
TUTELA PROFESSIONAL SC 35
fluid in the following proportions:
– 30% of TUTELA PROFES-
SIONAL SC 35and 70% of water in
summer; The cooling system is
pressurised. If necessary,
replace the cap only with
another genuine one, otherwise
system efficiency could be com-
promised.– 50% of TUTELA PROFES-
SIONAL SC 35and 50% of water in
winter;
– use undiluted TUTELA PRO-
FESSIONAL SC 35for tempera-
tures below –20°C.
fig. 7 - Versions 2.0 JTD 120 HP - 136 HP
F0B0445b
fig. 8 - Versions 2.2 JTD
F0B0603b
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 195
Page 197 of 254
Do not travel with the
windscreen washer reser-
voir empty. The wind-
screen washer is fundamental for
improving visibility.Do not start the wind-
screen washer when the
fluid is finished to prevent
damaging the pump engine.
POWER STEERING FLUID
fig. 9
The oil level, with the vehicle on lev-
el ground and the engine cold should
correspond to the MAX reference
line.
This check should be performed
when the engine is cold and with the
car on level ground.When topping up (where necessary)
make sure that the oil has the same
specifications as the oil in the system.
Apply the following procedure:
– when the engine has been started,
turn the steering wheel repeatedly on
the left and on the right; then bring it
back to its central position;
– remove cap Aand wait for the oil
level in the reservoir to stabilize;
– top up to reach the MAX refer-
ence line and put the cap back to its
place. Certain commercial ad-
ditives for windscreen
washers are inflammable.
The engine compartment con-
tains hot components which may
set it on fire.
CAR MAINTENANCE
196fig. 9 - Versions 2.0 JTD 120 HP - 136 HP
Versions 2.2 JTD 170 HP
F0B0443b
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 196
Page 210 of 254
CAR MAINTENANCE
209
Changing the rear window
wiper blade fig. 16
Proceed as follows:
– lift the rear window wiper arm A
off the glass and position the blade so
as to form a right angle with the arm;
– remove the pressure fitted blade B
following the arrow direction;
– fit the new blade in the opposite di-
rection and make sure it is properly
locked into place.SPRAY NOZZLES
If there is no jet of liquid, first make
sure that there is liquid in the reser-
voir (see “Checking fluid levels” in this
chapter).
Then make sure that the holes in the
nozzles are not clogged up. Use a pin
for this if necessary.HEADLIGHT
WASHERS
fig. 17
(for versions/markets, where provided)
Regularly check that the nozzles are
intact and clean.
The headlight washers are automat-
ically switched on when the wind-
screen washer is operated and the
headlights are on.
fig. 16
F0B0177b
fig. 17
F0B0181b
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 209
Page 242 of 254
INDEX
241
- maintenance indicator............ 54
- scheduled servicing ................ 184
- service
schedule ............................ 185-186
Ceiling lights
(central and rear) ..................... 103
- bulb replacement ................... 168
Central door locking system ..... 22
Central glass/can holder ............. 97
Chassis marking ........................... 216
Cheap running that respects
the environment ....................... 145
Checking fluid levels ................... 189
- brake and hydraulic
clutch fluid ................................ 197
- engine coolant.......................... 195
- engine oil ................................... 193
- power steering fluid ............... 196
- windscreen/rear window/
headlight washer fluid ............ 195
Child restraint systems .............. 42
- passenger seat compliance
with regulations on child’s
seat use...................................... 46
- presetting for mounting
“Isofix Type” child' seat ......... 47
Child safety lock
- electrical .................................... 23- mechanical ................................ 23
Child surveillance (mirrors)....... 35
Cigar lighter ................................. 101
Climate control system ............. 62
- air vents ............................ 63-64
Clutch
- technical specifications........... 221
CO
2emissions in exhaust ......... 233
CODE card
(Fiat CODE system) ................ 11
Compartments under front
seats .............................................. 98
CONNECT ................................... 56
Containing running costs
and pollution .............................. 145
Cruise Control ............................. 88
Dashboard ................................. 48
Diesel fuel filter
(draining the condense) .. 190-200
Dimensions ................................... 226
Dipped beam headlights
- control ....................................... 79
- halogen bulb replacement ..... 163
- Xenon light replacement ....... 164
Direction indicators
- control ...................................... 82- replacing front bulbs ............. 162
- replacing side bulbs ............... 165
- types ........................................... 161
Document compartment............ 98
Door lights ................................... 104
Doors super lock ......................... 22
Driving your car ........................... 136
EBD (Electronic braking
force distributor) ...................... 118
Elastic bands .................................. 100
Electric windows ......................... 105
- anti-crushing system ............... 105
- driver’s door controls ........... 105
- passenger’s door controls .... 106
- sliding door controls .............. 106
Electrical sockets .......................... 104
Electro-chromatic mirror........... 34
Electronic alarm .......................... 14
- deactivation without the
remote control ....................... 17
- programming the system....... 17
- request for additional
remote controls ...................... 17
- switching the volumetric
protection off ........................... 17
240-252 ULYSSE ING:240-252 ULYSSE ING 5-11-2009 12:13 Pagina 241
