Page 19 of 40
ENGLISH
19
WEIGHTSWeights (kg) 2.0 JTD 2.2 JTD
Kerb weight(including fuel, spare wheel, tools and accessories): 1706 1753Payload including driver (1): 749 737
Maximum allowed loads (2)
– front axle:1250 1250
– rear axle:1300 1300– total:2455 2490
Towable loads:
– trailer with brakes 1850 1850– trailer without brakes 650 650Maximum load on ball (trailer with brakes) 76 76Maximum load on roof 100 100(1) If special equipment is fitted (sunroof, tow hitch, etc.), the unladen vehicle weight increases, thus reducing the specified payload.
(2) Loads not to be exceeded. The driver is responsible for arranging the loads so that they comply with these limits.
