ECU FORD BRONCO 1988 Owners Manual

1
Introductory Information
*
[IN00300( ALL)04/95]
Ford's Commitment to You
*
[IN00400( ALL)04/95]
At Ford Motor Company, excellence is the
continuous commitment to achieve the best
result possible. It is dedication to learning what
you want, determination to develop the right
concept, and execution of that concept with care,
precision, and attention to detail. In short,
excellence means being the standard by which
others are judged.
*
[IN00500( ALL)04/95]
Our Guiding Principles
*
[IN00600( ALL)04/95]
q
Quality comes first.For your satisfaction, the
quality of our products and services must be
our number one priority.
*
[IN00700( ALL)04/95]
q
You are the focus of everything we do.Our
work must be done with you in mind,
providing better products and services than
our competition.
*
[IN00750( ALL)04/95]
q
Continuous improvement is essential to our
success.We must strive for excellence in
everything we do: in our products Ð in their
safety and value Ð and in our services, our
human relations, our competitiveness, and
our profitability.
*
[IN00800( ALL)04/95]
q
Employee involvement is our way of life.
We are a team. We must treat one another
with trust and respect.
*
[IN00900( ALL)04/95]
q
Dealers and suppliers are our partners.We
must maintain mutually beneficial
relationships with dealers, suppliers, and our
other business associates.
File:ltinb.ex
Update:Fri Jun 9 15:32:32 1995
ProCarManuals.com

12
*
[SR02400(BEF )05/95]
RWARNING
Passengers should not be allowed to ride
in the cargo area. Persons not riding in a
seat with a fastened seat belt are much
more likely to suffer serious injury in a
collision. Cargo should always be secured
to prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
*
[SR02500(BEF )05/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR02600(BEF )05/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR02800(BEF )03/95]
RWARNING
Never wear the shoulder belt under the
arm. Never swing it around the neck over
the inside shoulder. Never use a single
belt for more than one person or across
more than one seating position. Each
seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair.
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

16 [SR03110(B )04/95]To fasten a ªcinch tongue,º pull the combination
lap and shoulder belt from the retractor so that
the shoulder belt portion of the safety belt
crosses your shoulder and chest. Be sure the belt
is not twisted. If the belt is twisted, remove the
twist. (For instructions on how to remove a
twist, see theHow to Untwist or Unjam a Safety
Belt Retractorsection in this chapter.) Insert the
belt tongue into the proper buckle for your
seating position until you hear a snap and feel it
latch. Make sure the tongue is securely fastened
to the buckle by pulling on tongue. Adjust the
lap belt portion of the safety belt by pulling up
on the shoulder belt until the lap belt fits snugly
and as low as possible around your hips.
[SR03115(B )05/95]
half page art:0000841-B
Lab and shoulder belt fastened
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

17
*
[SR03120(BEF )05/95]
Combination Lap and Shoulder
Belts
*
[SR03125(BEF )05/95]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, corner hard or if
your truck receives an impact of 5 mph
(8 km/h) or more, the combination lap/shoulder
belt locks and helps reduce your forward
movement. The front seat belt systems can also
be made to lock by jerking on the shoulder belt.
*
[SR03130(BEF )05/95]
NOTE: The rear belts cannot be made to lock
up by jerking on shoulder belt.
*
[SR03135(BEF )05/95]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
[SR03137(BEF )05/95]
To fasten the belt
*
[SR03140(BEF )05/95]
Pull the combination lap/shoulder belt from the
retractor so that the shoulder portion of the belt
crosses your shoulder and chest. Be sure the belt
is not twisted. If it is, remove the twist. Insert
the belt tongue into the proper buckle until you
hear a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
[SR03150(B )05/95]
one third page art:0020639-DFile:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

19 [SR03190(BEF )05/95]
While you are fastened in the seat belt, the
combination lap and shoulder belt adjusts to
your movement. However, if you brake hard,
turn hard, or if your vehicle receives an impact
of 5 mph (8 km/h) or more, the lap and
shoulder belt will become locked and help
reduce your forward movement.
%*
[SR06800(BEF )05/95]
Adjustable Lap Belts Without Retractors
[SR07100(B )05/95]
On the center position of the front and rear
three-passenger bench seats you will find a
lap-belt without a retractor, but does have a
locking adjustable tongue. Shorten this belt and
fasten it to buckle when you are not using it. To
lengthen the belt, tip the tongue at a right angle
to the belt and pull the belt over your lap until
the tongue reaches the buckle.
[SR07400(BEF )05/95]
one third page art:0020638-C
Fastening occupant safety lap belts
[SR07500(BEF )04/95]
To fasten the belt, pull the belt across your hips
and insert the tongue into the correct buckle on
your seat until you hear a snap and feel it latch.
Make sure the buckle is securely fastened by
pulling tongue.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

21 [SR08651(B )05/95]
Instructions for securing child safety seats with
combination lap/shoulder safety belts having
ªcinch tonguesº are provided later in this
chapter.
*
[SR08800(BEF )03/95]
How to Untwist or Unjam a Safety Belt
Retractor
*
[SR08900(BEF )03/95]
If you should jam the lap belt retractor by
allowing the belt to retract when it is twisted,
you can free the webbing with this procedure:
*
[SR09000(BEF )03/95]
1. Pull on the belt with both hands to tighten it
on the retractor spool.
*
[SR09100(BEF )03/95]
2. Feed the belt back into the retractor until it
is completely retracted. Repeat previous step
if necessary.
[SR09200(BEF )02/95]
3. Pull the belt out of the retractor as far as it
will go and untwist the belt or remove the
object that is jamming the belt. Let the belt
retract.
*
[SR09300(BEF )03/95]
4. Then, pull the belt out and let it retract
several times to make sure that the belt
works properly.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

35
*
[SR14600(BEF )05/95]
RWARNING
Passengers should not be allowed to ride
in the cargo area. Persons not riding in a
seat with a fastened seat belt are much
more likely to suffer serious injury in a
collision. Cargo should always be secured
to prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
*
[SR14700(BEF )05/95]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SR14800(BEF )05/95]
When possible, put children in the rear seat of
your vehicle. Accident statistics suggest that
children are safer when properly restrained in
the rear seating positions than in the front
seating positions.
*
[SR15000(BEF )05/95]
RWARNING
Safety belts and seats can become hot in a
vehicle that has been closed up in sunny
weather; they could burn a small child.
Check seat covers and buckles before you
place a child anywhere near them.
*
[SR15025(BEF )05/95]
RWARNING
Never leave a child unattended in your
vehicle.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

37
*
[SR15900(BEF )01/95]
Safety Seats for Children
*
[SR16000(BEF )05/95]
Use a safety seat that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
*
[SR16015(BEF )02/95]
Ford recommends the use of a child safety seat
having a top tether strap. Install the child safety
seat in a seating position which is capable of
providing a tether anchorage. For more
information on top tether straps seeAttaching
Safety Seats With Tether Strapsin this chapter.
[SR16025(BEF )05/95]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position making sure the tongue is securely
fastened in the buckle and for a shoulder/lap
belt combination with a sliding tongue make
sure the retractor is in the ªautomatic locking
mode.º
*
[SR16095(BEF )05/95]
All child restraint systems are designed to be
secured in vehicle seats by lap belts or by the
lap portion of a lap-shoulder belt.
*
[SR16100(BEF )05/95]
RWARNING
If you do not properly secure the safety
seat, the child occupying the seat may be
injured during a collision or sudden stop.
An unsecured safety seat could also injure
other passengers.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

42
*
[SR16370(BEF )04/95]
4. Insert the belt tongue into the buckle for that
seating position until you hear and feel the
latch engage. Figure 3. Make sure tongue is
latched securely to buckle by pulling on
tongue.
*
[SR16375(BEF )04/95]
half page art:0011240-B
Buckling the belt
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

46
*
[SR16410(BEF )04/95]
7. Before placing the child in the child seat,
forcibly tilt the seat from side to side, and
tug it forward to make sure that the seat is
securely held in place, Figure 7.
*
[SR16412(BEF )04/95]
half page art:0011244-A
Checking that the seat is secure
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com
