Special Notice
*
[IN04700(B )11/89]
NOTICE TO OWNERS OF
UTILITY-TYPE VEHICLES
*
[IN04810(B )11/89]
As with other vehicles of this type, failure to
operate this vehicle correctly may result in loss
of control or an accident. Be sure to read the
Additional Special Driving Instructions for Utility
Vehiclesin this book and the special supplement
included with four-wheel drive vehicles entitled
4-Wheeling with Ford.
*
[IN04850(B )03/95]
AMBULANCE PACKAGES
*
[IN04875(B )03/95]
RWARNING
Do not use this vehicle as an ambulance.
%
*
[IN05100( ALL)05/95]
Your Vehicle Identification
Number (VIN)
*
[IN05200( ALL)05/95]
Your Vehicle Identification Number (VIN) is the
same as the warranty number that appears on
your owner card. You should include this
number any time you write to Ford Motor
Company about your vehicle.
*
[IN05300(BEF )05/95]
The Vehicle Identification Number is attached to
your vehicle in the following places:
*
[IN05400(BEF )05/95]
q
on the metal tag attached to the top of the
instrument panel on the driver's side Ð you
can see the tag by looking through the
windshield from outside your vehicle.
File:ltinb.ex
Update:Fri Jun 9 15:32:32 1995
ProCarManuals.com

64
[ST05150( ALL)02/95]
Starting your vehicle
%*
[ST05200( ALL)05/94]
Preparing to Start Your Vehicle
*
[ST05300( ALL)05/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
*
[ST05400( ALL)01/95]
Before you start your vehicle, do the following:
*
[ST05500(BEF )01/95]
1. Make sure you and all your passengers
buckle your safety belts. SeeSafety Restraints
in the Index for more details.
*
[ST05600( ALL)03/95]
2. Make sure the headlamps and other
accessories are turned off when starting.
*
[ST05700(B F )10/94]
3.If you have an automatic transmission,
make sure that the gearshift lever is in P
(Park) and the parking brake is set before
you turn the key.
*
[ST05800(B F )03/91]
4.If you have a manual transmission,make
sure that the parking brake is fully set, push
the clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key. (Remember, the starter will operate only
if the clutch pedal is pushed in all the way).
*
[ST05900(BEF )03/95]
Testing the Warning Lights
*
[ST06015(BEF )03/95]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to theWarning
Lights and Gaugeschapter.
*
[ST06025(BEF )03/95]
If your Brake Warning Light does light up with
the key in the ON position, you may not have
File:ltstb.ex
Update:Fri Jun 9 15:30:44 1995
ProCarManuals.com

73
Warning Lights and
Gauges
*
[LG00400( ALL)01/95]
The instrument panel (dashboard) on your
vehicle is divided into several different sections.
The illustrations on the following pages show
the major parts of the instrument panel that are
described in this chapter. Some items shown
may not be on all vehicles.
*
[LG00500(B F )02/95]
Your vehicle has one of the following clusters:
*
[LG00600(B F )11/89]
q
A mechanical cluster
*
[LG00700(B F )11/89]
q
A mechanical cluster with tachometer
*
[LG00900(B F )12/89]
If you are not sure which cluster your vehicle
has, check the diagrams on the following pages
of this section.
File:ltlgb.ex
Update:Fri Jun 9 15:30:26 1995
ProCarManuals.com

89
Instrument Panel Controls
[IP00485(B )12/91]
full page art:0020026-F
Instrument Panel and Controls
File:ltipb.ex
Update:Fri Jun 9 15:29:43 1995
ProCarManuals.com

90
*
[IP00500(BEF )01/95]
The Climate Control Systems
*
[IP00601(BEF )12/91]
Your vehicle is equipped with a control
assembly designed to handle either a
combination A/C-Heater System or a
Heater-Only System.
*
[IP00801(BEF )10/93]
Instrument Panel Registers
*
[IP00950(B F )04/95]
There are four registers in the instrument panel.
Each of these registers contain a louver assembly
which can be manually adjusted to direct airflow
up, down, left, right, and positive shut-off. An
illustration of the register locations follows.
*
[IP01300(B F )03/93]
quarter page art:0020101-C
Instrument panel registers
*
[IP01400(B F )02/95]
Air Conditioner and Heater (If equipped)
*
[IP01450(B F )02/95]
The control for your air conditioning and heater
system is located at the center of the instrument
panel below the radio and will operate only
when the ignition key is turned to the ON
position. Your air conditioner and heater will
heat and/or cool your vehicle interior depending
on the function position and temperature you
select. The function selector control knob allows
you to select heating or cooling and determine
where the air will be directed. The temperature
control knob setting determines the temperature
of the air that flows into the vehicle.
File:ltipb.ex
Update:Fri Jun 9 15:29:43 1995
ProCarManuals.com

92
*
[IP01481(B F )08/94]
Airflow selections
*
[IP01482(B F )03/95]
VENT
[IP01483(B F )02/95]
UseVENTto bring outside air through the
instrument panel registers. You can heat the air
in this position by rotating the center knob into
the RED area. The air CANNOT be cooled
below the outside temperature regardless of the
center knob setting. Select NORM A/C or MAX
A/C to get cool air through the instrument
panel registers.
[IP01484(B F )03/95]
NORM A/C
*
[IP01485(B F )02/95]
SelectNORM A/Cto get refrigerated outside air
through the instrument panel registers. The A/C
position is used for cooling except when it is
extremely hot or fast cooling of the vehicle is
needed. Then, select MAX A/C for fast cooling
and return to NORM A/C when you are
comfortable.
*
[IP01486(B F )03/95]
MAX A/C
*
[IP01487(B F )04/95]
TheMAX A/Cposition produces cool air more
rapidly to provide faster cooling of your vehicle.
This is possible because cooler air is drawn from
inside the passenger area and refrigerated again
instead of using warmer outside air. Using
inside air will also make the fan sound louder
which is normal when using MAX A/C. The air
flow will be from the instrument panel registers.
*
[IP01488(B F )03/95]
FLOOR
*
[IP01489(B F )05/94]
Air flow will be to the floor whenFLOORis
selected. The air cannot be cooled in the FLOOR
position but can be heated by rotating the center
knob in the RED area.
File:ltipb.ex
Update:Fri Jun 9 15:29:43 1995
ProCarManuals.com

94
*
[IP01499(B F )05/94]
q
Remove any snow, ice or leaves from the air
intake area of your Air Conditioner and
Heater System which could block the air
intake. The intake area is located at the
bottom of the windshield.
*
[IP01500(B F )05/94]
Standard Heater
*
[IP01505(B F )05/94]
The control for your Heater system is located in
the center of the instrument panel below the
radio and will operate only when the ignition
key is turned to the RUN position. Your Heater
will heat and/or ventilate your vehicle interior
depending on the Function and temperature you
select. The Function Selector knob allows you to
select heating or ventilation and determine
where the air will be directed. The Temperature
knob setting determines the temperature of the
air that flows into the vehicle.
*
[IP01510(B F )05/94]
one third page art:0020096-D
*
[IP01515(B F )05/95]
To turn your Heater system on, select any
position except OFF. This will turn the fan ON
and allow air flow into the vehicle. Select OFF to
turn your Heater off. This will turn the fan off
and stop outside air from coming into the
vehicle.
File:ltipb.ex
Update:Fri Jun 9 15:29:43 1995
ProCarManuals.com

95
*
[IP01520(B F )03/95]
Temperature selection
*
[IP01525(B F )02/95]
The Temperature knob is the rotating knob
located at the center of the control with tapered
RED and BLUE bands surrounding most of the
knob. The wide RED part of the band (full right)
is the heat or warmer area. The wide BLUE area
(full left) is the cool or unheated temperature
area. Any position selected between full right
and full left will give a temperature between the
two extreme temperatures. The cool temperature
you select will not be cooler than the outside
temperature.
*
[IP01530(B F )03/95]
HFan speed adjustment
*
[IP01535(B F )05/94]
The
Hknob on the control is the fan speed
knob which controls the volume of air flow.
Rotate the
Hknob to the right to increase fan
speed and increase the amount of of air entering
the vehicle. Four fan speed positions are
available and are indicated by LO, two separate
dots and HI beside the
Hcontrol knob. The HI
position provides the most air flow.
*
[IP01540(B F )03/95]
Air flow selections
*
[IP01542(B F )03/95]
VENT
*
[IP01545(B F )02/95]
Use VENT to bring outside air through the
instrument panel registers. You can heat the air
in this position by rotating the temperature knob
into the RED area. The air CANNOT be cooled
below the outside temperature regardless of the
temperature knob setting.
*
[IP01550(B F )03/95]
FLOOR
*
[IP01555(B F )05/94]
Air flow will be to the floor when FLOOR is
selected. The air can be heated by rotating the
temperature knob into the RED area.
File:ltipb.ex
Update:Fri Jun 9 15:29:43 1995
ProCarManuals.com

97
*
[IP03901(B F )05/94]
one third page art:0020096-D
Climate control knobs (heater only)
*
[IP12300(B )08/93]
Rear Window Defroster
(If equipped)
(Standard in Canada)
*
[IP12400(B )12/91]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window.
*
[IP12550(B )04/95]
The control switch is located on the instrument
panel to the right of the steering column.
[IP12650(B )05/91]
quarter page art:0020887-A
Rear window defroster switch
*
[IP12800(B )02/95]
To defrost the rear window:
*
[IP12900(B )02/95]
1. Clear any snow from the rear window.
*
[IP13000(B )02/95]
2. Get in your vehicle and start the engine.
*
[IP13150(B )03/95]
3. Press the switch. The indicator light should
turn on.
File:ltipb.ex
Update:Fri Jun 9 15:29:43 1995
ProCarManuals.com
