jacking points FORD BRONCO 1988 Owners Manual

244 [RE09400(B )05/90]NOTE: If your truck has optional aluminum
wheels, you should slip the anti-scratch
spacer over the ªJº bolt between the
tire and carrier to prevent scratching
the aluminum styled-side surface.
[RE09500(B )05/91]
one third page art:0020273-C
Optional outside mounted spare tire and carrier
*
[RE15100(BEF )05/95]
RWARNING
Make sure the spare tire and jacking
equipment are stowed and secured in the
proper storage location.
%*
[RE15200( ALL)03/95]
Preparing to Change the Tire
*
[RE15250( ALL)12/91]
NOTE: To lift your vehicle by other than the
front or rear jacking points, be sure to
use only hoist adapters with a wide
contact surface.
*
[RE15300(B F )03/91]
1. Make sure that your vehicle will not move
or roll. If you have an automatic
transmission, put the gearshift in Park. If
you have a manual transmission, put the
gearshift in Reverse. Set the parking brake
and block the wheel that is diagonally
opposite the tire that you are changing.
*
[RE15335(B F )12/91]
NOTE: Make sure the ignition is in the OFF
position.
