tires FORD BRONCO 1996 5.G Owners Manual

86
*
[LG12350(B F )03/93]
quarter page art:0020535-D
Engine coolant temperature gauge
*
[LG12601( ALL)01/95]
Speedometer
*
[LG12700( ALL)01/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
*
[LG12750(BEF )04/95]
Your vehicle contains a speedometer which
receives its input from the Anti-Lock brake
sensor. The speedometer is also used to provide
a speed signal for correct operation of the
vehicle's Powertrain Control Module (PCM),
electronic transmission, and speed control (if so
equipped). Because of this, it is very
IMPORTANT to change the speedometer's
internal conversion constant if the size of the
tires on the vehicle is changed. Changing the
conversion constant to the proper value when
the tires are changed will also ensure that the
speedometer retains the original factory-set
accuracy. NOTE: The conversion constant can
only be changedsix timesonce the vehicle
leaves the factory. Your Ford dealership service
personnel can change the conversion constant.
*
[LG12753(BEF )01/95]
Some vehicles are equipped with a vehicle speed
(MPH/km/h) limiting device that is contained
within the Powertrain Control Module (PCM).
The purpose of this device is to maintain peak
vehicle speed below a specified limit. (Vehicle
speed limits may vary based on engine
displacement).
File:ltlgb.ex
Update:Fri Jun 9 15:30:26 1995

201
tires on the ground, and they must be rolling,
not sliding or spinning.
*
[DR19925(B F )11/89]
Transmission upshift in 4x4 with transfer case in
4L may be quite firm due to large total gear
reduction. This condition is normal.
*
[DR20000(B F )11/89]
Sand
*
[DR20100(B F )11/89]
When driving over sand, try to keep all four
wheels of the vehicle on the most solid area of
the trail. Do not reduce the tire pressures but
shift to a lower gear and drive steadily through
the terrain. Apply accelerator slowly and avoid
spinning the wheels.
*
[DR20200(B F )11/89]
Mud and Water
*
[DR20300(B F )12/89]
When driving through water, determine the
depth; avoid water higher than the bottom of
the hubs (if possible) and proceed slowly. If the
ignition system gets wet, the vehicle may stall.
*
[DR20400(B F )11/89]
Once through water, always try the brakes. Wet
brakes do not stop the vehicle as effectively as
dry brakes. Drying can be improved by moving
your vehicle slowly, while applying light
pressure on the brake pedal.
*
[DR20500(B F )11/89]
After driving through mud, clean off residue
stuck to rotating driveshafts and tires. Excess
mud stuck on tires and rotating driveshafts
causes an imbalance which could damage drive
components.
*
[DR20525(B F )07/94]
NOTE: If the transmission and transfer case is
submerged in water, their fluids should
be checked and changed, if necessary.
File:ltdrb.ex
Update:Fri Jun 9 15:26:57 1995

212
*
[DR27150(B F )05/95]
RWARNING
To avoid losing control on slippery roads,
do not downshift into Low with the
automatic transmission when moving
faster than 20 mph (32 km/h). Do not
downshift into First with the manual
transmission when moving faster than
5 mph (8 km/h).
*
[DR27350(B F )06/94]
RWARNING
The rear antilock brake system may not
prevent brake lock-up on extremely
slippery surfaces. Rear brake lock-up may
also occur while driving in four-wheel
drive because the transfer case couples the
front and rear axles together.
*
[DR27450(BEF )03/95]
Traction-Lok Rear Axle (If equipped)
*
[DR27501(BEF )03/95]
This axle provides added drive away traction on
slippery surfaces, particularly when one or more
wheels are on a surface with poor traction.
*
[DR27550(BEF )03/93]
Extended use of other than matching size tires
on a Traction-Lok rear axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
*
[DR27601(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
File:ltdrb.ex
Update:Fri Jun 9 15:26:57 1995

214may overheat the engine and transmission,
causing damage to both. In addition, other
vehicle systems and components may also be
damaged.
*
[DR27975( ALL)05/95]
RWARNING
Do not spin the wheels at over 35 mph
(56 km/h). The tires may fail and injure a
passenger or bystander.
*
[DR28050(BEF )03/95]
Driving With a Heavy Load
*
[DR28101(BEF )01/95]
There are limits to the amount of weight your
vehicle can carry or tow. The total weight of
your vehicle, plus the weight of the passengers
and cargo, should never be more than the Gross
Vehicle Weight Rating (GVWR). Also, the weight
that your vehicle carries over the front axle and
rear axle should never be more than the Gross
Axle Weight Rating (GAWR) for the respective
axle.
*
[DR28150(BEF )01/95]
The weight limits of your vehicle's tires affect
the GVWR or GAWR limitations. Usage of
replacement tires with higher weight limit than
originals does not increase GVWR or GAWR.
Usage of lower capacity replacement tires may
lower GVWR and GAWR limitations.
*
[DR28201(BEF )02/95]
RWARNING
If the GVWR or the GAWR specified on
the Safety Compliance Certification Label
is exceeded, your vehicle may be damaged
or you may lose control and injure
someone.
File:ltdrb.ex
Update:Fri Jun 9 15:26:57 1995

215
*
[DR28250(B F )03/91]
Heavy duty front suspension package
(option)
*
[DR28301(B F )03/91]
This optional front suspension package is
designed to handle the additional loads that will
be imposed on the vehicle by adding aftermarket
equipment, such as a snowplow. Refer to the
Safety Compliance Certification Label for details.
*
[DR28750( ALL)01/93]
Vehicle/Trailer Loads
*
[DR28801( ALL)06/92]
All vehicles may tow a Class I trailer provided
the Gross Combined Weight (GCW) is less than
or equal to the GVWR shown on the Safety
Compliance Certification Label. For heavier
trailer applications, refer to the towing
information found later in this chapter.
*
[DR28950(BEF )02/95]
Trailer Towing (may require trailer tow
option package)
*
[DR29001( ALL)03/91]
Towing a trailer puts additional loads on your
vehicle's engine, transmission, axle, brakes, tires
and suspension. For your safety and for the
good of your vehicle, use the right equipment
for the type of trailer you tow.
[DR29010(B F )05/95]
If your trailer is equipped with electric brakes,
auxiliary battery, or back-up lamps, the optional
7 wire trailer towing electrical hook-up will be
required on the vehicle.
*
[DR29025( ALL)09/92]
Your trailer towing capability will vary based on
the standard and optional equipment on your
vehicle. Refer to the followingVehicle
Loading/Towing Informationand the Trailer
Towing Tables to determine the specific towing
capability of your vehicle.
*
[DR29050( ALL)02/92]
q
Stay within the load limits when you tow.
File:ltdrb.ex
Update:Fri Jun 9 15:26:57 1995

220Overloading a vehicle punishes components and
can lead to shortened service life or outright
failure.
*
[DR31001( ALL)06/92]
The capacity of the tires is included as part of
the axle and suspension system, which is to be
considered when determining the lowest rated
component. Tires are rated to carry a specific
maximum load at a specific maximum tire
pressure.
*
[DR31050( ALL)06/92]
Passenger car type tires when installed on light
trucks and multipurpose passenger vehicles are
rated at 10% lower load carrying capacity due to
the differences in vehicle usages.
*
[DR31101(BEF )07/92]
The vehicle must not be loaded to both the front
and rear GAWR because the GVWR will be
exceeded. The GAWR of the front and rear axles
exceed the GVWR when added together to allow
flexibility in fore and aft loading of cargo.
*
[DR31110( ALL)06/92]
With the tires inflated to the specified pressure
the total weight of your vehicle must not exceed
the GVWR and GAWR specified on the Safety
Compliance Certification Label. This includes full
fuel tank(s), vehicle equipment, and occupants as
well as the cargo load.
*
[DR31120( ALL)06/92]
GCWR (Gross Combined Weight Rating)
*
[DR31130( ALL)06/92]
GCWR is the maximum combined weight of the
towing vehicle (including passengers and cargo)
and the loaded trailer. The GCWR is specified
by the manufacturer to indicate the combined
maximum loaded weight that the vehicle is
designed to tow.
*
[DR31140( ALL)06/92]
Maximum Trailer Weight Rating
*
[DR31150( ALL)06/92]
The maximum weight of a trailer the vehicle is
permitted to tow. The maximum trailer weight
rating is specified by the manufacturer and is
determined by subtracting the vehicle curb
File:ltdrb.ex
Update:Fri Jun 9 15:26:57 1995

241
*
[RE03400( ALL)05/95]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[RE03500( ALL)04/95]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
You may need to use a battery charger to fully
recharge the battery.
*
[RE03550( ALL)03/95]
If you need to replace your battery, seeBattery
in theServicing Your Vehiclechapter.
%
*
[RE03600( ALL)03/95]
Changing a Tire
*
[RE03700( ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
*
[RE03800( ALL)03/95]
The Conventional Spare Tire
*
[RE03900(BEF )01/95]
If you have the conventional spare tire, you can
use it as a spare or as a regular tire. This spare
tire is identical to the other tires that come with
your vehicle, although the wheel may not match.
*
[RE04275(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE04280(BEF )10/94]
Extended use of other than matching size spare
tires on a Traction-Lok axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995

290
*
[SV12500( ALL)05/95]
Improving Fuel Economy
*
[SV12600( ALL)05/95]
Fuel economy is affected by a number of
variables which can reduce efficiency. You can
improve fuel economy by understanding these
variables and minimizing their effect.
*
[SV12700( ALL)05/95]
The following decrease fuel economy:
*
[SV12800( ALL)05/95]
q
Lack of regular, scheduled maintenance
*
[SV12900( ALL)05/95]
q
Driving with your foot on the brake
*
[SV13000( ALL)05/95]
q
Sudden stops
*
[SV13100( ALL)05/95]
q
Excessive speed
*
[SV13200( ALL)05/95]
q
Extended engine idling
*
[SV13300( ALL)05/95]
q
Heavy loads
*
[SV13400( ALL)05/95]
q
Underinflated tires
*
[SV13500(BEF )05/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[SV13550(BEF )05/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
*
[SV13600( ALL)02/95]
Engine Oil Recommendations
*
[SV13610( ALL)04/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
ESE-M2C153-E and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995

303
*
[SV24900(BEF )03/01]
Wiper blade replacement
*
[SV25000(BEF )03/95]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent. To replace the blades, follow the
instructions that come with them.
*
[SV25200( ALL)03/95]
Tires
*
[SV25300( ALL)03/95]
Look at your tires each time you fill your fuel
tank. If one tire looks lower than the others,
check the pressure in all of them. Always follow
these precautions:
*
[SV25400( ALL)04/95]
q
Keep your tires inflated to the pressures that
are recommended.(SeeChecking the pressure
of the tireslater in this chapter.)
*
[SV25500(BEF )02/95]
q
Stay within the recommended load limits (see
Load limitsin the Index).
*
[SV25600( ALL)02/95]
q
Make sure the weight of your load is evenly
distributed.
*
[SV25700( ALL)10/89]
q
Drive at safe speeds.
*
[SV25800( ALL)01/95]
If you do not take these precautions, your tires
may fail or go flat.
*
[SV25875( ALL)05/95]
Ford Motor Company recommends obeying
posted speed limits.
*
[SV25900( ALL)05/95]
RWARNING
Driving too fast for conditions creates the
possibility of loss of vehicle control.
Driving at very high speeds for extended
periods of time may result in damage to
vehicle components.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995

304
*
[SV26000( ALL)03/95]
Checking the pressure of the tires
*
[SV26100( ALL)11/89]
At least once a month, check the pressure in all
your vehicle's tires, including the spare. Use an
accurate tire pressure gauge. Check the tire
pressure when tires are cold, that is, after the
vehicle has been parked for at least one hour or
has been driven less than 3 miles (5 km). You
can find the proper cold pressure on the Safety
Compliance Certification Label.
*
[SV26150( ALL)05/95]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
*
[SV26200( ALL)02/95]
Tire inspection and maintenance
*
[SV26300( ALL)02/95]
Inspect the tire treads, and remove stones, nails,
glass or other objects that may be wedged in the
tread grooves. Check for holes or cuts that may
permit air to leak from the tire, and make the
necessary repairs.
*
[SV26400( ALL)10/89]
Inspect the tire side walls for cuts, bruises and
other damage. If you suspect internal damage to
the tire, have it demounted and checked. You
may need to repair or replace it.
*
[SV26410( ALL)11/89]
Wheel inspection and maintenance
*
[SV26420( ALL)11/89]
Check for damage that would affect the runout
of the wheels. Wobble or shimmy will eventually
damage the wheel bearings.
*
[SV26430( ALL)06/93]
Front wheel bearings require periodic repacking
and adjustment as specified in theMaintenance
Schedule and Recordbooklet. Loose or worn front
wheel bearings tend to let the vehicle wander or
shimmy, and can eventually cause excessive tire
wear.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
