windshield wipers FORD CONTOUR 1996 2.G Owners Manual

84
*
[SC02800(ALL)05/95]
High Beams and Flashing the Lamps
[SC02900(ALL)05/95]
To turn on the high beams, turn the headlamp control knob to
the headlamp ON position and push the turn signal lever away
from you until it latches. When the high beams are on, the high
beam indicator light on the instrument cluster comes on.
[SC03000(ALL)10/93]
To turn off the high beams, pull the lever back to the off
position.
*
[SC03400(ALL)06/95]
To flash the headlamps, pull the lever toward you for a moment
and then release it. The headlamps will flash whether the
headlamp knob is in the on or off position.
*
[SC03700(ALL)03/95]
Windshield Wipers and Washer
*
[SC03800(ALL)03/95]
To turn on the windshield wipers, the ignition key must be
turned to the ON or ACC position.
[SC04400(ALL)05/95]
10-1/2 pica
art:0001189-D
Using the windshield wiper
[SC04500(ALL)02/94]
The windshield wipers can be set on high, low speed or interval
wipe. Turn the ring on the lever to set a longer or shorter pause
between wiping cycles.
File:cdsco.ex
Update:Thu Jan 25 12:10:03 1996

Steering Column Controls
85
*
[SC04950(ALL)05/95]
Windshield Washer
[SC05000(ALL)01/95]
When the lever is pulled to activate the windshield washer, the
wipers operate for about three cycles after the spray stops.
[SC05110(ALL)05/95]
7-1/2 pica art:0001194-D
Washing the windshield
*
[SC05310(ALL)01/95]
Do not try to clean the windshield when the washer fluid
container is empty or activate the washers at any time for more
than 15 seconds continuously. This could damage the washer
pump system.
*
[SC05350(ALL)01/93]
RWARNING
In freezing weather, the washer solution may freeze on
the windshield and obscure your vision. Always warm
up the windshield with the defroster before you use the
washer fluid. If you cannot see through the windshield
clearly, it can increase the risk of being involved in a
collision.
*
[SC05500(ALL)04/95]
For information about refilling the washer fluid or replacing
your windshield wiper blades, seeWindshield washer fluid and
Wipersin the Index.
File:cdsco.ex
Update:Thu Jan 25 12:10:03 1996

Servicing Your Contour
219
[SV20660(ALL)06/95]
Disconnecting the Battery
[SV20675(ALL)02/95]
Because your vehicle engine is electronically controlled by a
computer, some control conditions are maintained by power
from the battery. If you ever disconnect the battery or install a
new battery, you must allow the computer to ªrelearnº its idle
conditions before your vehicle will drive properly. To begin this
process, put the gearshift in P (Park) (automatic transaxle) or
Neutral (manual transaxle), set the emergency brake, turn off all
the accessories, and start the vehicle. Bring the engine to normal
operating temperature. Allow the manual transaxle to idle for
one minute in Neutral. Allow the automatic transaxle engine to
idle for one minute in N (Neutral) and one minute in D (Drive).
Perform the previous procedure with the air conditioning (if
equipped) on and off (conditions permitting). The relearning
process will complete automatically as you drive the vehicle.
*
[SV20700(ALL)03/95]
If you do not let the engine relearn its idle, the idle quality of
your vehicle may be adversely affected until the idle is
relearned. Your vehicle will eventually relearn its idle while you
drive it, but it takes much longer than if you use the previous
procedure.
*
[SV21700(ALL)03/95]
Windshield Washer Fluid and Wipers
*
[SV21800(ALL)03/95]
Washer Fluid
*
[SV22100(ALL)01/95]
Check the level of the windshield washer fluid every time you
stop for fuel. The reservoir for washer fluid is located on the
passenger's side of the engine compartment. Visual inspection
can determine if the washer fluid is adequate. Do not operate
the washer when the reservoir is empty.
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996

Servicing Your Contour
221
*
[SV23200(ALL)03/95]
Wiper Blades
*
[SV23300(ALL)03/95]
Check the windshield wiper blades at least twice a year. Also
check them whenever they seem less effective than usual.
Substances such as tree sap and some hot wax treatments used
by commercial car washes reduce the effectiveness of wiper
blades.
*
[SV23400(ALL)03/95]
If the blades do not wipe properly, clean both the windshield
and the wiper blades. Use undiluted windshield washer solution
or a mild detergent. Rinse thoroughly with clear water. Do not
use fuel, kerosene, paint thinner, or other solvents to clean your
wiper blades. These will damage your blades.
*
[SV23500(ALL)03/95]
To make reaching the wiper blades easy, simply turn the
ignition to the ACC position and turn your wipers on. Wait for
them to reach a vertical position and turn the ignition to the
OFF position. Do not move the wipers manually. Manually
moving the wipers across the windshield may damage them.
*
[SV23600(ALL)03/01]
Wiper blade replacement
*
[SV23700(OZ)03/95]
If the wiper blades still do not work properly after you clean
them, you may need to replace the wiper blade assembly or the
blade element. When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part or equivalent. To
replace the blades, follow the instructions that come with them.
[SV23716(ALL)11/94]
Passenger Compartment Air Filter Replacement
*
[SV23719(ALL)04/95]
In your climate control system, you may have a filter that cleans
the air before it enters the interior of the vehicle. This filter
should be replaced at the intervals in theMaintenance Schedule
and Recordbooklet.
[SV23723(ALL)04/95]
To replace the passenger compartment air filter:
[SV23726(ALL)02/95]1.
Remove both windshield wiper arms. With the wiper arm in
the horizontal position, lift the arm away from the
windshield while pulling the retaining clip at the base
toward the windshield. Release the wiper arm, then lift it off
the base.
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996

290
U
Used engine oil, disposal................ 212
V
Variable interval wipers................. 84
VECI (Vehicle Emission Control Information) decal.... 249
Vehicle Identification Number (VIN)........181, 186
Vehicle loading
automatic transaxles................. 156
calculating the load................. 156
manual transaxles.................. 156
Vehicle storage.................... 255
Ventilating your vehicle (see Climate control)....... 71
Viscosity (see Engine oil)................ 209
Visor (see Sun visor).................. 109
W
Warm engine, starting.................. 47
Warning chimes
headlamps on.................... 60
key in ignition.................... 43
safety belt...................... 56
Warning lights (see Lights)................ 53
Warranties
basic......................... 3
Canada....................... 3
radio........................ 137
Warranty Information Booklet.............. 3
Washer fluid
reservoir...................... 219
windshield..................... 219
Weight limits (GAWR, GVWR)............. 155
Wheel dollies (see Towing)............... 175
File:cdixo.ex
Update:Thu Jan 25 12:10:47 1996

291
Wheels
anti-theft lugnuts.................. 174
cleaning...................... 229
covers....................... 171
inspection and maintenance............. 223
lug nuts...................... 170
Windows........................ 98
power windows, operating............... 98
Windshield washer fluid and wipers
checking and adding fluid.............. 219
checking and replacing wiper blades......... 221
operation....................... 84
reservoir...................... 219
specifications.................... 220
variable interval wipers................ 84
Wrecker towing.................... 175
File:cdixo.ex
Update:Thu Jan 25 12:10:47 1996
