Seating and Safety Restraints
99 process that inflates the air bag. Small amounts of sodium
hydroxide may be present which may irritate the skin and eyes,
but none of the residue is toxic. The Air Bag Supplemental
Restraint System will reduce, but not eliminate all injuries in an
accident.
*
[SS11001(ALL)03/96]
RWARNING
Several air bag system components get hot after inflation.
Do not try to touch them after inflation.
*
[SS11101(ALL)03/96]
RWARNING
The air bag will inflate only once. The system is
designed to function on a one-time-only basis. If the air
bag is inflated, THE AIR BAG WILL NOT FUNCTION
AGAIN AND MUST BE REPLACED IMMEDIATELY. If
the air bag is not replaced, this will increase the risk of
injury in a subsequent collision.
*
[SS11201(ALL)03/96]
The Air Bag Supplemental Restraint System consists of:
*
[SS11301(ALL)03/96]
n
driver and passenger air bag modules (which include the
inflators and air bags),
*
[SS11401(ALL)03/96]
n
one or more impact and safing sensors,
*
[SS11501(ALL)00/96]
n
a system diagnostic module,
*
[SS11601(ALL)03/96]
n
a readiness light and tone,
*
[SS11701(ALL)03/96]
n
and the electrical wiring which connects the components.
[SS11751(ALL)04/96]
The diagnostic module monitors its own circuits, the air bag
electrical system, the air bag readiness light, the air bag power
and the air bag inflators.
