Maintenance and care
150Checking wiper blades
Check the wiper blades on your
vehicle for roughness by running
the tips of your fingers over the
edge of the blade.
Traces of grease, silicone and fuel
prevent wiper blades from
functioning properly. We
recommend Ford cleaning
solutions or equivalent to clean
wiper blades.
Change the wiper blades on your
vehicle at least once a year.
Cabin air filter replacement
In your climate control system, you
have a filter that cleans the air
before it enters the interior of the
vehicle. This filter should be
replaced at the intervals in the
”Maintenance Schedule” booklet.
To replace the cabin air filter:
1. Remove both windshield wiper
arms. With the wiper arm in the
horizontal position, lift the arm
away from the windshield while
pulling the retaining clip at the
base toward the windshield.
Release the wiper arm, then lift it
off the base.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 150

Maintenance and care
151 2. Remove the plastic caps from
the screws on the grille. Remove
the screws.
3. Open the hood. Pull off the
rubber weatherstrip at the back of
the engine compartment. Remove
the screws that hold the grille,
separate the two halves and
remove the grille.
4. The filter is in a housing at the
back of the engine compartment,
on the left side. Pull off the two
clips on the sides of the housing.
Slide out the housing and filter.
5. Slide the filter out of the
housing, replace with the new filter
and slide the housing and cabin air
filter back into place. Reinstall the
clips on the housing.
6. Replace the grille and wiper
arms.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 151

193
Index
APage
Accessory position on
the ignition . . . . . . . . . . . . . . . . . .27
Additives, engine oil . . . . . . . . .135
Air bag supplemental
restraint system
and child safety seats . . . . . . . .59
description . . . . . . . . . . . . . . . . .58
disposal . . . . . . . . . . . . . . . . . . .63
indicator light . . . . . . . . . . .10, 62
operation . . . . . . . . . . . . . . . . . .60
wearing safety belts . . . . . . . . .58
Air conditioning
(see Climate control system)
Alarm, activating panic . . . . . . . .42
Antenna, radio
(see Audio sytem) . . . . . . . . . . . .21
Anti-lock brake system (ABS) . .87
Anti-theft system (see Passive
Anti-Theft System) . . . . . . . . . . .44
Antifreeze (see Engine coolant)
Audio system . . . . . . . . . . . . . . . .21
Automatic transaxle
driving with . . . . . . . . . . . . . . . .92
fluid, adding . . . . . . . . . . . . . . .144
fluid, checking . . . . . . . . . . . . .145
fluid, refill capacities . . . . . . . .187
fluid, specification . . . . . . . . . .188
B
Backing up . . . . . . . . . . . . . . .92, 98
Battery
charging system warning light . .7
jumping a disabled battery . . .124
proper disposal, recycling . . . .148
replacement, specifications . .186
servicing . . . . . . . . . . . . . . . . . .146BPage
Brake fluid
checking and adding . . . . . . . .138
specifications . . . . . . . . . . . . . .188
Brake-shift interlock . . . . . . . . . .91
Brakelamps
(see Bulb replacement)
Brakes
anti-lock brake system (ABS) .87
brake warning light . . . . . . . . . .11
fluid, checking and adding . . .138
fluid, refill capacities . . . . . . . .187
fluid, specification . . . . . . . . . .188
parking . . . . . . . . . . . . . . . . . . . .89
Built-in child seat
folding up the seat . . . . . . . . . .73
inspection after a collision . . . .73
interlock safety feature . . . . . . .69
operation . . . . . . . . . . . . . . . . . .68
retractors . . . . . . . . . . . . . . . . . .69
Break-in period . . . . . . . . . . . . . . .2
Bulbs, replacing
foglamps . . . . . . . . . . . . . . . . .172
headlamps . . . . . . . . . . . . . . . .171
high-mounted brake lamp . . . .174
license plate lamp . . . . . . . . . .173
rear lamps . . . . . . . . . . . . . . . .173
specifications . . . . . . . . . . . . . .175
C
Cabin air filter . . . . . . . . . . . . . .150
Capacities for refilling fluids . . .187
Carbon monoxyde in exhaust . .166
Catalytic converter . . . . . . . . . .168
Chains, tires . . . . . . . . . . . . . . . .158
Changing a tire . . . . . . . . . . . . .119
Charging system warning light . . .7
CDW_Index_en_C 5/15/97 8:59 PM Page 193

Index
197 MPage
Maintenance (see Servicing)
Manual transaxle
backing up (reverse) . . . . . . . . .98
clutch . . . . . . . . . . . . . . . . . . . . .96
fluid, capacity . . . . . . . . . . . . .187
fluid, checking and adding . . .138
shift speeds . . . . . . . . . . . . . . . .97
Mileage, calculating fuel
economy . . . . . . . . . . . . . . . . . . .165
Mirrors
side view mirrors (power) . . . .20
Motorcraft parts . . . . . . . . . . . .186
N
National Highway Traffic Safety
Administration . . . . . . . . . . . . . .192
O
Octane rating . . . . . . . . . . . . . . .163
Odometer . . . . . . . . . . . . . . . . . . .15
Oil (see Engine oil)
Oil filter . . . . . . . . . . . . . . .136, 187
On-board diagnostic (OBDII)
system . . . . . . . . . . . . . . . . . . . .169
Overdrive . . . . . . . . . . . . . . . . .9, 93
Overhead controls . . . . . . . . . . . .36
P
Panel dimmer control . . . . . . . . .19
Panic alarm, remote entry sytem42
Parking brake . . . . . . . . . . . . . . .89
Parts (see Motorcraft parts) . . .186
Passenger compartment
air filter (see Cabin air filter) . .150
Passive Anti-Theft
System (PATS) . . . . . . . . . . . . . .44PPage
Power distribution box
(see Fuses)
Power door locks . . . . . . . . . . . . .37
Power features
mirrors . . . . . . . . . . . . . . . . . . . .20
seats . . . . . . . . . . . . . . . . . . . . . .48
sunroof . . . . . . . . . . . . . . . . . . . .36
windows . . . . . . . . . . . . . . . . . . .37
Power steering
fluid, checking and adding . . .143
fluid, refill capacity . . . . . . . . .187
fluid, specification . . . . . . . . . .188
R
Radio (see Audio system) . . . . . .21
Rear window defroster . . . . . . . .19
Refill capacities for fluids . . . . .187
Relays . . . . . . . . . . . . . . . . . . . . .112
Remote control
luggage compartment . . . . . . . .39
Remote entry system
locking/unlocking doors . . . . . .41
opening the trunk . . . . . . . . . . .42
panic alarm . . . . . . . . . . . . . . . .42
replacing the batteries . . . . . . .42
replacement/additional
transmitters . . . . . . . . . . . . . . . .43
Repairing paint chips . . . . . . . .181
Reporting safety defects . . . . . .192
Restraints, safety . . . . . . . . . . . . .50
Rotating the tires . . . . . . . . . . . .155
CDW_Index_en_C 5/15/97 8:59 PM Page 197
