Instrumentation
7 High beams
Illuminates when the headlamp
high beams are on. Charging system
Briefly illuminates when the
ignition is turned on and the engine
is off. The light also illuminates
when the battery is not charging
properly and the vehicle may
require electrical system service.
Safety belt
Illuminates when the ignition is
switched on as a reminder to fasten
the safety belts. For more
information, refer to
Safety belt
indicator light and warning
chime in the Seating and safety
restraints chapter.
Alternative design
Alternative design
Alternative design
CDW IIA2Instrum_en C 5/15/97 8:42 PM Page 7

Instrumentation
9 O/D Off indicator
(Automatic transaxle only)
Illuminates and remains
illuminated when the transaxle
control switch (TCS) on the end of
the gearshift lever is pressed and
overdrive is turned off.
Indicates the status of the
transaxle and will flash steadily if a
malfunction is detected. If the
flashing persists, have your
transaxle serviced by your dealer
or a qualified service technician as
soon as possible.
If the condition persists, your
transaxle may be damaged.
TRACTION
CONTROLO/D
OFF
Check engine
Illuminates when the ignition is
turned on and the engine is off.
Also illuminates when the engine’s
emission control system requires
service or if the fuel filler cap is
not fitted correctly.CHECK
ENGINE
CHECK
ENGINELow fuel
Illuminates when the fuel level is
low.
CDW IIA2Instrum_en C 5/15/97 8:42 PM Page 9

Instrumentation
12
EF 1
/
2
UNLEADED FUEL ONLY
NORMAL
BRAKE
TRACTION
CONTROLO/D
OFF
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
CHECK
ENGINE
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
EF 1
/
2
UNLEADED FUEL ONLY
12
03
x 1000
4
5
6
7
8
NORMAL
BRAKE
TRACTION
CONTROLO/D
OFFCHECK
ENGINE
Testing the warning and
indicator lights and chimes
Turn the ignition key to the on
position without starting the
engine. The following warning and
indicator lights will illuminate
briefly: charging system, safety belt
(does not illuminate, if the driver’s
safety belt is fastened), low
coolant, low fuel, engine oil
pressure, check engine and air bag
readiness.
If any of these lights do not
illuminate, see your dealer or
qualified service technician.
CDW IIA2Instrum_en C 5/15/97 8:42 PM Page 12

Maintenance and care
146Battery
Your vehicle may be equipped with
a Motorcraft maintenance-free
battery. The Motorcraft
maintenance-free battery normally
does not require additional water
during its life of service. However,
for severe service usage or in high
temperature climates, check your
battery electrolyte level, at least
every 24 months or 40 000 km
(24 000 miles). Keep the
electrolyte in each cell up to the
“level” indicator. Do not overfill the
battery cell.
For longer, trouble-free operation,
keep the top of the battery clean
and dry. Also, make certain the
battery cables are always tightly
fastened to the battery terminals.
If you see any corrosion on the
battery cables or terminals, remove
the cables from the terminal(s) and
clean with a wire brush. You can
neutralize the acid with a solution
of baking soda and water. Reinstall
the cables when you are done
cleaning them, and apply a small
quantity of grease to the top of
each battery terminal to help
prevent corrosion.
MotorcraftSUPERSTART
Pb
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 146

Maintenance and care
177
Adjusting the horizontal aim
1. Make sure the vehicle is on a
level surface.
2.With the hood open, locate the
horizontal indicator and adjusting
screw.
3. Turn the horizontal adjusting
screw until the reference mark on
the reflector extension aligns with
the “0” reference mark on the
horizontal indicator when viewed
directly from above.
4. When the horizontal aim has
been adjusted, close the headlamp
access panel. The horizontal aim must be
adjusted first. You will need one 7
mm box wrench, open end wrench
or T-15 Torx drive.
The following procedures assumes
that the vehicle’s front structure is
properly aligned. If the vehicle has
been in an accident requiring the
front end of the vehicle to be
repaired, the horizontal indicator
should be recalibrated by your
dealer or a qualified service
technician.
