stop start FORD CONTOUR 1998 2.G Owners Manual

Starting
80IMPORTANT VENTILATION
INFORMATION
If the engine is idling while the
vehicle is stopped in an open area
for long periods of time, open the
windows at least 2.5 cm (1 inch).
AUTO
OFFPNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C/
Adjust the heating or air
conditioning to bring in fresh air.
Do not start your vehicle in a
closed garage or in other
enclosed areas. Exhaust fumes
can be toxic. Always open the
garage door before you start the
engine. See
Guarding against
exhaust fumesin this chapter for
more instructions.
CDW IVA1_2 Starting en C 5/15/97 8:50 PM Page 80

110
FUELPUMPSHUT-OFF SWITCH
If the engine cranks, but does not
start or does not start after a
collision, the fuel pump shut-off
switch may have been activated.
The shut-off switch is a device
intended to stop the electric fuel
pump when your vehicle has been
involved in a substantial jolt.
Once the shut-off switch is
activated, you must reset the
switch by hand before you can start
your vehicle. The switch is located
on the side panel in front of the
driver’s side door.
Roadside emergencies
HAZARD FLASHER CONTROL
Use only in an emergency to warn
traffic of vehicle breakdown or
approaching danger. Depress to
activate. Depress again to switch
off. The hazard lights can be
operated when the ignition is off.
CDW IVC1-6Roads en C 5/15/97 8:53 PM Page 110

Maintenance and care
169 Preparing your vehicle for
inspection/maintenance (I/M)
testing
In some localities it may be a legal
requirement to pass an I/M test of
the on-board diagnostic(OBD) II
system. If your vehicle’s powertrain
system or battery has just been
serviced, the OBD II system is reset
to a condition unready for I/M
testing. To ready the OBDII system
for I/M testing, the law specifies
that additional city and highway
driving is necessary to complete
the check of the OBDII system.
The driving mode required to reach
the ready condition consists of a
minimum of 30 minutes of city and
highway driving:
•At least 20 minutes driving in
stop and go city-type traffic with
at least four idle periods.
•At least 10 minutes of driving on
an expressway or highway.
Before completing the above
driving modes, the engine must be
warmed up and at operating
temperature. Once started, the
vehicle must not be turned off
during these modes.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 169
