ENGINE
ConfigurationTransversely mounted, 60-degree V6, cast
aluminum block and heads, iron cylinder
liners, fully counterweighted forged crankshaft.
Bore x Stroke3.24 in (8.23 cm) x 3.11 in (7.90 cm)
Displacement2,544 cc / 155 cid
Compression ratio10.0:1
Horsepower145 kW @ 6,625 rpm
(195 HP @ 6,625 rpm)
Torque224 Nm @ 5,625 rpm
(165 ft-lb @5,625 rpm)
Redline6,750 rpm (fuel shut-off at 7,000 rpm)
Specific output77 HP per litre
ValvetrainDual overhead chain-driven cams, roller finger
followers with hydraulic lash adjustment,
ovate-wire valve springs, four valves per
cylinder.
Intake valves2 per cylinder, 32 mm head diameter
Exhaust valves2 per cylinder, 26 mm head diameter
Fuel systemSequential electronic fuel injection, 19 lb/hr.
injectors, 379 kPa (55 psi)
Intake manifoldUnique airflow-tuned upper intake, cast
aluminum plenum chamber, extrude-hone
internal surfaces
Throttle body6.0 cm (2.36 in) bore
Air-mass sensor7.0 cm (2.75 in) diameter
Exhaust manifoldsSteel tube (clamshell design)
Exhaust system5.72 cm (2.25 in), stainless steel,
6.35 cm (2.5 in) polished stainless steel tips
SVT Contour Specifications
12
TRANSAXLE
Type: MTX-75
Final drive: 4.06:1
Gear Ratio Speed (mph) Speed (km/h)
1st 3.42 35 56
2nd 2.14 56 90
3rd 1.45 82 132
4th 1.03 117 188
5th 0.77 143 230
Reverse 3.42 - -
SUSPENSION
FrontMacpherson struts, lower A-arms, coil springs,
tube shock dampers, anti-roll bar
RearIndependent Quadralink design, coil springs,
tube shock dampers, anti-roll bar
STEERING
TypePower assist, rack and pinion
Gear ratio14.5:1
Turns, lock to lock2.7
Turning diameter12.2 m (40 ft)
BRAKES
Front27.79 cm (10.94 in) vented discs,
single-position calipers
Rear25.10 cm (9.88 in) vented discs,
single-position calipers
ABS4-channel, 4-sensor system
SVT Contour Specifications
13
