Page 67 of 248
Controls and features
67 Fuel pump shut-off switch
For information on the fuel pump
shut-off switch, refer to Fuel
pump shut-off switch in the
Roadside emergencies chapter.
Positive retention floor mat
Position the floor mat in the
footwell. Place the mat eyelet over
the pointed end of the retention
post from the rear and rotate
forward to install. Adjust the floor
mat position to allow proper
operation of the accelerator pedal,
brake pedal, and clutch pedal (if
equipped).
To remove, lift the floor mat just
forward of the retention post and
rotate it rearward to disengage it
from the retention post.
Keep vehicle doors and
luggage compartment locked
and keep keys out of a child’s
reach. Unsupervised children
could lock themselves in an open
trunk and risk injury. Children
should be taught not to play in
vehicles.
On hot days, the
temperature in the trunk or
vehicle interior can rise very
quickly. Exposure of people or
animals to these high
temperatures for even a short time
can cause heat-related injury or
death. Small children are
particularly at risk.
13CCfen 17.6.99 10:53 Uhr Seite 67
Page 112 of 248
Starting
112If starting a vehicle with an
automatic transaxle:
• Make sure the parking brake is
set.
• Make sure the gearshift is in P
(Park).
If starting a vehicle with a manual
transaxle:
• Make sure the parking brake is
set.
• Push the clutch pedal to the floor
otherwise the engine will not crank
(turn over).
• Put the gearshift into neutral.
21CSten 17.6.99 11:06 Uhr Seite 112
Page 117 of 248
Driving
117
Two important
rules when
braking in
emergencies with
ABS:
1.
Apply full force
on both brake
and clutch pedal
(if equipped). Braking with ABS
• In an emergency, apply full force
on the brake pedal. In vehicles
with manual transaxles, you must
also depress the clutch pedal. The
anti-lock braking system will be
activated immediately, allowing
you to retain full steering control
of your vehicle and, providing
there is sufficient space, will
enable you to avoid obstacles.
• We recommend that you
familiarize yourself with this
braking technique. However,
avoid taking any unnecessary
risks.
• Although the ABS ensures
optimum braking efficiency,
stopping distances can vary
greatly, depending on the road
surface and conditions. Use of
the ABS cannot eliminate the
dangers inherent in driving too
close to the vehicle in front of you,
hydroplaning, excessive cornering
speed, or poor road surfaces.
2.
Steer around the
obstacle. No matter
how hard you brake,
steering control is
maintained.
22CDren 17.6.99 11:08 Uhr Seite 117
Page 127 of 248
Driving
127
Manual transaxle (if equipped)
Vehicles equipped with a manual
transaxle have a starter interlock
that prevents cranking the engine
unless the clutch pedal is fully
depressed.
Using the clutch
When starting a vehicle with a
manual transaxle:
1. Hold down the brake pedal.
2. Depress the clutch pedal.
3. Put the gearshift lever in neutral.
4. Start the vehicle.
5. Put the gearshift in 1 (First) or R
(Reverse).
6. Release the clutch slowly while
pressing gradually down on the
accelerator pedal.
Do not drive with your foot resting
on the clutch pedal. Do not use the
clutch to hold your vehicle at a
standstill while waiting on a hill.
These actions may reduce the
clutch life.
22CDren 17.6.99 11:09 Uhr Seite 127
Page 129 of 248
Driving
129 Parking
1. Apply the brake and the clutch
and shift into neutral.
2. Engage the parking brake.
3. Shift into 1 (First) or R
(Reverse).
4. Turn the ignition off.
Do not park your vehicle in
Neutral, it may move
unexpectedly and injure someone.
Use 1 (first) gear and set the
parking brake.
Reverse
To shift into R (Reverse):
1. Completely stop your vehicle.
2. Depress the clutch pedal to the
floor and place the gearshift lever
in the neutral position. Do not
release the clutch pedal.
3. If the following direction is not
followed, a grinding noise may
occur.
Wait a minimum of three seconds
before attempting to shift into R
(Reverse) gear.
1
2
22CDren 17.6.99 11:09 Uhr Seite 129
Page 130 of 248
Driving
130GVW (Gross Vehicle Weight)
Base curb weight plus the payload
weight. The GVW is not a limit or a
specification. Payload
Combined maximum allowable
weight of passengers, cargo, and
optional equipment. LOADING YOUR VEHICLE
Before loading your vehicle,
familiarize yourself with these
terms.
Base curb weight
Weight of the vehicle including any
standard equipment, fluids, and
lubricants. It does not include
passengers or aftermarket
equipment. 4. Push the gearshift lever
completely to the right, pull up the
ring on the stalk of the gearshift
lever, and then pull rearward on
the gearshift lever to engage the R
(Reverse) gear.
5. If the R (Reverse) gear is
engaged, slowly release the clutch
pedal from the floor.
22CDren 17.6.99 11:09 Uhr Seite 130
Page 164 of 248
Maintenance and care
164Working with engine off
(automatic transaxle)
1. Set the parking brake fully and
ensure the gearshift is securely
latched in P (Park).
2. Turn off the engine and remove
the key.
3. Block the wheels to prevent the
vehicle from moving unexpectedly.
Working with engine off
(manual transaxle)
1. Set the parking brake, depress
the clutch and place the gearshift
in 1 (first) or R (Reverse).
2. Turn off the engine and remove
the key.
3. Block the wheels to prevent the
vehicle from moving unexpectedly.
31CMCen 17.6.99 11:15 Uhr Seite 164
Page 165 of 248
Maintenance and care
165 Working with engine on
(automatic transaxle)
1. Set the parking brake fully and
ensure the gearshift is securely
latched in P (Park).
2. Block the wheels to prevent the
vehicle from moving unexpectedly.
Do not start your engine
with the air cleaner removed
and do not remove it while the
engine is running.
Working with engine on
(manual transaxle)
1. Set the parking brake, depress
the clutch and place the gearshift
in neutral.
2. Block the wheels to prevent the
vehicle from moving unexpectedly.
31CMCen 17.6.99 11:15 Uhr Seite 165
Page 172 of 248
Maintenance and care
172Brake/clutch fluid reservoir
Brake and clutch fluid systems are
supplied from the same reservoir.
The level of the fluid must lie
between the MIN and MAX marks
on the side of the reservoir. If the
level falls below the MIN mark, the
brake fluid level warning light on
the instrument cluster will
illuminate. Add only DOT 3, DOT 4
or Super DOT 4 brake fluid that
meets the Ford specification (see
the chapter Capacities and
specifications).
If you use brake fluid that is not
DOT 3, DOT 4 or Super DOT 4 you
will cause permanent damage to
your brakes.
MAX
MIN
Brake fluid is toxic.
BRAKE
BRAKE
Do not let the reservoir for
the master cylinder run dry.
This may cause the brakes to fail.
Windshield washer system
If necessary, add enough washer
fluid to fill the reservoir. Follow the
instructions on the washer fluid
label.
Alternative design
Do not put engine coolant in
the container for the
windshield washer fluid.
31CMCen 17.6.99 11:15 Uhr Seite 172
Page 243 of 248
243
Index
CPage
Cleaning your vehicle
engine compartment . . . . . . . .219
exterior lamps . . . . . . . . . . . . .220
fabric . . . . . . . . . . . . . . . . . . . .221
instrument panel . . . . . . . . . . .221
plastic exterior parts . . . . . . . .220
safety belts . . . . . . . . . . . . . . .222
wheels . . . . . . . . . . . . . . . . . . .218
wiper blades . . . . . . . . . . . . . .220
Climate control system
air conditioning . . . . . . . . . . . . .29
controlling airflow . . . . . . . . . . .26
defrosting . . . . . . . . . . . . . . . . . .38
temperature . . . . . . . . . . . . . . . .27
vents . . . . . . . . . . . . . . . . . . . . . .26
Clock . . . . . . . . . . . . . . . . . . . . . .45
Clutch
operation . . . . . . . . . . . . . . . . .127
recommended shift speeds . . .128
Cold engine starting . . . . . . . . .114
Controls
instrument panel . . . . . . . . . . . .20
power seats . . . . . . . . . . . . . . . .75
steering column . . . . . . . . . . . . .55
Customer assistance . . . . . . . . .229
D
Daytime running lights . . . . . . . .23
Defects, reporting . . . . . . . . . . .241
Defrost
rear window . . . . . . . . . . . . . . . .24
windshield . . . . . . . . . . . . . . . . .32
Dipstick, engine oil . . . . . . . . . .167
Door mounted controls . . . . . . . .64
Driving under special conditions
heavy load . . . . . . . . . . . . . . . .133
towing a trailer . . . . . . . . . . . .134
E
Electrical system
fuses . . . . . . . . . . . . . . . . . . . . .143EPage
Emergencies, roadside
fuel pump shut-off switch . . . .141
jump starting . . . . . . . . . . . . . .154
towing . . . . . . . . . . . . . . . . . . .160
Emergency brake (see Parking
brake)
Emission control system . . . . . .202
Engine
check engine warning light . . . .12
fuel pump shut-off switch . . . .141
lubricant specifications . . . . . .225
preparing to start . . . . . . . . . .111
refill capacities . . . . . . . . . . . .224
starting . . . . . . . . . . . . . . . . . . .114
Engine block heater . . . . . . . . .115
Engine coolant
checking and adding . . . . . . . .174
disposal . . . . . . . . . . . . . . . . . .178
low coolant warning light . . . . .11
refilll capacities . . . . . . . . . . . .224
specifications . . . . . . . . . . . . . .225
Engine fan . . . . . . . . . . . . . . . . .163
Engine oil
changing oil and filter . . . . . . .170
checking and adding . . . . . . . .169
dipstick . . . . . . . . . .167, 168, 169
disposal . . . . . . . . . . . . . . . . . .171
engine oil pressure
warning light . . . . . . . . . . . . . . .18
filter specifications . . . . . . . . .223
refill capacities . . . . . . . . . . . .224
specifications . . . . . . . . . . . . . .225
Exhaust fumes . . . . . . . . . .110, 202
F
Fan (see Engine fan)
Flasher, hazard . . . . . . . . . .56, 141
Flashing the lights . . . . . . . . . . . .57
Floor mats . . . . . . . . . . . . . . . . . .67
Fluid refill capacities . . . . . . . . .224
Foglamps . . . . . . . . . . . . . . .23, 208
4CInden 17.6.99 11:32 Uhr Seite 243
