Roadside emergencies
150
CHANGING TIRES
Park your vehicle in such a position
that neither the traffic nor you are
hindered or endangered when
changing the tire. Ensure that the
vehicle is on firm, level ground.
Secure your vehicle further by
blocking the wheels.
Activate the hazard lights.
Apply the parking brake and
engage first or reverse gear if the
vehicle has a manual transaxle or, if
the vehicle has an automatic
transaxle, select the P (Park)
position.
If parking on a slope is unavoidable,
block the wheels.
The temporary spare tire
The vehicle may have a high
pressure temporary spare tire. This
spare is smaller than a regular tire
and is designed for emergency use
only. This tire should be replaced
as soon as possible.
If you use the temporary
spare tire continuously or do
not follow these precautions, the
tire could fail, causing you to lose
control of the vehicle, possibly
injuring yourself or others.
23CREen 17.6.99 11:11 Uhr Seite 150

Roadside emergencies
151
80
MAX
km/h
When driving with a temporary
spare tire:
• Do not exceed the maximum
speed of 80 km/h (50 mph) and
only drive the shortest possible
distance.
• Do not exceed the permissible
gross weight of the vehicle.
• Do not install more than one
spare wheel on your vehicle at any
one time.
• Do not use snow chains on this
type of wheel.
• Do not drive through an
automatic car wash.
Spare tire location
The spare tire and tools are located
under the floor cover in the
luggage compartment.
50
MAX
mph
Removing the spare tire and
tools
1. Raise the rear of the floor cover
in the luggage compartment.
2. Completely unscrew the bolt and
remove the bolt and bracket.
3. Lift out the spare wheel.
4. Unscrew the jack bolt and
remove jack.
5. Obtain jack handle, which is
located on the floor under the
spare wheel.
23CREen 17.6.99 11:11 Uhr Seite 151

Roadside emergencies
153
Replacing a tire
1. Push the spare tire onto the
wheel studs.
2. Screw on the wheel nuts,
ensuring the tapered end of the
wheel nuts are facing the wheel,
and secure in a clockwise direction.
3. Lower the vehicle and remove
the jack by turning the handle
counterclockwise.
4. Fully tighten the wheel nuts in a
crosswise pattern.
5. Align the hub cap with the valve
and push firmly into position with
the ball of the hand.
6. Stow the jack and damaged tire
in the luggage compartment by
reversing the spare tire removal
instructions.
3
42 1
23CREen 17.6.99 11:11 Uhr Seite 153

Maintenance and care
188New vehicles are fitted with tires
that have their Tire Quality Grade
(described below) molded into the
tire’s sidewall. These Tire Quality
Grades are determined by
standards that the United States
Department of Transportation has
set.
Tire Quality Grades apply to new
pneumatic tires for use on
passenger cars. They do not apply
to deep tread, winter-type snow
tires, space-saver or temporary use
spare tires, tires with nominal rim
diameters of 10 to 12 inches or
limited production tires as defined
in Title 49 Code of Federal
Regulation Part 575.104(c)(2).
U.S. Department of
Transportation – Tire quality
grades: The U.S. Department of
Transportation requires Ford to
give you the following information
about tire grades exactly as the
government has written it. INFORMATION ABOUT TIRE
QUALITY GRADES
31CMCen 17.6.99 11:15 Uhr Seite 188

Maintenance and care
195 Change over from winter to
summer tires as soon as road
conditions allow, this will reduce
fuel consumption and noise in the
vehicle’s interior.
• Drive cautiously. If you hear the
chains rub or bang against the
vehicle, stop and retighten them. If
this does not work, remove the
chains to prevent vehicle damage.
• Local regulations may prohibit or
restrict the use of tire chains.
Investigate the laws and
regulations in your area before
installing chains.
• Avoid overloading your vehicle.
• Do not use tire chains on
temporary spare tires.
• Remove the tire chains when
they are no longer needed. Do not
use chains on dry roads.
• The suspension insulation and
bumpers will help prevent vehicle
damage. Do not remove these
components from the vehicle when
using snow tires and chains.
31CMCen 17.6.99 11:15 Uhr Seite 195

Customer assistance
239 Protection and appearance
equipment
Air bag anti-theft locks
Bed mat/bedliner tailgate covers
Bed mats
Bedliners
Car/truck covers
Cargo liners, interior
Carpet floor mats
Cleaners, waxes and polishes
Flat splash guards
Frond end covers (full and mini)
Hood deflectors
Locking gas cap
Lubricants and oils
Molded splash guards
Molded vinyl floor mats
Rallye bars
Rear air deflectors
Rear decklid spoilers
Side window air deflectors
Spare tire lock
Step bumpers
Step/sill plates
Tailgate covers
Tailgate lock
Tailgate protection
Tonneau covers
Touch-up paint
Universal floor matsFor maximum vehicle performance,
keep the following information in
mind when adding accessories or
equipment to your vehicle:
• When adding accessories,
equipment, passengers and luggage
to your vehicle, do not exceed the
total weight capacity of the vehicle
or of the front or rear axle (GVWR
or GAWR as indicated on the Safety
compliance certification label).
Consult your dealer for specific
weight information.
• The Federal Communications
Commission (FCC) and Canadian
Radio Telecommunications
Commission (CRTC) regulate the
use of mobile communications
systems - such as two-way radios,
telephones and theft alarms - that
are equipped with radio
transmitters. Any such equipment
installed in your vehicle should
comply with FCC or CRTC
regulations and should be installed
only by a qualified service
technician.
33CCAen 17.6.99 11:32 Uhr Seite 239

Index
246RPage
Radio (see Audio system) . . . . . .34
Rear window defroster . . . . . . . .24
Refill capacities for fluids . . . . .224
Relays . . . . . . . . . . . . . . . . . . . . .146
Remote control
luggage compartment . . . . . . . .66
Remote entry system
locking/unlocking doors . . . . . .68
opening the trunk . . . . . . . . . . .69
panic alarm . . . . . . . . . . . . . . . .69
replacing the batteries . . . . . . .69
replacement/additional
transmitters . . . . . . . . . . . . . . . .70
Repairing paint chips . . . . . . . .218
Reporting safety defects . . . . . .241
Restraints, safety . . . . . . . . . . . . .77
Rotating the tires . . . . . . . . . . . .191
S
Safety belts
(see Safety restraints)
Safety chains, when towing
a trailer . . . . . . . . . . . . . . . . . . . .138
Safety Compliance Certification
Label . . . . . . . . . . . . . . . . . . . . . .136
Safety defects, reporting . . . . . .241
Safety restraints
adjusting the safety belts . . . . .81
automatic locking mode
(retractors) . . . . . . . . . . . . . . . .79
cleaning the safety belts . . . . .222
extention assembly . . . . . . . . . .85
for children . . . . . . . . . . . . . . . .93
head restraints . . . . . . . . . . . . .74
lap and shoulder belts . . . . . . . .78
maintenance . . . . . . . . . . .86, 222
vehicle sensitive locking mode .79
warning light and chime . . . .9, 19
Safety seats for children
and air bags . . . . . . . . . . . .87, 103
attaching with tether straps . .104
automatic locking mode SPage
(retractors) . . . . . . . . . . . .79, 102
built-in child seat . . . . . . . . . . .97
in front seat . . . . . . . . . . . .87, 104
tether anchorage hardware . .107
Seats
adjusting the seats, manual . . .74
adjusting the seats, power . . . .75
folding rear seats . . . . . . . . . . . .76
head restraints . . . . . . . . . . . . .74
Servicing your vehicle . . . . . . . .162
Shift-lock system . . . . . . . . . . . .121
Shift positions (see Gearshift)
Snow tires and chains . . . . . . . .194
Spare tire
changing the tire . . . . . . . . . . .150
removing the spare tire . . . . . .151
temporary spare tire . . . . . . . .150
Spark plugs, certifications . . . .223
Specification charts, lubricants 225
Speed control
disengaging speed control . . . .62
return to a set speed . . . . . . . . .62
set a speed . . . . . . . . . . . . . . . . .60
set a higher speed . . . . . . . . . . .61
set a lower speed . . . . . . . . . . . .61
turn speed control off . . . . . . . .59
turn speed control on . . . . . . . .59
Speedometer . . . . . . . . . . . . . . . .20
Starting your vehicle
preparing to start the vehicle .111
starting the engine . . . . . . . . .114
Steering column controls . . . . . .55
Steering wheel
horn . . . . . . . . . . . . . . . . . . . . . .56
speed control . . . . . . . . . . . . . . .59
tilting . . . . . . . . . . . . . . . . . . . . .55
Sunroof . . . . . . . . . . . . . . . . . . . .63
Supplemental restraint
system . . . . . . . . . . . . . . . . . . . . .87
4CInden 17.6.99 11:32 Uhr Seite 246

Index
247 TPage
Tachometer . . . . . . . . . . . . . . . . .21
Tail lamps (see Lamps)
Temperature control
(see Climate control)
Testing the warning lights . . . . . .19
Tether anchor installation
(see Child safety restraints)
Tilt steering wheel . . . . . . . . . . . .55
Tires
changing . . . . . . . . . . . . . . . . .150
checking tire pressure . . . . . .191
cleaning . . . . . . . . . . . . . . . . . .218
inspection and maintenance . .191
replacing . . . . . . . . . . . . . . . . .192
rotating . . . . . . . . . . . . . . . . . .191
snow tires and chains . . . . . . .194
spare tire . . . . . . . . . . . . . . . . .151
tire grades . . . . . . . . . . . . . . . .188
treadwear . . . . . . . . . . . . .189, 192
wearbands . . . . . . . . . . . . . . . .192
Towing your vehicle . . . . . . . . .161
Trailer towing . . . . . . . . . . . . . .134
Transaxle
automatic, operation . . . . . . . .121
fluid, checking and adding
(automatic) . . . . . . . . . . . . . . .179
fluid, refill capacities . . . . . . . .224
lubricant specifications . . . . . .225
manual, operation . . . . . . . . . .127
Transmitter (see Remote entry)
Trip odometer . . . . . . . . . . . . . . .20
Trunk (see Luggage compartment)
remote release lever . . . . . . . . .66
using the remote entry system .69
Turn signal
indicator lights . . . . . . . . . . . . . .8
lever . . . . . . . . . . . . . . . . . . . . . .57
U
Used engine oil, disposal . . . . . .171VPage
Variable interval wipers . . . . . . . .58
Vehicle care . . . . . . . . . . . . . . . .216
Vehicle Identification Number
(VIN) . . . . . . . . . . . . . . . . . . . . .228
Vehicle Emission Control
Information(VECI) . . . . . . . . . .204
Vehicle loading . . . . . . . . . . . . .130
Ventilating your vehicle . . . . . .109
Viscosity (see Engine oil)
W
Warning chimes
headlamps on . . . . . . . . . . . . . .19
key in ignition . . . . . . . . . . . . . .19
safety belt . . . . . . . . . . . . . . . . .19
Warning lights (see Lights)
Washer fluid reservoir . . . .167, 168
Weight limits (GAWR, GVWR) .130
Wheels
cleaning . . . . . . . . . . . . . . . . . .218
inspection and maintenance . .191
Windows
one-touch down . . . . . . . . . . . .64
power windows, operating . . . .64
rear, defrosting . . . . . . . . . . . . .24
Windshield washer fluid and wipers
checking and adding fluid . . . .172
checking and replacing
wiper blades . . . . . . . . . . . . . .186
operation . . . . . . . . . . . . . . . . . .58
fluid, specification . . . . . . . . . .225
variable interval wipers . . . . . . .58
Wrecker towing . . . . . . . . . . . . .160
4CInden 17.6.99 11:32 Uhr Seite 247
