Removing jumper cables
*
[RE03000( ALL)03/95]
1.Always remove the jumper cables in the
reverse order.Remove the negative (S) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled
vehicle.
*
[RE03100( ALL)06/95]
2. Remove the negative (S) cable from the
booster battery.
*
[RE03200( ALL)06/95]
3. Remove the positive (+) cable from the
booster battery.
*
[RE03400( ALL)05/95]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[RE03500( ALL)04/95]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
You may need to use a battery charger to fully
recharge the battery.
*
[RE03550( ALL)03/95]
If you need to replace your battery, seeBattery
in theServicing Your Vehiclechapter.
*
[RE03600( ALL)03/95]
Changing a Tire
*
[RE03700( ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
%*
[RE03800( ALL)03/95]
The Conventional Spare Tire
*
[RE03900(BEF )01/95]
If you have the conventional spare tire, you can
use it as a spare or as a regular tire. This spare
tire is identical to the other tires that come with
your vehicle, although the wheel may not match.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

248
*
[RE04275(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE04280(BEF )10/94]
Extended use of other than matching size spare
tires on a Traction-Lok axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
*
[RE05100(BEF )03/95]
Spare Tire Location
*
[RE05250( E )06/94]
The spare tire for your vehicle is stowed at the
rear under the frame (except cutaway and
stripped chassis models).
*
[RE05550( E )03/91]
To remove the spare tire:
[RE05625( E )03/93]
1. Open both of the rear doors. Remove the
access cover from the rubber strip found
behind the left door. Insert tapered end of
lug wrench or tip of jack handle through the
access hole. Turn counterclockwise until the
cable extends enough to allow the spare tire
to be pulled rearward from under the
vehicle.
*
[RE05700( E )10/94]
2. Slide the spare tire to the rear and remove
the retainer from the wheel.
*
[RE05850( E )10/94]
3. To stow the cable/retainer with spare
removed, turn jack handle wrench clockwise
until slack is removed.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

252
*
[RE16900(BEF )10/89]
4. Loosen the wheel nuts by pulling up on the
handle of the lug nut wrench about one-half
turn (counterclockwise). Do not remove the
wheel lug nuts until you raise the tire off the
ground.
*
[RE16950(BEF )05/95]
Removing and Replacing the Tire
[RE17000( E )02/95]
1. Unfold the jack handle and lock into the
jack. Use the jack handle to slide the jack
under the vehicle.
*
[RE17175(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE17200(BEF )05/95]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
[RE17300(BEF )06/95]
2. Positioning the jack
[RE18501( E )01/89]
a. To raise a front or rear wheel, place the
jack as shown in the following
illustrations.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

257 % [RE24375( E )02/89]
ten pica chart:0020318-B
*
[RE24397(BEF )02/95]
If the Engine Cranks But Does
Not Start or Does Not Start After
a Collision
*
[RE24400(BEF )04/95]
The Fuel Pump Shut-off Switch
*
[RE24500(BEF )03/95]
If the engine cranks but does not start or if you
have had a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device that stops the fuel pump
when your vehicle has been involved in a
substantial jolt.
*
[RE24600(BEF )01/95]
For information on how to check and reset the
fuel pump shut-off switch, seeFuel pump shut-off
switchin the Index.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

267
*
[HS06400( ALL)06/95]
Getting Help Outside the U.S.
and Canada
*
[HS06500( ALL)06/95]
Before you export your vehicle to a foreign
country, contact the appropriate foreign embassy
or consulate to make sure local regulations do
not prevent you from registering your vehicle.
Officials at the embassy can also help you decide
whether you should import your vehicle to that
country.
*
[HS06600( ALL)06/95]
Officials at the embassy or consulate can tell you
where to get unleaded fuel. If you cannot get
unleaded fuel or can get only fuel with an
anti-knock index that is lower than your vehicle
needs, contact a district or owner relations office
before you leave the U.S. or Canada.
*
[HS06700( ALL)06/95]
Use of leaded fuel in your vehicle without a
proper conversion may damage the effectiveness
of your emissions control system and may cause
engine knocking or serious engine damage. Ford
Motor Company is not responsible for any
damage that is caused by use of improper fuel.
*
[HS06800( ALL)06/95]
You may also have difficulty importing your
vehicle back into the U.S. if you use leaded fuel.
*
[HS06900( ALL)06/95]
If your vehicle must be serviced while you are
traveling or living in Central or South America,
the Caribbean, or the Middle East, contact the
nearest Ford dealership. If the dealership cannot
help you, write to:
*
[HS07000( ALL)06/95]
one inch art:0095024-A
File:12lthse.ex
Update:Wed Apr 17 08:41:20 1996

271
Accessories
*
[AC00400( ALL)03/95]
Ford Accessories for Your Vehicle
*
[AC00500( ALL)04/95]
A wide selection of accessories is available
through your local authorized dealer. These fine
accessories have been engineered specifically to
fulfill your automotive needs. They are custom
designed to complement the style and
aerodynamic appearance of your Ford-built
vehicle. In addition, each accessory is made from
high quality materials and meets or exceeds
Ford's rigid engineering and safety specifications.
That is why Ford brand accessories are
warranted for up to 3 years or 36,000 miles
(60,000 km), whichever comes first. See your
dealer for complete warranty information and
accessory availability.
File:13ltace.ex
Update:Wed Apr 17 08:41:05 1996

273
*
[AC02000( ALL)05/95]
NOTE: The Federal Communications
Commission (FCC) or the Canadian
Radio Telecommunications Commission
(CRTC) regulates the use of mobile
communications systems Ð such as
two-way radios, telephones, and theft
alarms Ð that are equipped with radio
transmitters. Any such equipment
installed in your vehicle should comply
with FCC or CRTC regulations and
should be installed only by a qualified
technician.
*
[AC02100( ALL)01/95]
NOTE: Mobile communications systems may
harm the operation of your vehicle,
particularly if they are not properly
designed for automotive use or are not
properly installed. For example, when
operated, such systems may cause the
engine to stumble or stall. In addition,
such systems may themselves be
damaged or their operation affected by
operating your vehicle. (Citizens band
[CB] transceivers, garage door openers,
and other transmitters whose power
output is 5 watts or less will not
ordinarily affect your vehicle's
operation.)
*
[AC02200( ALL)05/95]
NOTE: Because we have no control over the
installation, design, or manufacture of
such systems, Ford cannot assume
responsibility for any adverse effects or
damage that may result if you use this
equipment.
File:13ltace.ex
Update:Wed Apr 17 08:41:05 1996

279
Servicing Your Econoline
%*
[SV00300( ALL)03/95]
Service Made Easy
*
[SV00400(BEF )01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(BEF )01/95]
1. When we can, we design parts that do not
need to be serviced.
*
[SV00600(BEF )01/95]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[SV00700(BEF )01/95]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[SV00800(BEF )01/95]
q
When possible, we design parts Ð such as
the headlamp bulbs Ð that can be replaced
without tools.
*
[SV00900(BEF )05/94]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedule and Record
booklet.
*
[SV01000( ALL)01/95]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[SV01100( ALL)02/95]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[SV01300( ALL)03/95]
Ford Motor Company recommends that the
Owner Maintenance Checks listed in the
Maintenance Schedule and Recordbooklet be
performed for the proper operation of your
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

280vehicle. In addition to the conditions listed in
theOwner Maintenance Checklist, be alert for any
unusual noise, vibration, or other indication that
your vehicle may need service. If you do notice
something unusual, see that your vehicle is
serviced promptly.
*
[SV01600( ALL)06/95]
Precautions When Servicing Your
Vehicle
*
[SV01700( ALL)06/95]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
*
[SV01900( ALL)06/95]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
*
[SV02000( ALL)06/95]
q
Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
*
[SV02100( ALL)06/95]
q
Never get under a vehicle while it is
supported by a jack only. If you must work
under a vehicle, use safety stands.
*
[SV02200( ALL)06/95]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[SV02500( ALL)03/95]
If you disconnect the battery, the engine must
ªrelearnº its idle conditions before your vehicle
will drive properly. To find out how the engine
does this, seeBatteryin this chapter.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

281
*
[SV02600( ALL)03/95]
Working with the engine off:
*
[SV02650( E M)03/95]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park).
[SV02700( ALL)06/95]
2. Remove the key from the ignition after you
turn the engine off.
[SV02725( ALL)06/95]
3. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[SV02750( ALL)03/95]
Working with the engine on:
*
[SV02785( E M)03/95]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park).
*
[SV02795( E M)03/95]
2. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[SV02900( ALL)02/95]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
*
[SV02950(BEF )03/95]
Opening the Hood
[SV03025( E )05/89]
1. Pull the hood release handle, located on the
left kick panel near the parking brake release
handle.
*
[SV03050(BEF )12/91]
2. While applying downward pressure on the
hood, push the hood latch handle located
behind the grille near the center front of the
vehicle to the left.
*
[SV03100( E )08/94]
3. Disconnect the hood support from the
retaining clip on the radiator support and
place it into the slot marked PROP in the
underside of the hood.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996
