MOTORCRAFT PART NUMBERS
Component Engine application
4.2L 4.6L 5.4L 6.8L
Spark plug AWSF-42EE AWSF-32PP AWSF-22E AWSF-22E
Air filter FA-1632 FA-1632 FA-1632 FA-1632
Oil filter FL-400-S FL-820-S FL-820-S FL-820-S
Fuel filter FG-872 FG-872 FG-872 FG-872
Battery
Standard BXT-65-650 BXT-65-650 BXT-65-650 BXT-65-650
Optional BXT-65-750 BXT-65-750 BXT-65-750 BXT-65-750
Auxiliary BH-65DC BH-65DC BH-65DC BH-65DC
P.C.V. valve EV-152 EV-233 EV-233 EV-233
REFILL CAPACITIES
Fluid Application Capacity
Engine oil (includes
filter change)4.2L engine 5.7L (6.0 qts.)
4.6L engine 5.7L (6.0 qts.)
5.4L engine 5.7L (6.0 qts.)
6.8L engine 5.7L (6.0 qts.)
Engine coolant 4.2L engine 22.0L (23.2 qts.)
4.6L engine 23.7L (25.0 qts.)
5.4L engine 27.4L (29.0 qts.)
6.8L engine 29.0L (30.6 qts.)
Rear axle Ford 8.8º/9.75º
conventional and
Traction-Lok2.6L (5.5 pints)
1
Dana 9.75º (M60-IU) 3.0L (6.3 pints)2
Dana 10.5º (M70-2U) 3.1L (6.6 pints)2
Dana 10.5º M70-1HD) 3.5L (7.5 pints)2
Dana 11.25º (model
80)3.5L (7.5 pints)2
eco_motorcraft_part_numbers
eco_refill_capacities
Capacities and specifications
173

Air bag supplemental restraint
system ..........................................52
and child safety seats ..............54
description ................................52
disposal ......................................58
indicator light ...........................57
passenger air bag .....................55
Audio system (see Electronic
sound system) .............................17
Battery .......................................144
servicing ..................................145
Brakes
adjustment ................................80
anti-lock .....................................80
fluid, checking and adding ....134
parking ......................................80
Brake-shift interlock ...................85
Break-in period .............................4
Bulbs, replacing ........................165
headlamps ...............................166
specifications ..........................167
Cleaning your vehicle ...............168
engine compartment ..............170
fabric ........................................172
instrument panel ....................172
plastic parts ............................171
safety belts ..............................172
tail lamps .................................171
washing ....................................168
waxing .....................................169
wheels ......................................170
Climate control system ..............17
Controls
steering column ........................23
Coolant (see Engine coolant)
proper solution .......................137
Driveline universal joint and
slip yoke ....................................144
Driving under special
conditionsheavy load .................................86
Emission control system ..........162
emissions warranty .................163
Engine ........................................178
check engine temperature
warning, message center .......129
Engine block heater ...................77
Engine coolant
checking and adding ..............136
checking hoses .......................138
Engine oil
changing oil and oil filter .......133
specifications ..........................130
Entry system
illumination ...............................36
Exhaust fumes ............................78
Fail safe cooling ........................139
Flashing the lights ......................27
Fuel ............................................157
calculating fuel economy .......161
improving fuel economy ..........99
octane rating ...........................160
quality ......................................160
safety information relating to
automotive fuels .....................157
Fuel pump shut-off switch .......100
Fuse panels
instrument panel ....................104
power distribution box ...........108
Fuses ..........................................102
Gauges, Mechanical ....................11
engine coolant temperature
gauge .........................................12
engine oil pressure gauge ........13
fuel gauge ..................................12
Gearshift ......................................24
Hazard flashers ....................27,100
Headlamps
turning on and off ....................15
Hood ..........................................128
Index
183
