compression ratio FORD E SERIES 1997 4.G Owners Manual

complete refill of Dana
Traction-Lok rear axles.
ENGINE DATA
4.2L ENGINE
Displacement 4.2L (256 cid) V6
Bore X Stroke 96.8 x 95.0 mm (3.81 x 3.74 in.)
Induction Sequential multi-port fuel injection
Ignition Electronic distributorless ignition system
(EDIS)
Firing order 1-4-2-5-3-6
Spark plug gap 1.37 mm (.054 in.)
Compression ratio 9.2:1
4.6L ENGINE
Displacement 4.6L (281 cid) V8
Bore X Stroke 90.2 x 90.0 mm (3.55 x 3.55 in.)
Induction Sequential multi-port fuel injection
Ignition Electronic distributorless ignition system
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.37 mm (.054 in.)
Compression ratio 9.0:1
5.4L ENGINE
Displacement 5.4L (330 cid) V8
Bore X Stroke 90.2 x 105.8 mm (3.55 x 4.17 in.)
Induction Sequential multi-port fuel injection
Ignition Coil on plug
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.37 mm (.054 in.)
Compression ratio 9.0:1
eco_engine_data
eco_engine_data_4.2
eco_engine_data_4.6
eco_engine_data_5.4
Capacities and specifications
177

6.8L ENGINE
Displacement 6.8L (415 cid) V10
Bore X Stroke 90.2 x 105.8 mm (3.55 x 4.17 in.)
Induction Sequential multi-port fuel injection
Ignition Coil on plug
Firing order 1-6-5-10-2-7-3-8-4-9
Spark plug gap 1.37 mm (.054 in.)
Compression ratio 9.0:1
eco_engine_data_6.8
Capacities and specifications
178
