separation in the metal wire inside
the fuse.
Always replace a fuse with
one that has the specified
amperage rating. Using a fuse
with a higher amperage rating
can cause severe wire damage
and could start a fire.
Even after a fuse is replaced, it
will continue to blow if the cause
of the overload is not identified
and corrected. If a fuse continues
to blow, have the vehicle's
electrical system checked.
Standard fuse amperage rating
and color
Fuse rating Color
3 amp Violet
4 amp Pink
5 amp Beige
10 amp Red
15 amp Blue
20 amp Yellow
25 amp Natural
30 amp Light Green
High current fuse amperage
rating and color
Fuse rating Color
30 amp Light Green
40 amp Amber
50 amp Red
60 amp Blue
eco_fuse_id-chart
eco_fuse_id-chart2
Roadside emergencies
103
