Safety belt buckle pretensioner
Your vehicle is equipped with
safety belt buckle pretensioners at
the driver and front passenger
seating positions.
The safety belt buckle pretensioner
is a device which removes excess
webbing from the safety belt
system. The safety belt buckle
pretensioner uses the same crash
sensor system as the air bag
supplemental restraint system
(SRS). When the safety belt buckle
pretensioner deploys, the buckle
moves downward, pulling excess
webbing from the lap and shoulder
safety belt.
Combination lap and shoulder
belts
To fasten the safety belt, insert the
tongue into the slot in the buckle.
To disconnect the safety belt at:
²front seating positions, push the
red release button on the end of
eco_comb_shoulder-belts
Seating and safety restraints
45

²one or more impact and safing
sensors,
²a readiness light and tone,
²driver and front passenger
safety belt buckle pretensioners
²and the electrical wiring which
connects the components.
The diagnostic module monitors its
own internal circuits and the
supplemental air bag electrical
system readiness (including the
impact sensors), the system wiring,
the air bag system readiness light,
the air bag back up power and the
air bag ignitors.
Determining if the system is
operational
The SRS uses a readiness light in
the instrument cluster or a tone to
indicate the condition of the
system. Refer to theAir bag
readinesssection in the
Instrumentationchapter. Routine
maintenance of the air bag is not
required.
A difficulty with the system is
indicated by one or more of the
following:
²The readiness light will either
flash or stay lit.
²The readiness light will not
illuminate immediately after
ignition is turned on.
²A group of five beeps will be
heard. The tone pattern will
repeat periodically until the
problem and light are repaired.
com_determing_operational.01
Seating and safety restraints
57

Number Fuse amperage
ratingCircuits protected
8 30 amp Noise supression
capacitor, ignition coil
positive feed, PCM
relay diode/PCM
power relay, fuel
heater (diesel), glow
plug relay (diesel)
9 30 amp Wiper control module,
wiper motor
10 20 amp Headlamp switch
(exterior lamps),
Multi-function switch
(flash-to-pass)
11 15 amp Stoplight switch, brake
pressure switch,
multi-function switch
12 15 amp Digital transmission
range sensor (backup
lamps), auxiliary
battery relay
13 15 amp A/C mode switch,
blend door actuator
14 5 amp Instrument cluster (air
bag and charge
indicator lamps)
15 5 amp Trailer tow battery
charge relay (coil)
16 30 amp Power seats
17 - Not used
18 - Not used
19 10 amp Air bag module
20 5 amp Overdrive cancel
switch
Roadside emergencies
106

Number Fuse amperage
ratingCircuits protected
21 30 amp Power windows
22 - Not used
23 20 amp Cigar lighter, data link
connector
24 5 amp Illuminated entry
25 10 amp Left headlamp (low
beam)
26 - Not used
27 - Not used
28 25 amp Instrument panel
power point
29 - Not used
30 15 amp Headlamps (high
beam), Daytime
running lamps (DRL),
high beam indicator
31 10 amp Right headlamp (low
beam), Daytime
running lamps (DRL)
32 - Not used
33 - Not used
34 10 amp Digital transmission
range sensor (start
control)
35 - Not used
36 5 amp Panel illumination
37 - Not used
38 10 amp Air bag module
39 - Not used
40 30 amp Modified vehicle
41 30 amp Modified vehicle
42 - Not used
Roadside emergencies
107
