VEHICLE DIMENSIONS
Van/wagon models
E-150 E-250 E-350
1 = Overall
height2054.8 mm
(80.9 in.)2118.4 mm
(83.4 in.)2136.1 mm
(84.1 in.)
2 = Track
front/rear1762.8 mm (69.4 in.)/1701.8 mm (67.0 in.)
3 = Overall
width (excluding
mirrors)2014.2 mm (79.3 in.)
4 = Wheelbase 3505 mm (138 in.)
5 = Overall
lengthRegular van, 5379.7 mm (211.8 in.)
Super van, 5892.8 mm (232.0 in.)
3
2
1
5 4
eco_dimensions_van
Capacities and specifications
179

Cutaway/commercial stripped
chassis models
E-250 E-350 E-Super Duty
1 = Overall
heightRefer to Body Builder for specifications.
2 = Track
front/rear1762.8 mm
(69.4 in.)/1701.8
mm (67.0 in.)1762.8 mm
(69.4 in.)/SRW
1701.8 mm
(67.0 in.), DRW
1859.3 mm
(73.2 in.)1762.8 mm
(69.4 in.)/1973.6
mm (77.7 in.)
3 = Overall
width (excluding
mirrors)Refer to Body Builder for specifications.
4 = Wheelbase 3149.6 mm
(124 in.)3505 mm
(138 in.)
4013 mm
(158 in.)
4470 mm
(176 in.)4013 mm
(158 in.)
4470 mm
(176 in.)
5 = Overall
lengthRefer to Body Builder for specifications.
VEHICLE IDENTIFICATION
NUMBER
Complete Ford built vehicles
The vehicle identification number
is attached to your vehicle in the
following places:
²On the metal tag attached to the
top of the instrument panel on
the driver's side.
eco_dimensions_stripped
eco_vin
eco_vin_complete_vehicle
Capacities and specifications
