²hazard flasher
The overview of your vehicle's
exterior lamps shows the tail lamp/
backup lamp assembly for the
sedan model only. The lamp
assembly for the wagon is similar,
although the bulb replacement
process differs. For more
information, seeTail lamps/
Backup lampsin this section. In
addition, the headlamp assembly
includes the headlamp and the
turn signal/parking lamp
assemblies
Do not remove lamp bulbs unless
they may be replaced immediately
with new ones. If a bulb is
removed for an extended period of
time, contaminants may enter the
lamp housings and affect
performance.
Handle a halogen bulb
carefully and keep out of
children's reach. Grasp the bulb
only by its plastic base and do
not touch the glass; the oil from
your hand could cause the bulb
to break the next time that the
headlamps are operated.
Maintenance and care
161

BULB SPECIFICATIONS
Function Number of
bulbsTrade number
Exterior illumination
Front park/turn lamps 2 3457
Foglamps (if equipped) 2 881
Headlamps Ð aero high and low
beam2 9007
Rear license plate lamp 2 168
High-mount brakelamp 1 921
Notchback Ð Backup lamp 2 3156
Notchback Ð Brakelamp 2 3157
Notchback Ð Rear/turn/side
marker2 3157
Liftgate wagon rear side marker
lamp2
(1 each side)168
Interior illumination
Cargo lamp liftgate (wagon) 1 12V/5W
Interior overhead lamp 2 12V/10W
Luggage compartment lamp (if
equipped)15W
PRNDL illumination 1 197
Heater control nomenclature 1 14V/3.0
High beam indicator 1 W
Instrument panel gauge (cluster) 4 194
Sport cluster w/ tachometer 2 194
Turn signal indicator 1 194
Upshift indicator (if equipped) (1 each) 194
Warning lights Ð all 194
Maintenance and care
172

head restraints ..........................54
split-folding rear seat ...............54
Servicing your vehicle
precautions when servicing ...124
servicing when you tow .........105
Special driving conditions ..........89
Specification chart, lubricants .180
Speed control ..............................27
Starting your vehicle ..................88
preparing to start your
vehicle .......................................86
starting a cold engine ..............89
starting a warm engine ............89
Steering wheel
tilting .........................................29
Tail lamps
bulb replacement .............167,168
Tilt steering wheel ......................29
Tire types ..................................152
Tires ...........................................148
changing ..................................114
checking the pressure ............150
replacing ..................................151
rotating ....................................151
snow tires and chains ............152
tire grades ...............................148
treadwear ................................148
Trailer towing ............................102
safety chains ...........................104
tips ...........................................105
trailer brakes ...........................104
trailer lamps ............................104
Transaxle .....................................96
fluid, checking and adding
(automatic) .............................139
Turn signal
indicator lights ............................9
Upshift indicator light ...........8,100
Upshift speeds ..........................100
Vehicle dimensions ...................182
Vehicle headlamp aiming
device (VHAD) .........................173Vehicle Identification Number
(VIN) ..........................................185
Ventilating your vehicle (see
Climate control) ................18,19,23
Warning chimes ...........................10
headlamps on ............................11
key in ignition ...........................11
safety belt .................................10
Washer fluid ..............................134
reservoir ..................................135
windshield .................................30
Windows
one-touch down ........................35
power windows, operating .......34
Windshield
washing ......................................30
Windshield washer fluid and
wipers
checking and adding fluid .....134
checking and replacing wiper
blades ......................................146
liftgate reservoir .....................135
operation ...................................30
Wrecker towing .........................123
