snow chains FORD ESCORT 1999 6.G Owners Manual

Downloaded from www.Manualslib.com manuals search engine Failure to follow these precautions may adversely affect the
handling of the vehicle and make it easier for the driver to lose
control and roll over.
Tires that are larger or smaller than your vehicle's original tires may also
affect the accuracy of your speedometer.
SNOW TIRES AND CHAINS
Snow tires must be the same size and grade as the tires you
currently have on your vehicle.
The tires on your vehicle have all weather treads to provide traction in
rain and snow. However, in some climates, you may need to use snow
tires and chains. If you need to use snow tires and chains, it is
recommended that steel wheels are used of the same size and
specifications as those originally installed.
Follow these guidelines when using snow tires and chains:
²Do not use tire chains on aluminum wheels. Chains may chip the
wheels.
²Use only SAE Class S chains.
²Install chains securely, verifying that the chains do not touch any
wiring, brake lines or fuel lines.
²Drive cautiously. If you hear the chains rub or bang against your
vehicle, stop and re-tighten the chains. If this does not work, remove
the chains to prevent damage to your vehicle.
²If possible, avoid fully loading your vehicle.
²Do not use tire chains with 38 cm (15 inch) wheel/tire options. Using
chains on this size tire may cause damage to steering, suspension
and/or body components.
²Remove the tire chains when they are no longer needed. Do not use
tire chains on dry roads.
²The suspension insulation and bumpers will help prevent vehicle
damage. Do not remove these components from your vehicle when
using snow tires and chains.
Maintenance and care
151

Downloaded from www.Manualslib.com manuals search engine illuminated entry ......................58
locking/unlocking doors ......55,56
opening the trunk .....................56
panic alarm ...............................57
replacement/additional
transmitters ...............................58
replacing the batteries .............57
Roof rack ...................................104
Safety belts (see Safety
restraints) ................10,65,66,67,68
Safety Compliance
Certification Label ....................180
Safety defects, reporting ..........193
Safety restraints ...........65,66,67,68
cleaning the safety belts ...70,173
extension assembly ..................69
for adults ..............................66,67
for children ..........................75,76
lap belt ......................................68
warning light
and chime .....................8,10,69,70
Safety seats for children ............77
Seat belts
(see Safety restraints) ...............65
Seats ............................................61
child safety seats ......................77
cleaning ...................................173
Servicing your vehicle ..............123
Spark plugs,
specifications ...............174,176,177
Specification chart,
lubricants ............................175,176
Speed control ..............................44
Speedometer ...............................13
Starting your vehicle .............83,86
jump starting ..........................117
Steering wheel
tilting .........................................48
Tachometer .................................13
Tilt steering wheel ......................48
Tires .............................113,148,149changing ...........................113,114
checking the pressure ............149
replacing ..................................150
rotating ....................................149
snow tires and chains ............151
tire grades ...............................149
treadwear ................................148
Towing
wrecker ....................................122
Transaxle .....................................92
automatic operation .................95
fluid, refill capacities ..............174
lubricant specifications ..........176
manual operation ......................92
Transmission
fluid, checking and adding
(automatic) .............................141
fluid, checking and adding
(manual) .................................143
Trip odometer .............................13
Trunk
remote release .....................15,56
Turn signal ...............................9,43
Vehicle dimensions ...................177
Vehicle Identification Number
(VIN) ..........................................180
Vehicle loading ..........................100
Ventilating your vehicle .............88
Warning chimes ...........................10
Warning lights (see Lights) .........6
Washer fluid ..............................136
Water, Driving through .............102
Windows
power .........................................53
rear wiper/washer .....................50
Windshield washer fluid and
wipers
checking and cleaning ............147
operation ...................................49
replacing wiper blades ...........147
Wrecker towing .........................122
Index
197
