Page 102 of 200
Downloaded from www.Manualslib.com manuals search engine You may add equipment throughout your vehicle if the total weight
added is equal to or less than the Total Axle Reserve Capacity (TARC)
weight. You should NEVER exceed the Total Axle Reserve Capacity.
Always ensure that the weight of passengers, cargo and equipment being
carried is within the weight limitations that have been established for
your vehicle including both Gross Vehicle Weight and Front and Rear
Gross Axle Weight Rating limits. Under no circumstance should these
limitations be exceeded. Exceeding any vehicle weight rating limitation
could result in serious damage to the vehicle and/or personal injury.
DRIVING THROUGH WATER
Do not drive quickly through standing water, especially if the depth is
unknown. Traction or brake capability may be limited and if the ignition
system gets wet, your engine may stall. Water may also enter your
engine's air intake and severely damage your engine.
If driving through deep or standing water is unavoidable, proceed very
slowly. Never drive through water that is higher than the bottom of the
hubs.
Once through the water, always try the brakes. Wet brakes do not stop
the vehicle as effectively as dry brakes. Drying can be improved by
moving your vehicle slowly while applying light pressure on the brake
pedal.
Driving through deep water where the transmission is submerged
may allow water into the transmission and cause internal
transmission damage.
TRAILER TOWING
Your vehicle is capable of towing a trailer up to 454 kg (1 000 lbs.) gross
trailer weight with a maximum tongue load of 45 kg (100 lbs.). Do not
tow a trailer until your vehicle has been driven at least 800 km
(500 miles).
Towing a trailer places an additional load on your vehicle's engine,
transaxle, brakes, tires and suspension. Inspect these components
carefully after towing.
Do not exceed the GVWR or the GAWR specified on the
certification label.
Driving
102
Page 149 of 200
Downloaded from www.Manualslib.com manuals search engine Temperature A B C
The temperature grades are A (the highest), B, and C, representing the
tire's resistance to the generation of heat and its ability to dissipate heat
when tested under controlled conditions on a specified indoor laboratory
test wheel. Sustained high temperature can cause the material of the tire
to degenerate and reduce tire life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to a level of performance
which all passenger car tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the minimum required by
law.
The temperature grade for this tire is established for a tire that
is properly inflated and not overloaded. Excessive speed,
underinflation, or excessive loading, either separately or in
combination, can cause heat buildup and possible tire failure.
SERVICING YOUR TIRES
Checking the tire pressure
²Use an accurate tire pressure gauge.
²Check the tire pressure when tires are cold, after the vehicle has
been parked for at least one hour or has been driven less than 5 km
(3 miles).
²Adjust tire pressure to recommended specifications found on the
Certification Label.
Improperly inflated tires can affect vehicle handling and can fail
suddenly, possibly resulting in loss of vehicle control.
Tire rotation
Because your vehicle's tires perform different jobs, they often wear
differently. To make sure your tires wear evenly and last longer, rotate
them as indicated in the Scheduled Maintenance Guide. If you notice
that the tires wear unevenly, have them checked.
Maintenance and care
149
Page 180 of 200
Downloaded from www.Manualslib.com manuals search engine IDENTIFYING YOUR VEHICLE
Certification label
The National Highway Traffic Safety
Administration Regulations require
that a Certification Label be affixed
to a vehicle and prescribe where the
Certification Label may be located.
The Certification Label is located on
the front door latch pillar on the
driver's side.
Vehicle identification number
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel.
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block and transmission.
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
XXXXXXXXXXXXXXXXX
AIR BAG
Capacities and specifications
180
Page 197 of 200
Downloaded from www.Manualslib.com manuals search engine illuminated entry ......................58
locking/unlocking doors ......55,56
opening the trunk .....................56
panic alarm ...............................57
replacement/additional
transmitters ...............................58
replacing the batteries .............57
Roof rack ...................................104
Safety belts (see Safety
restraints) ................10,65,66,67,68
Safety Compliance
Certification Label ....................180
Safety defects, reporting ..........193
Safety restraints ...........65,66,67,68
cleaning the safety belts ...70,173
extension assembly ..................69
for adults ..............................66,67
for children ..........................75,76
lap belt ......................................68
warning light
and chime .....................8,10,69,70
Safety seats for children ............77
Seat belts
(see Safety restraints) ...............65
Seats ............................................61
child safety seats ......................77
cleaning ...................................173
Servicing your vehicle ..............123
Spark plugs,
specifications ...............174,176,177
Specification chart,
lubricants ............................175,176
Speed control ..............................44
Speedometer ...............................13
Starting your vehicle .............83,86
jump starting ..........................117
Steering wheel
tilting .........................................48
Tachometer .................................13
Tilt steering wheel ......................48
Tires .............................113,148,149changing ...........................113,114
checking the pressure ............149
replacing ..................................150
rotating ....................................149
snow tires and chains ............151
tire grades ...............................149
treadwear ................................148
Towing
wrecker ....................................122
Transaxle .....................................92
automatic operation .................95
fluid, refill capacities ..............174
lubricant specifications ..........176
manual operation ......................92
Transmission
fluid, checking and adding
(automatic) .............................141
fluid, checking and adding
(manual) .................................143
Trip odometer .............................13
Trunk
remote release .....................15,56
Turn signal ...............................9,43
Vehicle dimensions ...................177
Vehicle Identification Number
(VIN) ..........................................180
Vehicle loading ..........................100
Ventilating your vehicle .............88
Warning chimes ...........................10
Warning lights (see Lights) .........6
Washer fluid ..............................136
Water, Driving through .............102
Windows
power .........................................53
rear wiper/washer .....................50
Windshield washer fluid and
wipers
checking and cleaning ............147
operation ...................................49
replacing wiper blades ...........147
Wrecker towing .........................122
Index
197
Page 200 of 200
Downloaded from www.Manualslib.com manuals search engine Item Information
Required fuel Unleaded fuel only - 87 octane
Fuel tank capacity 48.5L (12.8 gallons)
Tire size and pressure Refer to the Certification Label
inside of driver's door.
Hood release Pull handle under the left side of
the instrument panel.
Oil capacity (includes filter
change)Sedan/wagon-3.8L (4.0 quarts)
ZX2-4.25L (4.5 quarts)
Engine oil Use Motorcraft 5W30 Super
Premium Motor Oil, Ford
specification WSS-M2C153-G
Coolant capacity
1Automatic transaxle-6.0L (6.3
quarts)
Manual transaxle-5.0L (5.3 quarts)
Power steering fluid capacity Fill to line on reservoir.
Automatic transaxle capacity 3.9L (4.1 quarts)
Manual transaxle capacity 3.35L (3.55 quarts)
1Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford
Extended Life Engine Coolant (orange in color). Refer toAdding engine
coolant, in the Maintenance and Care chapter.
Filling station information
200
