26. Remove the A/C line bracket bolt.
27. Disconnect the A/C manifold and tube spring lock coupling at the accumulator/drier. For additional information, refer to
Section 412-03.
28. Disconnect the A/C manifold and tube spring lock coupling at the condenser. For additional information, refer to
Section 412-03.
29. Remove the accessory drive belt, the auto tensio ner and, if vehicle is equipped with A/C, the accessory drive belt idler. For additional information, refer to
Section 303-05.
30. Suction out the power steering fluid from the po wer steering reservoir.
31. NOTE: Position a drain pan under the power steering reser voir.
Disconnect the power steering lines.
Loosen the clamp and disconnect the (A) power steer ing reservoir pump hose (3691) at the reservoir. Disconnect the (B) power steering pressure hose (3A719).
32. Raise and support the vehicle. For additional in formation, refer to
Section 100-02.
33. Remove the (A) wheel nuts (1012) and the (B) fro nt wheel and tire assemblies.
102001 Escort Workshop Manual
6/27/2010http://www.fordtechservice.dealerconnection.com/pub s/content/~WS1F/~MUS~LEN/19/S...
Page 6 of 10
Downloaded from www.Manualslib.com manuals search engine
34. Remove the LH splash shields. 1. Remove the six bolts.
2. Remove the LH splash shields.
35. Remove the (A) six bolts and remove the (B) RH s plash shields.
36. Drain the engine coolant system. For additional information, refer to
Section 303-03.
37. Drain the engine oil.
38. Remove the (A) bolts and the (B) crossmember.
39. Remove the bolts for the three way catalytic con verter (TWC) (5E212).
