KEYS
The key operates all locks on your vehicle. In case of loss, replacement
keys are available fromyour dealer.
You should always carry a second key with you in a safe place in case
you require it in an emergency.
POWER DOOR LOCKS (IF EQUIPPED)
Press U to unlock all doors and L to
lock all doors.
INTERIOR LUGGAGE COMPARTMENT RELEASE
Your vehicle is equipped with a mechanical interior luggage compartment
release handle that provides a means of escape for children and adults in
the event they become locked inside the luggage compartment.
Adults are advised to familiarize themselves with the operation and
location of the release handle.
UL
Locks and Security
51

To open the luggage compartment
door (lid) fromwithin the luggage
compartment, pull the illuminated
“T” shaped handle and push up on
the trunk lid. The handle is
composed of a material that will
glow for hours in darkness following
brief exposure to ambient light.
The “T” shaped handle will be
located either on the luggage
compartment door (lid) or inside
the luggage compartment near the
tail lamps.
Keep vehicle doors and
luggage compartment
locked and keep keys and remote
transmitters out of a child’s reach.
Unsupervised children could lock
themselves in the trunk and risk
injury. Children should be taught
not to play in vehicles.
On hot days, the temperature in the trunk or vehicle interior can
rise very quickly. Exposure of people or animals to these high
temperatures for even a short time can cause death or serious
heat-related injuries, including brain damage. Small children are
particularly at risk.
REMOTE ENTRY SYSTEM (IF EQUIPPED)
This device complies with part 15 of the FCC rules and with RS-210 of
Industry Canada. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that may
cause undesired operation.
Locks and Security
52

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
Your vehicle may have an all-door remote entry system or a driver’s door
only remote entry system.
The all-door remote entry system
allows you to:
•lock or unlock all vehicle doors
without a key.
•armand disarmthe anti-theft
system. (For more information on
the anti-theft system, refer to
Anti-theft systemin this
chapter.)
•open the trunk.
•activate the panic alarm.
The driver’s door only entry systemallows you to:
•lock the driver’s door
•unlock the driver’s door only without a key.
•activate the panic alarm.
•open the trunk
The remote entry features only operate with the ignition in the LOCK
position.
If there is any potential remote keyless entry problem with your vehicle,
ensureALL remote entry transmittersare brought to the dealership,
to aid in troubleshooting.
Unlocking the doors
1. Pressand release to unlock the driver’s door.Note:The interior
lamps will illuminate.
2. With the all-door remote entry, press
and release again within
three seconds to unlock all the doors.
The remote entry system activates the illuminated entry feature. This
feature turns on the interior lamps for 20 seconds or until the ignition is
turned to the ON position. The dome lamp control must be set to the
DOORposition in order for the illuminated entry feature to operate.
Locks and Security
53

Locking the doors
1. Pressand release to lock all the doors. On vehicles equipped with
the driver’s door only remote entry system, only the driver’s door will
lock.Note:the interior lamps will turn off.
2. On vehicles with the all-door remote entry, press
and release again
within three seconds to confirmthat all the doors are closed and locked.
Note:the doors will lock again, the horn will chirp once and the
headlamps will flash.
If any of the doors are not properly closed the horn will make two quick
chirps.
This process will also activate the vehicle’s anti-theft system(if
equipped). For more information on arming the anti-theft system, refer
toAnti-theft systemin this chapter.
Opening the trunk
Pressonce to open the trunk.
•Ensure that the trunk is closed and latched before driving your
vehicle. Failure to properly latch the trunk may cause objects to fall
out or block the driver’s rear view.
Sounding a panic alarm
Press
to activate the alarm. Press again or turn the ignition to ACC
or ON to deactivate.
Note:The panic alarmwill only operate when the ignition is in the OFF
position.
Replacing the battery
The remote entry transmitter uses one coin type three-volt lithium
battery CR2032 or equivalent. The typical operating range for your
remote entry transmitter is approximately 10 meters (33 feet). A
decrease in the operating range could be caused by:
•weather conditions,
•nearby radio towers,
•structures around the vehicle and
•other vehicles parked next to the vehicle.
Locks and Security
54

To replace the battery:
1. Twist a thin coin between the two
halves of the remote entry
transmitter near the key ring. DO
NOT TAKE THE FRONT PART OF
THE REMOTE ENTRY
TRANSMITTER APART.
2. Remove the old battery.
3. Insert the new battery. Refer to
the diagraminside the remote entry
transmitter for the correct orientation of the battery.
4. Snap the two halves back together.
Note:Replacement of the battery willnotcause the remote transmitter
to become deprogrammed from your vehicle. The remote transmitter
should operate normally after battery replacement.
Replacing lost remote entry transmitters
If you would like to have your remote entry transmitter reprogrammed
because you lost one, or would like to buy additional remote entry
transmitters, you can either reprogram them yourself, or takeall
remote entry transmittersto your authorized dealer for
reprogramming.
How to reprogram your remote entry transmitters
You must haveall remote entry transmitters(maximum of four)
available before beginning this procedure.
To reprogramthe remote entry
transmitters:
1. Ensure the vehicle is electronically unlocked.
2. Put the key in the ignition.
3. Turn the key fromthe 1 (LOCK) position to 2 (ACC).
LOCKACCONSTART0IIIIII4
3
2
1
Locks and Security
55

4. Cycle, eight times, rapidly (within 10 seconds) between the 2 (ACC)
position and 3 (ON).Note:The eighth turn must end in the 3 (ON)
position.
5. The doors will lock, then unlock, to confirm that the programming
mode has been activated.
6. Within 20 seconds press any button on the remote entry transmitter.
Note:If more than 20 seconds have passed you will need to start the
procedure over again.
7. The doors will lock, then unlock, to confirmthat this remote entry
transmitter has been programmed.
8. Repeat Step 6 to program each additional remote entry transmitter.
9. Turn the ignition to the 2 (ACC) position (or wait twenty seconds)
after you have finished programming all of the remote entry transmitters.
10. The doors will lock, then unlock, to confirm that the programming
mode has been exited.
ANTI-THEFT SYSTEM (IF EQUIPPED)
When activated, the anti-theft systemwill help prevent your vehicle from
unauthorized entry.
If there is any potential remote keyless entry problem with your vehicle,
ensureALL remote entry transmittersare brought to the dealership,
to aid in troubleshooting.
Activating the anti-theft system
Turn the ignition to the 1 (LOCK) position, remove the key and press
on the remote entry transmitter.
Identifying an activated system
While the systemis activating, theTHEFTindicator, located in the
instrument cluster, will illuminate for 30 seconds. After 30 seconds, the
indicator will flash, indicating the systemis activated.
If the systemis activated with the doors open, theTHEFTindicator will
remain illuminated until all the doors are closed, then illuminate for 30
seconds and begin flashing.
When an unauthorized entry occurs, the activated systemwill:
•flash the parking lamps and theTHEFTindicator, and
•sound the horn.
The flashing parking lamps and the honking horn automatically shut off
after approximately three minutes, and will remain off unless another
unauthorized entry is attempted.
Locks and Security
56

Deactivating the anti-theft system
Deactivating an untriggered anti-theft system
You can deactivate an untriggered anti-theft systemalarmin the
following ways:
•Press
on the remote entry transmitter.
•Press
on the remote entry transmitter.Note:Pressing the
trunk control will prevent the alarmfromsounding until the trunk is
closed again.
Note:Using the ignition key to unlock the doors or trunk will not disarm
the anti-theft system.
Deactivating a triggered anti-theft system
You can deactivate a triggered anti-theft systemalarmin the following
ways:
•Press
on the remote entry transmitter.
•Press
on the remote entry transmitter.
•Insert the key into the ignition and turn to the 2 (ACC) or 3 (ON)
positions.
Locks and Security
57

SEATING
Notes:
Reclining the seatback can cause an occupant to slide under the
seat’s safety belt, resulting in severe personal injuries in the
event of a collision.
Do not pile cargo higher than the seatbacks to reduce the risk of
injury in a collision or sudden stop.
Adjustable head restraints (if equipped)
Head restraints help to limit head motion in the event of a rear collision.
Adjust your head restraint so that it is located directly or as close as
possible behind your head.
The head restraints can be moved
up and down.
Push control to lower head restraint.
Adjusting the front manual seat
Never adjust the driver’s seat or seatback when the vehicle is
moving.
Seating and Safety Restraints
58

Always drive and ride with your seatback upright and the lap
belt snug and low across the hips.
Lift handle to move seat forward or
backward.
Pull lever up to adjust seatback.
FOLDING DOWN THE REAR SEATS
To fold the seatback down:
•Press the latch control downward
or pull up on strap and
•Pull the seatback forward and
down.
Seating and Safety Restraints
59

RETURNING THE SEAT TO THE UPRIGHT POSITION
Check to see that the seat and seatback is latched securely in
position. Keep floor area free of objects that would prevent
proper seat engagement. Never attempt to adjust the seat while the
vehicle is in motion.
To return the seat to the upright/normal seating position:
•Rotate seat upward and latch.
The full rear bench seat is shown. The split-folding rear seat (if
equipped) operates in a similar manner.
SAFETY RESTRAINTS
Safety restraints precautions
Always drive and ride with your seatback upright and the lap
belt snug and low across the hips.
To reduce the risk of injury, make sure children sit where they
can be properly restrained.
Never let a passenger hold a child on his or her lap while the
vehicle is moving. The passenger cannot protect the child from
injury in a collision.
All occupants of the vehicle, including the driver, should always
properly wear their safety belts, even when an air bag (SRS) is
provided.
It is extremely dangerous to ride in a cargo area, inside or
outside of a vehicle. In a collision, people riding in these areas
are more likely to be seriously injured or killed. Do not allow people to
ride in any area of your vehicle that is not equipped with seats and
safety belts. Be sure everyone in your vehicle is in a seat and using a
safety belt properly.
Seating and Safety Restraints
60
