battery replacement FORD EXCURSION 2000 1.G Owners Manual

To replace the battery:
1. Twist a thin coin between the two
halves of the transmitter near the
key ring. DO NOT TAKE THE
FRONT PART OF THE
TRANSMITTER APART.
2. Place the positive (+) side of new
battery in the same orientation.
Refer to the diagram inside the
transmitter unit.
3. Snap the two halves back
together.
Replacement of the battery willnotcause the remote transmitter to
become deprogrammed from your vehicle. The remote transmitter should
operate normally after battery replacement.
Illuminated entry
The illuminated entry system will turn on the interior lights when the
remote transmitter unlock control is pressed.
The illuminated entry system will turn off the interior lights if the
ignition switch is turned to the ON position, or if the remote transmitter
lock control is pressed, or after 25 seconds of illumination.
The inside lights will not turn off if:
²they have been turned on with the dimmer control or
²any door or liftgate is open.
The battery save feature will turn off the interior lights 45 minutes after
the last door is closed, even if the dimmer control is on.
Controls and features
67

12. Remove the jack and fully
tighten the lug nuts in the order
shown.
13. Stow the the flat tire, jack, jack
handle and lug wrench. Make sure
the jack is securely fastened so it
does not rattle when driving.
14. Unblock the wheels.
Retighten the lug nuts to the
specified torque at 800 km (500
miles) of operation after any wheel
change or any time the lug nuts are loosened.
Bolt Size Wheel Lug nut Torque*
Nm Lb-ft
1/2-20 135 100
9/16-18 190 140
M14 x 2.0 200 150
* Torque specifications are for nut and bolt threads free of dirt and
rust. Do not use oil or grease on threads. Use only Ford recommended
replacement fasteners.
JUMP STARTING YOUR VEHICLE
The gases around the battery can explode if exposed to flames,
sparks, or lit cigarettes. An explosion could result in injury or
vehicle damage.
Do not push start your vehicle. You could damage the catalytic
converter.
Batteries contain sulfuric acid which can burn skin, eyes, and
clothing, if contacted.
Do not attempt to push start your vehicle. Automatic
transmissions do not have push-start capability.
1
3 4
27 6
5 8
Roadside emergencies
151

A
Accessory delay ..........................53
Air bag supplemental
restraint system ..........................95
and child safety seats ..............97
description ................................95
disposal ......................................99
driver air bag ............................97
indicator light .....................11, 99
operation ...................................97
passenger air bag .....................97
Air cleaner filter .......177±178, 204
Air conditioning ..........................22
auxiliary heater and air
conditioner ................................24
Antifreeze
(see Engine coolant) ................165
Anti-lock brake system
(see Brakes) ......................112±113
Anti-theft system
warning light .............................13
Audio system (see Radio) .........27
Automatic transmission
driving an automatic
overdrive .................................116
fluid, adding ............................172
fluid, checking ........................172
fluid, refill capacities ..............204
fluid, specification ..................209
Auxiliary power point .................21
Axle
lubricant specifications ..207, 209
refill capacities ........................204
traction lok ..............................179B
Battery .......................................175
acid, treating emergencies .....175
charging system warning light...12
jumping a disabled battery ....151
maintenance-free ....................175
replacement, specifications ...204
servicing ..................................175
voltage gauge ............................17
Belt minder .................................91
Brakes ........................................112
anti-lock ...........................112±113
anti-lock brake system (ABS)
warning light .....................12, 113
brake warning light ..................11
fluid, checking and adding ....163
fluid, refill capacities ..............204
fluid, specifications .........207, 209
lubricant specifications ..207, 209
parking ....................................113
shift interlock ..........................115
Break-in period .............................3
C
Capacities for refilling fluids ....204
Cargo net .....................................73
CD changer .................................39
Certification Label ....................211
Child safety restraints ..............100
child safety belts ....................100
Child safety seats ......................101
attaching with tether straps ..105
in front seat ............................102
in rear seat ..............................102
Cleaning your vehicle ...............199
engine compartment ..............201
Index
225
