washer fluid FORD EXPEDITION 1997 1.G Owners Manual

Low washer fluid
Illuminates briefly when the
ignition is turned to On. Also
illuminates when the windshield
washer fluid is low.
Oil pressure
Illuminates briefly when the
ignition key is turned to On.
Illuminates when the oil pressure
is low. Stop the engine and check
the engine oil level as soon as
possible. Refer toChecking and
adding engine oilin the
Maintenance and caresection.
The oil pressure and engine
coolant warning lights share the
same lightbulb Ð if one of the
warning lights illuminates, they
both do.
Door ajar
Illuminates when the ignition
switch is in the ON or START
position and any door is open.
Charging system
Briefly illuminates when the
ignition is turned on and the
engine is off. The light also
illuminates when the battery is not
charging properly, requiring
electrical system service.
LOW
WASH
DOOR
AJAR
exd_oil_pressure_light
exd_door_ajar_light
exd_charging_system
com_brake_system.01
Instrumentation
9

Front washer
For front window washer fluid
operation, push (and hold as
desired) the front washer control
on the end of the stalk.
INT 2
INT 1
OFF
exd_title_rear_washer
Controls and features
45

3. Engine oil dipstick (For more
information on the engine oil
dipstick location and maintenance,
refer toChecking and adding
engine oilin this chapter.)
4. Brake fluid reservoir
5. Engine compartment fuse panel
6. Engine coolant reservoir
7. Air cleaner filter
8. Power steering fluid reservoir
9. Engine oil filler cap
10. Washer fluid reservoir
CHECKING AND ADDING
ENGINE OIL
Use WSS-M2C153±F motor oil
CERTIFIED FOR GASOLINE
ENGINES by the American
Petroleum Institute.
Engine oils with an SAE 5W-30
viscosity and displaying the
American Petroleum Institute
certification mark are preferred for
your vehicle. They provide the best
engine performance, fuel economy
and engine protection for all
climates down to ±25ÉC (-15ÉF).
Do not use:
²ªnon-detergentº oils
²oils labeled API SA, SB, SC, SD,
SE, SF or SG
²additional engine oil additives,
oil treatments or engine
treatments
Additional engine oil additives, oil
treatments or engine treatments
com_check-add_oil.01
Maintenance and care
159

²Clean the reservoir cap before
removal to prevent dirt or water
from entering the reservoir.
²Visually inspect the fluid level.
²If necessary, add brake fluid
until the level reaches MAX. Do
not fill above this line.
²Use only a DOT 3 brake fluid
certified to meet Ford
specifications. Refer to
Lubricant specificationsin the
Capacities and specifications
chapter.
Brake fluid is toxic.
If you use a brake fluid
that is not DOT 3, you will
cause permanent damage to your
brakes.
Do not let the reservoir for
the master cylinder run
dry. This may cause the brakes
to fail.
MAX
MIN
exd_washer-fluid
Maintenance and care
163

CHECKING AND ADDING
WASHER FLUID
Adding washer fluid
1. Lift the washer fluid reservoir
cover.
2. Add washer fluid until the level
reaches the FULL line.
Use only fluid that meets Ford
Specifications. Refer toCapacities
and specifications.
The addition of a bug shield to the
front of the vehicle may adversely
affect the washer system from
delivering fluid to the windshield.
Devices such as bug shields are
not recommended.
Windshield washer fluid
contains methanol and it is
poisonous. Follow all instructions
on the bottle of washer fluid.
What you should know about
washer fluid
In freezing weather [temperatures
below 0ÉC (32ÉF)], use washer
fluid containing a small amount of
antifreeze, such as methanol. State
or local regulations on volatile
organic compounds (VOCs) may
restrict the use of methanol, a
common type of antifreeze.
Use a non-methanol antifreeze in
freezing weather only if the fluid
does not damage the paint finish,
wiper blades and washer system.
WASHER FLUID
ONLY
exd_adding_washer
exd_washer_fluid_info
exd_liftgate_washer_fluid
Maintenance and care
164

Washer fluid in the liftgate
reservoir
Washer fluid for liftgate wiper and
washer operation is supplied by
the washer fluid reservoir located
in the engine compartment. For
information on adding fluid to this
main reservoir, refer toWasher
fluid in the windshield reservoir
in this chapter.
CHECKING AND ADDING
ENGINE COOLANT
Adding engine coolant
Do not put engine coolant
in the container for the
windshield washer fluid.
If sprayed on the windshield,
engine coolant could make it
difficult to see through the
windshield.
When the engine is cool, add a
50/50 mixture of engine coolant
and water to the engine coolant
recovery reservoir Ð DO NOT
ADD DIRECTLY TO THE
RADIATOR. Add straight water
only in an emergency, but you
should replace it with a 50/50
mixture of coolant and distilled
water as soon as possible.
COOLANT FILL
LEVEL
exd_coolant
exd_adding_coolant
Maintenance and care
165

Cleaning the wheels
Wash the wheels with the same
detergent you use to clean the
body of your vehicle. Do not use
acid-based wheel cleaners, steel
wool, fuel or strong detergents.
Never use abrasives that will
damage the finish of special wheel
surfaces. Use a tar remover to
remove grease and tar.
Cleaning the engine
Engines are more efficient when
they are clean because grease and
dirt buildup act as insulators and
keep the engine warmer than
normal. Follow these guidelines to
clean your engine:
²Take care when using a power
washer to clean the engine. The
high pressure fluid could
penetrate the sealed parts and
cause damage.
²Do not spray with cold water to
avoid cracking the engine block.
com_engine_cleaning.01
Maintenance and care
208

Refill capacities
Capacities - liters (quarts) 4.6 L engine 5.4 L engine
Engine crankcase 5.7 L (6.0
quarts) with filter
change5.7 L (6.0
quarts) with filter
change
Transfer case 1.9L (2.0 quarts)
Automatic transmission 4R70W-13.1L (13.9 quarts)
E4OD (4 x 2) - 15.04L (15.9
quarts)
E4OD (4 x 4) - 15.51L (16.4
quarts)
Washer fluid reservoir 4.1 L ( 4.5 quarts)
4.6 L Engine coolant-2Row
radiator
-1 Row radiator17.9 L (19.9 quarts)
17.0 L (18.0 quarts)
5.4 L Engine coolant 19.7 L (20.8 quarts)
Engine oil 5.7 L (6.0 quarts)
Power steering fluid 2.3 L (2.4 quarts)
Capacites - pints
Axle (rear)
Ford 8.89/ 9.759Ring Gear
Conventional and Traction-Lok
1
5.5 pints
Axle (front) Ford 8.89Ring Gear 3.5 pints
1Add 4 oz. of additive friction
modifier C8AZ-19B546±A, Ford
specification EST-M2C118±A, for
complete fill of 8.8 inch and 9.75
inch ring gear Traction-Lok axles.
Service refill capacities are
determined by filling the rear axle
1/4 inch to 9/16 below the bottom
of the filler hole.
exd_specifications
Capacities and specifications
214

SPECIFICATIONS
Lubricant specifications
Item Ford part nameFord part
numberFord
specification
Windshield
washer fluid
reservoirFord Ultra-Clear
Windshield
Washer Fluid
ConcentrateC9AZ-19550-AA
OR -BAESR-M17P5-A
Body hinges,
latches, door
striker plates
and rotors, seat
tracks, fuel filler
door hinge and
spring, hood
latch, auxiliary
latchMulti-Purpose
GreaseD7AZ-19584-AA
OR
D0AZ-19584-AAESR-M1C159-A
AND
ESB-M1C93-B
Lock cylinders,
swing-away
spare tire carrier
padlockPenetrating
LubricantE8AZ-19A501-B ESB-M2C75-B
Parking brake
linkage pivots
and clevisesPremium Life
Long GreaseXG-1-C ESA-M1C75-B
Brake master
cylinderHigh
Performance
DOT 3 Brake
FluidC6AZ-19542-AA ESZ-M6C25-A
Brake pedal
pivot points and
clevisesEngine Oil
SAE-10W- WSS-M2C153-F
exd_lubricant_specifications
Capacities and specifications
215

Trailer towing
calculating maximum trailer
weight ......................................127
Transfer case (see Differential
fluid) ...................................175,176
Transmission ......................114,172
Transmission control switch ......49
Trip odometer .............................17
Turn signal ..................................47
indicator lights ..........................12
Vehicle dimensions ...................218
Vehicle headlamp aiming
device (VHAD) .........................206
Ventilating your vehicle ...........105
Voltmeter (see Battery voltage
gauge) ..........................................16Warning chimes
headlamps on ............................14
key in ignition ...........................14
safety belt .................................13
Warning lights (see Lights) .8,144,
145
Windows
accessory delay .........................59
Windshield washer fluid and
wipers ........................................179
checking and adding fluid .....164
operation ..............................44,45
Wrecker towing .........................154
