window FORD EXPEDITION 1997 1.G Owners Manual

Rear window defroster
Press the defroster control to clear
the rear window of thin ice and
fog.
²The small LED will illuminate
when the defroster is activated.
The ignition must be in the ON
position to operate the rear
window defroster.
The defroster turns off
automatically after 10 minutes or
when the ignition is turned to the
OFF position. To manually turn off
the defroster before ten minutes
have passed, push the control
again.
P
exd_parking_brake_location
Controls and features
26

Air conditioning
Select A/C for air conditioned air
to flow through these vents:
The A/C mode directs outside air
conditioned air to flow through the
instrument panel vents. The A/C
mode can be used for heating,
ventilating and defogging the
windows or air conditioning. The
A/C system only functions if the
outside temperature is above 10ÉC
(50ÉF).
Select MAX A/C for air to flow
through these vents:
The MAX A/C mode recirculates
the cabin air and directs it to flow
through the instrument panel
vents. This mode is noisier but
more economical than the A/C
mode. The air conditioning system
only functions if the outside
temperature is above 10ÉC (50ÉF).
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
d
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
d
Controls and features
32

Front washer
For front window washer fluid
operation, push (and hold as
desired) the front washer control
on the end of the stalk.
INT 2
INT 1
OFF
exd_title_rear_washer
Controls and features
45

Rear window wiper/washer
controls
Rear washer
Rotate (and hold as desired) the
rear wiper/washer control to either
position.
From either position, the control
will automatically return to the
INT2 or OFF position.
Rear wipers
For rear wiper operation, rotate
the rear window wiper and washer
control to the desired position.
Select:
INT 2 Ð One second interval rear
wiper.
INT1ÐTensecond interval rear
wiper.
OFF Ð Rear wiper and washer off.
INT 2
INT 1
OFF
exd_washer_rear exd_rear_wiper
exd_highbeams_flashtopass
Controls and features
46

The front overhead console and
overhead controls provide a variety
of available features including:
²compass display
²trip computer
²overhead lamps
²storage compartment
²garage door opener stowage
²moon roof control
²auxiliary A/C controls
²power quarter window switches
The appearance of your vehicle's
overhead console will vary
according to your option package.
Compass display (if equipped)
The compass reading may be
affected when you drive near large
buildings, bridges, power lines and
powerful broadcast antenna.
Magnetic or metallic objects placed
in or on the vehicle may also affect
compass accuracy. Adjustments
may be made to the zone and
calibration of the compass.
WARMPANEL FLOOR COOL
REAR
OFF
HI
MODE E/M
VENT VENT
km TO EMPTY
exd_compass_temp_display
exd_zone_compass_adjust
Controls and features
51

²Place Velcroyhook onto back
side of aftermarket transmitter
opposite of actuator control.
²Place transmitter into storage
compartment, control down.
²Place the provided height
adaptors onto the back of the
storage bin door as needed.
²Press the storage compartment
door to activate the transmitter.
One-touch moon roof (if
equipped)
²Press and release the rear
portion of the moon roof control
to open.
²Press and hold (as desired) the
front portion of the moon roof
control to close.
²To halt motion at any point
during one-touch opening, press
the control a second time.
²The moon roof has a sliding
shade that can be manually
opened or closed when the glass
panel is shut.
²To close the shade, pull it
toward the front of the vehicle.
Do not let children play
with the moon roof. They
may seriously hurt themselves.
exd_moonroof
exd_power_quarter_window
Controls and features
56

Power quarter rear windows (if
equipped)
Press the
portion of the VENT
control to open the power rear
quarter windows.
Press the
portion of the VENT
control to close the power rear
quarter windows.
RESET
VENTVENT
MODE E/M
exd_title_door-mount
Controls and features
57

Power windows
DriverÐside window control
²Press rear of switch to open
window.
²Press front of switch to close
window.
The driverÐside power window
has a one-touch down feature.
When AUTO is fully pressed and
released (two clicks will be heard),
the driver-side window will move
completely down. This feature can
be cancelled by pressing the
driver-side power window switch
again.
UL
DOOR LOCK
AUTO
exd_driver_windows
exd_passenger_window_controls
Controls and features
58

Passenger-side window
controls
²Press rear of switches to open
passenger window.
²Press front of switches to close
passenger window.
Accessory delay
With accessory delay, the window
switches may be used for up to ten
minutes after the ignition switch is
turned to the Off position or until
either door is opened.
L
U
exd_acc_delay
exd_door_locks_power
Controls and features
59

Power mirrors
To adjust the power outside
mirrors:
1. Select the mirror you want to
adjust:
LDriver side mirror
RPassenger side mirror
2. Move the mirror control in the
desired direction.
3. Lock the mirror by moving the
control to the center position.
Heated outside mirrors (if
equipped)
Both mirrors are heated
automatically to remove ice, mist
and fog when the rear window
defrost is activated.
Do not remove ice from the
mirrors with a scraper or attempt
to readjust the mirror glass if it is
frozen in place. These actions
could cause damage to the glass
and mirrors.
Signal mirrors (if equipped)
If your vehicle is equipped with
signal mirrors, the word ªsignalº is
located at the top of the right and
left side view mirrors.
When the turn signal is activated,
the appropriate mirror will show a
blinking red arrow.
The arrow provides an additional
warning to other drivers that your
vehicle is about to turn. Driver and
passengers seated inside the
vehicle cannot see the arrow.
L MIRRORS
R
Signal
exd_heated_mirrors
exd_signal_mirrors
exd_liftgate_controls
Controls and features
61
