roof FORD EXPEDITION 2000 1.G Rear Seat Entertainment System Manual

VIDEO DISPLAY UNIT
The roof-mounted Video Display Unit is the most visible component of
your RSES. In essence, it is the ªnerve centerº of your system. In
addition to containing the flip-down LCD video screen, it contains many
of the system's main control buttons, important indicator lights, and
facilities to support both the wireless and optional wired headphones.
1.POWERbutton
Press this button to turn the RSES system On and Off alternately.
2.REMOTE CONTROL SENSOR
To operate the VCP with the remote control, aim it toward this location.
3.VOLUMEbuttons
Press (+) or (þ) button to decrease or increase audio volume through
thewiredheadphones.
Wired headphones are not supplied. Any headphones for portable
cassette and compact disc units can be used.
4.SELECTbutton
Press to select between AV1 and AV2.
POWER
BRIGHTNESS VOLUMESENSORSELECT
FREQUENCY
OFF 1 2AV 1 AV 2
54321
876
Description
10
