center console FORD EXPEDITION 2003 2.G Quick Reference Guide

*Refer to the minimum
configuration requirements located
on the back panel of the CD jacket.
3
Service Engine Soon Lamp
Illuminates briefly to ensure the
system is functional. If the light
comes on after the engine is
started, refer to your Owner’s Guide.
To help prevent activation, always secure
your fuel cap by turning it clockwise 1/8 of a
turn until it stops.
Please note that if the fuel cap is not properly
secured, the warning "Check Fuel Cap" will be
displayed on the optional message center. The
warning will be reset once the cap is properly
tightened and your vehicle is driven a short
distance. If your vehicle is not equipped with a
message center, the Service Engine Soon Lamp
will illuminate.
ABS Warning Lamp
Illuminates briefly when the ignition
is turned to the ON position. In an
emergency, apply continuous force
on the brake to prevent wheel lock
when braking on slippery surfaces - do
notpump your brakes. Any pulsation or noise
you may feel or hear is normal.
Hazard Flasher Control
Press to activate all hazard flashers
simultaneously in an emergency to warn traffic
of vehicle breakdown, approaching danger, etc.
Press the control again to turn the flashers off.
The hazard flashers can be operated when the
ignition is off.
Message Center (if equipped)
Please see Additional Features for more details.
Air Flow Adjust
You can direct or shut off the air flow from the
instrument panel registers. Turn the satin steel
portion on the round register module clockwise
to eliminate air, or counterclockwise to open
the air vents. Push and move the vent knob in
the direction you wish to adjust the airflow.
Audiophile In-Dash Six-CD Radio (if equipped)
Please see reverse side for more details.
2
5
6
7
Turn Signal &
Wiper/Washer
Control
4Service Engine
Soon Lamp
ABS
Warning
LampAudiophile
In-Dash Six-CD
Radio
(if equipped)
12Gearshift/Overdrive
Control
11Control-Trac
Four-Wheel
Drive Control
(if equipped)
14Speed
Control
13Steering
Wheel Controls
(if equipped)
6Hazard
Flasher
Control
16Hood
Release
10Rear Window
Defroster
5
Rear Window Defroster
Press to activate rear window defrost. The
rear defrost indicator will illuminate. When
in operation, the rear window defroster
also defrosts the side view mirrors. The rear
window defroster will automatically turn
off after approximately 10 minutes of
operation. Press the control again to
re-engage if needed.
Control-Trac Four-Wheel Drive Control (if equipped)
2H (2WD HIGH) delivers power
to the rear wheels only, and
is the optimum position for
smoothness and fuel
economy. A4WD (4X4 AUTO)
automatically delivers power
to all four wheels, as required, for
increased traction. 4H (4X4 HIGH) provides
mechanically locked four-wheel drive power
to all four wheels. 4L (4X4 LOW) provides
mechanically locked four-wheel drive when
extra power at reduced speeds is required.
To shift from 2H to A4WD or 4H, move the
control at any forward speed up to 55 mph.
To shift from A4WD to 4H, move the control
at a stop or while driving at any speed. To
shift to or from 4L, bring the vehicle to a stop
and keep the brake pedal depressed. Next,
place the gearshift in N (Neutral), and then
move the control to 4L.
When shifting from one four-wheel drive
position to the next, a mechanical noise may
be heard. This is normal and no service
should be required.
Gearshift/Overdrive Control
Overdrive is the normal drive position for
the best fuel economy. Only deactivate
(OFF) overdrive when: driving
with a heavy load, towing a
trailer up or down steep
hills, or when additional
engine braking is desired.
To deactivate, press the
switch located on the
end of the gearshift lever.
104
AdvanceTracTM System(if equipped)
This system provides a stability
and traction enhancement
feature by detecting and
controlling wheel spin. The
system defaults to on, however,
the system does not function when
the vehicle is traveling in R (Reverse), or if
equipped with four-wheel drive, in 4L. If
you should become stuck, try switching the
system off by pressing the button on the
center console.
Keyless Entry System
With this control you can lock or unlock
all doors without using a key. First, enter
your five-digit program code and then
press the corresponding quick key:
Unlock all doors = 3-4
Lock all doors = 7-8 and 9-0
simultaneously
Climate Controlled Seats(if equipped)
Push the left portion of the control to
heat the seat back and the seat cushion. A
red light will illuminate when the system
is engaged. Push again to disengage. Push
the right portion to cool the seat back
and the seat cushion. A blue light will
illuminate when the system is engaged.
Push again to disengage. When in the
heat or cool mode, rotate the
thumbwheel to select the desired level
from 0 (OFF) to 5 (MAX). If in the cool
mode and setting 1 is selected, the seat(s)
will provide vent cooling only (the same
temperature as cabin air).
Once the feature is activated, please
allow five minutes for the temperature
level to stabilize. Some initial blower noise
should be expected at the beginning of
the cool cycle.The climate control seats turn off after
approximately 15 minutes in heat mode and
approximately 30 minutes in the cool mode
to minimize unintended drain on the
vehicle’s power supply.
The climate control seat system includes an
air filter that has to be replaced periodically.
For more information, please consult your
Owner’s Guide.
Message Center (if equipped)
The message center
displays important
vehicle information
through a constant monitor of vehicle systems
(with the ignition in the ON position). The
system will notify you of potential vehicle
problems with a display of system warnings
followed by a long indicator chime. You may
select display features on the message center
by pressing the Info or Setup buttons. The
Reset button may be used to reset select
functions in the Info and Setup menus.
For complete details on the message center
display features, please refer to your
Owner’s Guide.
Reverse Sensing System (if equipped)
This sonar and radar system sounds a tone to
warn the driver if an obstacle is detected
within approximately 20 feet behind the rear
bumper while the vehicle moves in reverse at
speeds less than 6 mph. RSS defaults to ON,
but can be disabled using the message center
functions when the ignition is ON, and the
gearshift is in R (Reverse).
Tire Pressure Monitoring System (if equipped)
Using radio-frequency pressure sensors, this
system monitors tire pressure on all tires
including the spare, and provides the driver
with a warning message when pressure is
severely low or high. If alerted, the system can
be reset using the message center functions.
9
15Power Adjustable
Foot Pedals
In order to help you fully appreciate the countless features of
your new Expedition, we invite you to explore this easy-to-use
Quick Reference Guide. Using this Guide in conjunction with the
Interactive Owner Experience CD Rom, you can briefly hear how
to operate the features listed to the right once you place the CD
into any audio CD player. Find the numbered call-outs from the
photograph of the instrument panel located in the center of the
Quick Reference Guide, and then select the corresponding
numbered audio track on the CD. For more comprehensive
information, place the CD into any computer,* or consult your
Owner’s Guide.
This vehicle handles differently from an
ordinary passenger car in driving
conditions which may occur on streets
and highways and off-road. DRIVE
WITH CARE AND WEAR A SAFETY BELT AT ALL TIMES. Ford urges
you to read the Owners’ Guide and Driving Your SUV or Truck
Supplement for further information on safe driving precautions
and instructions.
Message
Center
(if equipped)
2
7
Headlamp
and Panel
Dimmer Control
11
9
8
Headlamp and Panel Dimmer Control
Rotate clockwise one
position from off to
turn on the parking
lamps. Rotate two
positions to also turn
on the headlamps. Rotate counterclockwise
to activate autolamp, which provides light-
sensitive automatic on-off control of the
exterior lights and keeps them on for a short
period of time after the ignition is turned
OFF. When the control is in any position
except high beams or off, pull the control
toward you to activate the foglamps.
Turn Signal & Wiper/Washer Control
Push down
to activate
the left
turn signal,
or up to activate the right turn signal. On
Eddie Bauer vehicles, the lower portion of
the corresponding side view mirror will blink
to provide an additional warning to other
drivers that your vehicle is about to turn.
For front-wiper operation, rotate the ring
on the left to the desired interval, low- or
high-speed position. When in the
intermittent position, rotate the control up
for fast and down for slow intervals. The
speed-sensitive feature also allows the wipers
to adjust automatically as the vehicle’s speed
changes when the wiper control is set on the
intermittent settings. Push the end of the
stalk briefly for a single wipe (no wash).
Push and hold to activate the washer.
The ring on the right operates the rear-
window wiper. Rotate the control to INT 2
(slow interval), INT 1 (fast interval), or
washer position.
For extended wiper blade quality, occasional
cleaning of the wiper blades is required.
3
Note:The transmission shift strategy will
slightly delay transmission upshift in cold
weather to decrease the time required to
warm up the engine and produce heat in
the passenger compartment.
Steering Wheel Controls (if equipped)
For audio control operation, press the
control with the musical note to select
which media to play. Depending on the
mode, press MEM to select a preset station,
the next selection on a tape, or the next
track on a disc. Use VOL to adjust volume.
For climate control operation, press TMP up
or down to adjust temperature. Press the
control with the fan icon up or down to
adjust fan speed.
Speed Control
To operate, the speed control
must be ON and the vehicle
speed must be greater than
30 mph. To set a speed,
press SET +. To set a higher
speed, press SET + again.
To set a lower speed,
press CST -. Pressing RES
will return to a previously
set speed. To turn the
speed control off, press
the OFF button, or depress the brake
pedal to disengage.
Power Adjustable Foot Pedals
Press and hold the rocker control
to adjust the accelerator and
brake pedal toward you or away
from you. Adjust the pedals
only when the vehicle is stopped
and the gearshift lever is in the
P (Park) position.
Hood Release
Pull the hood release handle toward you.
Next, release the auxiliary latch located
under the front center of the hood. Lift the
hood until the lift cylinders hold it open.
12
15
16
13
14
Air Flow
Adjust8
