emergency towing FORD EXPEDITION 2014 3.G Quick Reference Guide

COMFORT (continued)
Pull Strap
Position 2
Position 3
instrument Panel
Liftgate
Rear Quarter Panel
The sliding shade can be manually opened
or closed when the moonroof is closed. Pull
the shade toward the front of the vehicle to
close it.
Power LifTgaTe oPeraTion*
You can open your power liftgate three
different ways:
• Push the button on the instrument panel
•
Press the
button on your remote entry
transmitter twice within three seconds
•
Press the liftgate control button located
on the inside of the liftgate handle.
To close with the rear cargo area button,
press and release the control located on the
left, rear quarter panel.
Obstacle detection
If the power liftgate is closing, the system
is designed to reverse to fully open when it
encounters a solid obstacle. A three-second
tone also sounds when the system detects
an obstacle. Once the obstacle is removed,
the liftgate can be closed under power.
If the power liftgate is opening, the system is
designed to stop when it encounters a solid
obstacle. A tone will sound for three seconds
while the obstacle is present.
ESSENTIAL INFORMATION
eaSY fUeL® SYSTem
Your vehicle’s fuel system allows you to
open the fuel filler door, insert the nozzle
and start fueling. Wait 10 seconds from the
time the refueling nozzle is shut off until you
remove the nozzle from the vehicle to allow
residual fuel in the nozzle to drain into
the tank.
The Easy Fuel system is self-sealing and
therefore protected against dust, dirt,
water, snow and ice. If you need to fill your
fuel tank with a portable fuel container,
use the fuel funnel which is attached to
the underside of the spare tire cover or
is included with the tire changing tools.
Slowly insert the funnel into the Easy Fuel
system and fill the tank with fuel from the
container. When done, clean the funnel or
properly dispose of it. Extra funnels can be
purchased from your authorized dealer.
Note: Do not use aftermarket funnels as they
will not work with the Easy Fuel system and
may cause damage.
fUeL TYPe and fUeL Tank caP aciTY
Depending on your vehicle, your fuel tank
has a capacity of either 28 gallons (106L)
or 33.5 gallons (126.8L). Flex Fuel vehicles
have a yellow ring around the top of the fuel
filler inlet (tube) and can use either Regular
unleaded fuel, E85 Ethanol fuel or any
mixture of the two. It is best not to alternate repeatedly
between gasoline and E85.
If you do switch
fuels, it is recommended that you add
as much fuel as possible—at least half
a tank. Do not add less than five gallons
(18.9L) when refueling. You should drive
the vehicle immediately after refueling
for at least 5 miles (8 km) to allow the
vehicle to adapt to the change in ethanol
concentration. If you exclusively use E85
fuel, it is recommended to fill the fuel tank
with regular unleaded gasoline at each
scheduled oil change.
fUeL-efficienT TranSmiSSion
Your vehicle has been designed to improve
fuel economy by reducing fuel usage
while coasting or decelerating. This may
be perceived as a light to medium braking
sensation when removing your foot from
the accelerator pedal.
rear window BUffeTing
You may hear a pulsing noise when one or
both of the rear windows are open. Lower a
front window slightly to reduce this noise.
Tire PreSSUre moniToring SYSTem
Your vehicle is equipped with a Tire Pressure
Monitoring System (TPMS) that illuminates
a low tire pressure warning light when one
or more of your tires are significantly under- inflated.
If this happens, stop and check your
tires as soon as possible. Inflate them to the
proper pressure. Refer to the Inflating Your
Tires section in the Wheels and Tires chapter
of your Owner’s Manual for more information.
Loca Tion of SP are Tire and TooLS
Your vehicle is equipped with a temporary
spare tire located under the vehicle, just
forward of the rear bumper. The temporary
spare is designed for emergency use only
and should be replaced as soon as possible.
The jack and tools are located in the access
panel on the floor behind the third-row seat.
Make sure that you turn off the deployable
running boards (if equipped) as well as the
air suspension system (if equipped) prior to
jacking, hoisting or towing your vehicle. For
complete details on how to change your tire,
refer to the Roadside Emergencies chapter in
your Owner’s Manual.
page 13 page 12
To exit the third-row seating area
1. Pull the strap located at the bottom
outboard of the seatback to release it
from the floor. Rotate it up toward the
front seat.
2. Continue pulling up on the pull strap
and the seat will flip forward.
3. To return the seat to the upright
position, push the seat down until
it is latched.
4. Then, lift the seatback and the head
restraint to the upright position.
moonroof*
The moonroof control is located on the
overhead console. It has a one-touch
open and close feature. To stop its motion
during the one-touch operation, press the
control a second time.
To open, press and release the SLiDE
control. It will stop short of the fully
opened position to help reduce wind
noise. Press the SLiDE control again to
fully open the moonroof. To close, pull
and release the SLiDE control.
To vent, press and release the TiLT
control. Pull and hold the TiLT control to
close the moonroof.
*if equipped
roadSide aSSiST ance
Your new Ford Expedition comes with
the assurance and support of 24-hour
emergency roadside assistance.
To receive roadside assistance in the
United States, call 1-800-241-3673.
in Canada, call 1-800-665-2006.
